Bob's Discount Furniture PDEV100BTSPLEG Assembly Instructions

Caution: Please read instructions thoroughly before unpacking assembly parts. Sharp, exposed staple tips can
cause injury, therefore, for your protection, please remove any exposed staples used in packing.
1. We recommend that you should assemble this product with the assistance of another person; this will make
assembly easier, and will help to eliminate damage to the product or injury to persons during assembly.
2. Be sure to check all packing materials carefully for small parts that may have come loose inside the carton
during shipment.
3. Please do not over tighten screws or bolts.
4. Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble your
newly purchased product correctly and efficiently.
PART LIST FOR BAR TABLE
PART DESC
No.
A
BAR TABLE TOP
B Bar Table Single Pack Black Finish - L & R Leg
C Bar Table Single Pack Black Finish - Short Stretcher
D Bar Table Single Pack Black Finish - Long Stretcher
STEP:1
5
STEP:4
Date: 05-Aug-2019
Assembly Instructions
BAR TABLE
Q'TY
CODE.
1
PDEV100BTSPLEG 4
PDEV100BTSPSTR1 2
PDEV100BTSPSTR2 1
STEP:2
Do not tighten these bolts before
Setting up long stretcher.
3
2
1
4
5
HARDWARE LIST PACKED INSIDE BOX
HARDWARE DESC
No.
ALLEN BOLT (5/16" x 60mm)
1
SPRING WASHER (5/16")
2
FLAT WASHER (5/16")
3
ALLEN KEY (M4)
4
SCREWS (M4x38mm)
5
STEP:3
3
2
1
4
COMPLETED
Q'TY
CODE.
8
8
PDEV100BTSPHW
8
1
6
5
