- Page 1 12/2017 Mod: BMIV15/R2 Production code: 19046413...
- Page 2 INSTRUCTIONS MANUAL: REFRIGERATED TABLES ************** Profi Line Cod: 12170202...
-
Page 3: Table Of Contents
REFRIGERATED TABLES INSTALLATION, USE AND MAINTENANCE LANGUAGE INDEX Mesas Refrigeradas (Español)…………………………………………………………………………………………. 1 Tables Frigorifiées (Français)………………………………………………………………………………………… 8 Refrigerated Tables (English)……………………………………………………………………………………….… 15 Kühltische (Deutsch)..…………………………………………………………………………………. 22 Koeltafels (Nederlands)…………..……………………………………………………………………. 29 Tavoli Refrigerati (Italiano)……………………………………………..……………………………………..36 CONTENTS INSTALLATION ..........................16 POSITIONING ........................16 CLEANING ..........................16 GENERAL .......................... -
Page 4: Installation
INSTALLATION 1.0 POSITIONING Remove the packaging except the support pallet. A forklift truck or pallet truck can be used to move it to its installation site, lifting the refrigerated table making sure that it is not unbalanced. The table must not be dragged over the floor. The area where the table is positioned must be clear and clean, preventing the refrigerator equipment's fan from absorbing materials, which are then deposited on the condenser's ribbing, reducing the efficiency of the system. -
Page 5: Matriculation Plate
A table consumption table for adjusting the protection is attached POWER CURRENT CONSUMP. GENERAL DIFFEERENCIAL POSITIVE TABLES VOLTAGE FUSTE (T) DEVICE MR2/R2, BMIV15/R2 230v 50Hz 30 mA MR3/R2, BMIV20/R2 230v 50Hz 30 mA MR4/R2 230v 50Hz 30 mA MATRICULATION PLATE Explanation of the matriculation plate accompanying your unit. -
Page 6: Start-Up
START-UP When the inside of the unit has been cleaned, plug it into the electricity network and turn the switch to ON or I. The switch must be on. The temperature in the thermostat indicated the air temperature inside the table. ... -
Page 7: Recommendations
WARNING: Do not use electrical appliances inside the compartments designed for storing food unless they are of the type recommended by the manufacturer. The table you have purchased is designed to preserve drinks and food. We recommend not hot food or containers, nor chemical, corrosive products or medicines inside the refrigerator, and avoiding the incorrect use of the unit. -
Page 8: Maintenance
MAINTENANCE With these guidelines, we would like to offer both you and the technical assistance service help so that the table always works perfectly throughout its useful life. We will cover the cleaning you can carry out as well as a quick machine check before contacting the technical support service. -
Page 9: Special Maintenance
SPECIAL MAINTENANCE (authorised technical personnel) Condenser cleaning: When cleaning, take care not to bend the condenser aluminium ribs, as on the contrary the air will not come through and will not condense, causing serious damage to the appliance and its repair guarantee will be made void. ...
