- Page 1 ATHENS 2 Twin RIAA Turntable Preamplifier with Network Audio Outputs PRODUCT DETAILS 6 BROOKS PLACE, MAIDSTONE, KENT, ME14 1HE. ENGLAND. TEL: +44 (0) 1622 753662 Visit our Website at www.glensound.com FAX: +44 (0) 1622 762330...
- Page 2 Glensound Electronics Ltd Thank you for choosing a new Glensound product. All rights reserved. Information contained in this manual is subject to change without notice, if in doubt please contact us for the latest product information. If you need any help with the product then we can be contacted at: Glensound Electronics Ltd 1 –...
-
Page 3: Product Warranty
PRODUCT WARRANTY: All equipment is fully tested before dispatch and carefully designed to provide you with trouble free use for many years. We have a policy of supporting products for as long as possible and guarantee to be able to support your product for a minimum of 10 years. For a period of one year after the goods have been despatched the Company will guarantee the goods against any defect developing after proper use providing such defects arise solely from faulty materials or... - Page 4 Twin RIAA Preamp with Dante/ AES67 outputs This declaration of conformity is issued under the sole responsibility of the manufacturer. This equipment is manufactured by Glensound Electronics Ltd of Brooks Place Maidstone Kent ME14 1HE is marked and conforms to the...
- Page 5 RoHS DIRECTIVE RoHS 2 Directive 2011/65/EU restricts the use of the hazardous substances listed below in electrical and electronic equipment. This product conforms to the above directive and for these purposes, the maximum concentration values of the restricted substances by weight in homogenous materials are: Lead 0.1%...
- Page 6 WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) Glensound Electronics Ltd is registered for business to business sales of WEEE in the UK our registration number is: WEE/JJ0074UR Page 6 of 30...
-
Page 7: Table Of Contents
ATHENS 2 GLENSOUND Handbook Contents Issue 1 Description Page No. Contents PRODUCT WARRANTY: ............................ 3 OVERVIEW ................................8 ATHENS 2 PANEL LAYOUT ..........................9 Front Panel ............................... 9 Front Panel Features ............................9 Rear Panel ..............................11 Rear Panel Features ............................. 11 CARTRIDGE SETUP ............................ -
Page 8: Overview
OVERVIEW Athens 2 is twin RIAA phono preamplifier with Dante® and AES67 network audio outputs. It is a mains powered device with two high quality stereo turntable preamplifiers inputs. Each preamplifier has its own set of preset controls to allow accurate matching of the Athens 2 input circuitary to the turntable’s cartridge. -
Page 9: Athens 2 Panel Layout
ATHENS 2 PANEL LAYOUT Front Panel Input 1 Left Channel Input 1 Right Channel Input 1 PPM Controls Controls Input 2 PPM Input 2 Right Channel Input 2 Left Channel Controls Controls Anti-Tamper Screw Front Panel Features 1. Input 1 Left Channel Controls These 12 preset dip switches provide controls to adjust the input gain, the input impedance and the input capacitance for the left channel input of input 1. - Page 10 4. Input 2 Left Channel Controls These 12 preset dip switches provide controls to adjust the input gain, the input impedance and the input capacitance for the left channel input of input 2. Please see the cartridge setup section of this handbook for detailed information.
-
Page 11: Rear Panel
Rear Panel Copper Ethernet Identify Button Mains Input Ports Input 2 Connectors Reset Button Input 1 SFP Ethernet Connectors Slots Rear Panel Features 8. Identify Button This is used in combination with the reset button during software updates…..see updating firmware for further details. 9. - Page 12 11. Input 2 Connectors These 3 connectors are the audio input circuits from the turntable. Two of the connectors are the left/ right audio circuits and these are standard RCA (sometimes called phono) connectors. The third connector is a 4mm screw terminal used for an audio ground circuit. If the attached turntable has an equivalent ground/ earth connector then the two should be connected.
-
Page 13: Cartridge Setup
CARTRIDGE SETUP For best results it is important to carefully setup the front panel dip switch (input channel controls) for both channels of both inputs. Most cartridge manufacturers supply information such as the recommended load impedance and the recommended load capacitance. The Athens 2’s input should be set to match these recommended figures. -
Page 14: Gain Settings
Gain Settings NOTE: Please set input impedance and input capacitance prior to setting the gain. NOTE: Only 1 gain dip switch should be on at any time for gain settings. The quick and simple way of setting the gain is to connect your turntable and play a record then adjust the gain dip switches such that the PPM only ever occasionally peaks at +6. -
Page 15: Input Impedance Settings
Input Impedance Settings Most cartridge manufacturers provide the recommended load impedance for their cartridges. The Athens 2’s inputs should be set to match this recommended figure as closely as possible. 4 dip switches adjust the input impedance and more than one dip switch can be turned on at the same time. -
Page 16: Input Capacitance Settings
Input Capacitance Settings If you’re using a Moving Magnet cartridge then the manufacturer will provide the recommended load capacitance. The Athens 2’s inputs should be set to match this recommended figure as closely as possible. If you’re using a Moving Coil cartridge then the input capacitance should be set to minimum (15 pF (all capacitance dipswitches off)) 4 dip switches adjust the input capacitance and more than one dip switch can be turned on at the same time. -
Page 17: Network Dbfs Levels
NETWORK dBFs LEVELS The Athens 2 provides 2 separate stereo network audio outputs for each of the 2 input preamplifiers. One of these stereo outputs references 0dBu = - 18dBFs The other of these stereo outputs references 0dBu = -24dBFs Please note the front panel PPM is set for 0dBu = -18dBFs and if you are working in an environment utilising 0dBu = -24dBFs then the PPM will read too high and the -6dB LED will actually represent 0dB. -
Page 18: Connecting The Athens 2 To A Dante® Network
CONNECTING THE ATHENS 2 TO A DANTE® NETWORK The Athens 2 is a network audio devices utilizing the reliable and versatile Dante® audio over IP protocol. Dante® is a proprietary system (although very widely used) the originators of which are Audinate. The information below is only meant as a very basic guide. -
Page 19: Running Dante Controller
Running Dante Controller At the time of writing this manual the Dante Controller looks as per the screenshot below: The Athens 2 will have been named at the factory during test to allow them to be identified by the Dante controller. The format used for the factory name is: ‘Athens2-snXXX’... -
Page 20: Device Not Showing Up In Dante Controller
Device Not Showing Up In Dante Controller ® ® If your Dante device does not show up in Dante Controller then the most likely issue is that the device’s IP Address is not appropriate for your network. A) It maybe that the device is set to obtain an IP address automatically using DHCP (this is the default configuration) and your network is setup for fixed IP addresses only and does not have a DHCP server. -
Page 21: Aes67 Mode
AES67 and therefore the Athens 2 can be set to AES67 mode for interaction with other AES67 devices. Please note however that Glensound are relying on Audinate’s AES67 interface and are unfortunately not able to provide full AES67 support for the unit. AES67 support should be sought directly from Audinate. - Page 22 2. Sending AES67 Audio To transmit AES67 audio to the network a multicast flow must first be setup. This is done by selecting the ‘Create New Multicast Flow’ Icon in the Device View. Tick the AES67 Flow check box, then select up to 4 channels to be included in the flow then click ‘Create’...
-
Page 23: Updating Firmware
“DfuSe_Demo_V3.0.5_Setup.exe”, then run and install it. 2. Download firmware The latest firmware for the Athens 2 can be found on the Glensound website, under the product page for Athens 2 device. Once you have downloaded the file, place it in a folder or location of your choice. - Page 24 4. Firmware update preperation To prepare the Athens 2 for a firmware update; 1. Press and hold down the Enter Setup button 2. Power on the unit 3. Release the Enter Setup button Your PC should make an audible sound when this process is successful as windows is detecting a new USB device.
- Page 25 Figure 3 Choose .dfu file Click choose and then select the .dfu file that you downloaded from the Glensound website. This will be located in your downloads folder by default. If the file loads successfully then it will read along the bottom ‘File correctly loaded’.
- Page 26 The firmware is now ready to be put on to the Athens 2. Tick the ‘Verify after download’ box first and then click ‘Upgrade’. Figure 5 Upgrade Click yes to proceed. Figure 6 Start upgrade The progress bar along the bottom will show the status of the operation.If the operation was successful, DfuSe Demo will report that “Target 00: Verify Successful!”.
- Page 27 Figure 8 Successful upgrade! 7. Final steps Now click “Leave DFU mode” to finish the procedure. Figure 9 Final step You may now disconnect the USB cable and continue to use the Athens 2 with the freshly updated firmware! Page 27 of 30...
-
Page 28: Updating The Brooklyn Chipset
UPDATING THE BROOKLYN CHIPSET The Brooklyn module is a device supplied by Audinate that does most of the processing for the actual Dante/ AES67 network audio streams. There is one Brooklyn module in each Athens 2. We supply special code (a .dnt file) that sets up/ initiates the Brooklyn module and makes it work in particular way that is compatible to the Athens 2. -
Page 29: Specifications
SPECIFICATIONS RIAA EQUALISATION The Athens 2 uses a hybrid of Analogue & DSP circuits to perform its RIAA equalisation. In the below graph two horizontal light blue/ purple lines show the frequency output of the two channels of the amplifier after the RIAA equalisation. The level reference is the right Y axis (right hand scale) and the frequency range is the X (bottom) axis. -
Page 30: Specifications
SPECIFICATIONS NETWORK/ Dante® AUDIO Physical Interface Input Gain Range 2 off Rj45 60 to 40dB 2 off SFP slots Input Impedance (Ohms) Audio Sample Frequency 47000, 1000, 470, 320, 220, 180, 150, 130, 48kS/s 100, 90, 80, 76, 68, 60, 56 Transfer Rate Input Capacitance (pF) 1000 Mbps...
