- Page 1 OPERATORS MANUAL Authorised Representative STRAW HARROW DOC0132 REV-00 CLAYDON YIELD-O-METER LTD BUNTERS ROAD, WICKHAMBROOK, NEWMARKET, SUFFOLK, CB8 8XY TEL: +44 (0)1440 820 327 EMAIL: info@claydondrill.com www.claydondrill.com...
- Page 2 DOC0132 REV-00 CLAYDON YIELD-O-METER LTD © BUNTERS ROAD, WICKHAMBROOK, NEWMARKET, SUFFOLK, CB8 8XY TEL: +44 (0)1440 820 327 EMAIL: info@claydondrill.com www.claydondrill.com...
- Page 3 CONTENTS WARRANTY REGISTRATION DECLARATION OF CONFORMITY IDENTIFICATION OF MACHINE INTRODUCTION SAFETY DIRECTIVE PROVISIONS PRE-WORK PREPARATION IN FIELD OPERATION CARE AND MAINTENANCE PARTS MANUAL PARTS MANUAL INDEX OPERATORS MANUAL - 9M STRAW HARROW...
-
Page 5: Warranty Registration Card
Receive updates about your product including safety updates. Download your documents. Get support. In order to activate your Claydon Warranty this page & the Warranty check sheet and conformation form must be completed and returned to: Service Department Claydon Yield-O-Meter Ltd... - Page 7 Warranty registration document is completed & the end user has signed it and the document is sent to Claydon. In the event of a dealer not being present it is the customers responsibility to return this form to the following address.
-
Page 9: Declaration Of Conformity
Directive(s) Oliver Claydon Director of Operations Done at Gaines Hall Wickhambrook On: 07/03/2016 The technical documentation for the machinery is available from: Claydon Yieldometer Ltd Bunters Road Wickhambrook Newmarket, Suffolk, CB8 8XY OPERATORS MANUAL - 9M STRAW HARROW... -
Page 10: Identification Plate
Serial No: 2021 Year: 1500/2000 Mass Min/Max: Mass Min/Max - Maximum/Minimum laden mass of the vehicle in ‘Kg’ Model - Machine information Serial No - Serial number of machine Year - Year of manufacture OPERATORS MANUAL - 9M STRAW HARROW... -
Page 11: Identification Of Machine
Please ensure separate warranty registration card is filled in upon purchase of your machine to validate warranty claims. This is located at the rear of the operators manual. TECHNICAL DATA HORSE POWER WORKING TRANSPORT WEIGHT NUMBER OF HARROW MACHINE REQUIREMENTS WIDTH WIDTH (APPROX) TINES (ESTIMATED) 2100KG 175HP OPERATORS MANUAL - 9M STRAW HARROW... - Page 12 Claydon Yield-O-Meter Ltd using the contact details given on the front cover. The Claydon Straw Harrow will give many years of excellent service with little maintenance due to its robust construction and its small number of moving parts. However, regular routine maintenance will give you the optimum efficiency and working machine life of your machine.
-
Page 13: Decal Locations
If any of the decals become illegible or damaged, new decals can be ordered and attached in the appropriate position. The decals must not be removed. OPERATORS MANUAL - 9M STRAW HARROW... - Page 14 SAFETY Decal Locations OPERATORS MANUAL - 9M STRAW HARROW...
- Page 15 High pressure fluid can puncture skin causing serious injury or death. DC0037 Keep clear of slewing range. There is an extreme risk of injury or death from slewing or folding machine parts. DC0039 OPERATORS MANUAL - 9M STRAW HARROW...
- Page 16 Re-tighten all nuts and bolts. All nuts should be checked and re-tightened after a few operating hours. Nuts may come loose due to machine vibration. DC0035 Avoid overhead cables. DC0038 Hydraulic connections. Hydraulic connections overview. DC0122 OPERATORS MANUAL - 9M STRAW HARROW...
-
Page 17: Machine Overview
‘Left’ indicates the left of the machine as you look at the machine from the rear ‘Right’ indicates the right of the machine as you look at the machine from the rear. Front Left Rear Right OPERATORS MANUAL - 9M STRAW HARROW... - Page 18 DIRECTIVE PROVISIONS Machine Overview 1. Manual holder 2. Electronic junction box 3. Machine folding ram 4. Harrow tines 5. Harrow tine folding ram 6. Rear lights OPERATORS MANUAL - 9M STRAW HARROW...
-
Page 19: Airborne Noise Emissions
DIRECTIVE PROVISIONS Directive Provisions Directive Provisions This Claydon Straw Harrow conforms to Machinery Directive 2006/42/EC (see Declaration of Conformity at the front of the manual). AIRBORNE NOISE EMISSIONS WARNING AND CAUTION These warnings and cautions must be observed when operating the Straw Harrow •... - Page 20 PRE-WORK PREPARATION Connecting Straw Harrow to the Tractor The Claydon Straw Harrow can be mounted onto any compatible three point linkage with the linkage pins supplied and CATIII balls (not supplied). Once the Straw Harrow is attached and at the correct working depth, the top link should be set at an angle in which the convergence point between the upper and lower link arms should fall at the front axle.
- Page 21 MACHINE INTO TRANSPORT. Raise the machine off the ground, fold tines back and fold the wings fully upright. Ensure sufficient clearance is present between the rear of the Straw Harrow and the ground prior to folding. OPERATORS MANUAL - 9M STRAW HARROW...
- Page 22 SETTING MACHINE LEVEL For optimal working, the Claydon Straw Harrow must be set level from front to rear on the top link of the tractor when in the working position. Failure to achieve this will result in the harrow blocking with straw in the front if the top link is too short or in the back if the top link is too long.
-
Page 23: Working Height
WORKING HEIGHT The Claydon Straw Harrow has no depth wheels and is designed to carry its own weight on the tines. If you are finding that the Straw Harrow is doing more work than you would like you can transfer more of the harrows weight on the tractors three point linkage. -
Page 24: Field Use
You should pull the Claydon Straw Harrow as quickly as you can (up to speeds of 25 km/h). From time to time (very rarely) the Straw Harrow can catch a lump or a tramline and start to bounce, in this scenario you should slow down or stop until the machine has settled and then carry on as normal. -
Page 25: Care And Maintenance
CARE AND MAINTENANCE CARE AND MAINTENANCE The Claydon Straw Harrow requires very little maintenance in order to provide reliable service. Prior to using the machine, the Straw Harrow should be checked for any broken tines or hydraulic fluid leaks. Ensure all bolts are retightened after the first eight hours of use. -
Page 26: Winter Storage
WHILST STORING IT OVER THE WINTER PERIOD. 1. Wash machine down and wait for it to dry. 2. Ensure all lubricating points are greased. (See pages 25 for grease points) 3. Ideally store inside a building OPERATORS MANUAL - 9M STRAW HARROW... - Page 27 CARE AND MAINTENANCE OPERATORS MANUAL - 9M STRAW HARROW...
- Page 28 CLAYDON YIELD-O-METER LTD BUNTERS ROAD, WICKHAMBROOK, NEWMARKET, SUFFOLK, CB8 8XY TEL: +44 (0)1440 820 327 EMAIL: info@claydondrill.com www.claydondrill.com...
