Page 1: User Guide
ADA2:6 Analogue Distribution Amplifier 2 in 6 out (Stereo) or 1 in 12 out (Mono) User Guide Glensound 6 Brooks Place, Maidstone Kent, UK, ME14 1HE Tel: +44 (0)1622 753662 www.glensound.co.uk... - Page 2 Glensound Electronics Ltd Thank you for choosing a new Glensound product. All rights reserved. Information contained in this manual is subject to change without notice, if in doubt please contact us for the latest product information. If you need any help with the product then we can be contacted at: Glensound Electronics Ltd 1 –...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This symbol is intended to highlight that This symbol is intended to warn that there are important operating & dangerous voltages within the product are maintenance instructions in the literature present and constitute a risk of electric accompanying this unit. - Page 4 IMPORTANT: MAINS PLUG WIRING INSTRUCTIONS This Signature unit is supplied with a moulded mains plug fitted to the AC mains lead. Mains wiring colours/ connections: The Green/ Yellow or Green wire must be connected to the terminal in the plug marked ‘E’...
- Page 5 Emissions: EN55103.1 Immunity: EN55103.2 WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) Glensound Electronics Ltd is registered for business to business sales of WEEE in the UK our registration number is: WEE/JJ0074UR RoHS2 DIRECTIVE EC directive 2011/65/EU restricts the use of the hazardous substances listed below in electrical and electronic equipment.
-
Page 6: Product Warranty
PRODUCT WARRANTY: All equipment is fully tested before dispatch and carefully designed to provide you with trouble free use for many years. We have a policy of supporting products for as long as possible and guarantee to be able to support your product for a minimum of 10 years. For a period of one year after the goods have been despatched the Company will guarantee the goods against any defect developing after proper use providing such defects arise solely from faulty materials or workmanship and that the... -
Page 7: Table Of Contents
ADA2:6 Analogue Distribution Amlifier Handbook Contents Issue 1, Description Page No. Contents IMPORTANT SAFETY INSTRUCTIONS ........................3 PRODUCT WARRANTY: ..............................6 OVERVIEW ..................................8 PHYSICAL INSTALLATION ..............................9 AUDIO BLOCK DIAGRAM ..............................11 EXAMPLES OF USE ................................12 Radio Station CTA ............................... 12 Commentary Feed @ IBC ........................... -
Page 8: Overview
A front panel toggle switch selects between these 2 modes. The ADA2:6 is powered from an internal switch mode mains power supply fed from a filtered IEC mains plug suitable for use Worldwide. It has an internal fuse for safety. The unit can also alternatively be powered from an external +/-12V DC power source (such as the Signature Series PS1). -
Page 9: Physical Installation
PHYSICAL INSTALLATION The Glensound Signature Series have been designed to be highly versatile for installation and can be installed in 19” racks with either their front or rear panels facing the front of the rack. They can also be mounted underneath desks or work tops and can be either permananetly mounted or stood (using the supplied feet) on top of desks or worktops. - Page 10 SWAPPING RACK EARS TO ALLOW THE REAR TO BE INSTALLED AT THE FRONT OF A RACK PART No Signature Series PWR ON K e e p s W o rkin g PIN 1 = GND PIN 2 = +12V (100mA) PIN 3 = -12V (100mA) 100-240V +/-12V - - -...
-
Page 11: Audio Block Diagram
AUDIO BLOCK DIAGRAM INTERNAL FUSE +12V 100 - 240 VAC AC/DC PSU -12V EXT DC +/-12V GAIN/ LOSS CONTROL LEFT (MONO) IN RIGHT IN MONO/ STEREO SWITCH (SHOWN IN MONO) Page 11 of 16... -
Page 12: Examples Of Use
EXAMPLES OF USE Radio Station CTA ISDN 2 x XLR3 Backup 2 x XLR3 Transmiter 2 x XLR3 Mixer Output 2 x XLR3 Logging (balanced or unbalanced) 2 x XLR3 Local Monitoring 2 x XLR3 Digital Services 2 x XLR3 Headphone The main stereo programme audio from a radio station needs to be distributed across multiple platforms. -
Page 13: User Controls
USER CONTROLS 1. Gain/ Loss Controls 2. Mono/ Stereo Switch Gain/ Loss Controls The front panel preset gain controls are recessed to prevent accidental usage. A small screwdriver is required to adjust the controls. The gain/ loss controls adjust a gain stage amplifier after the input amplifiers but before the output amplifiers. -
Page 14: Wiring Information
WIRING INFORMATION Standard Pin Outs STANDARD XLR AUDIO PINOUTS: 1: Ground/ Earth XLR SOCKET (FEMALE) 2: INPHASE/ POSITIVE/ MIC + 3: MATE/ NEGATIVE/ MIC - XLR PLUG (MALE) STANDARD HEADPHONE WIRING: RING TIP: A/ LEFT Ear RING: B/ RIGHT Ear SLEEVE SLEEVE: Common/ Earth HEADPHONE WIRING NOTE:... -
Page 15: Wiring To Unbalanced Devices
Wiring to unbalanced devices The input & output circuits of the Signature Series can be connected to unbalanced (domestic style) devices. The wiring diagrams below show a mono jack plug as the unbalanced end of the cable but this of course could easily be a different type of connector such as an RCA Phono or ‘D’... -
Page 16: Technical Specification
TECHNICAL SPECIFICATION AUDIO POWER Frequency Response Mains Input <-0.5dB 20Hz to 20kHz Filtered IEC, 100 to 240VAC 47 - 63Hz Gain Range AC Consumption -10dB to +15dB 2.8 Watts @ 230VAC Maximum Input Level DC Input >+28dB FEATURES 4 Pin Neutrik XLR plug +/- 12V Maximum Output Level Internal Mains Fuse +24dBu...
