A S S E M B LY I N S T R U C T I O N S
The Roman Trellis
Please read through before starting assembly.
Check Box for These Contents
In the event of missing or defective parts please call our customer service dept. at 1 800 282 9346, ext #20 (Mon. to Fri. 8:00 AM to 4:00 PM EST).
1. Pre-Assembled Roman Trellis (1)
2. Post Caps (2)
3. Ground Anchoring Stakes (2)
4. Hardware (in plastic bag)
a)
5/8" Self-Auguring Stainless Steel Screws (8)
b)
#2 Robertson Drill Bit (1)
Tools You Will Need
• Cordless Drill
• Hammer
• Tape Measure
• Level
• Shovel
General Information
• Read Instructions through carefully before beginning assembly.
• When assembling components, place on a non-abrasive surface
(i.e. shipping box) to avoid scratching.
• We recommend an area approx 5'x 8' for unobstructed assembling.
• You should not need to use excessive force when assembling components.
(Pre-Assembled)
53.65
4
28.94
20
27.27
2
1
3
www.edenarbors.com
3.37
2
4 a
b
Not to Scale
1
Advertisement
Table of Contents
Related Manuals for Eden Roman Trellis
Summary of Contents for Eden Roman Trellis
- Page 1 Check Box for These Contents In the event of missing or defective parts please call our customer service dept. at 1 800 282 9346, ext #20 (Mon. to Fri. 8:00 AM to 4:00 PM EST). 1. Pre-Assembled Roman Trellis (1) 2. Post Caps (2) 3.
- Page 2 Mounting Into the Ground Trellises must be well secured in the event of high winds, etc. We have provided two ground anchoring stakes for securing the privacy screen either into the ground or into a concrete footing. If you are installing your trellis directly to the wall of your home,or on a wood deck or concrete surface,please see your hardware store for the appropriate galvanized bracket hardware.
