Installing The Handle - Intermec CK30 Instructions

Use these instructions to install the handle on a CK30 or CK31 Handheld Computer.
To install the handle
(CK31 only) Remove the adhesive backing
1
from the spacer.
(CK31 only) Insert the spacer on the
2
CK31 handle and press to make sure it is
securely attached.

Installing the Handle

Spacer
Installing the Handle
Installing the Handle (continued)
3
Place the handle on the computer.
4 Tighten the screw so the handle does not move.
If you have a torque screwdriver, tighten the screw to
1.26 Nm (12 in-lb) maximum.
Do not overtighten the handle screw.
You may damage the threads or cause
the trigger mechanism to jam.
