  • Page 1 OPERATORS MANUAL HYBRID Authorised Representative M3F & M4RF DOC0017 REV-01 CLAYDON YIELD-O-METER LTD BUNTERS ROAD, WICKHAMBROOK, NEWMARKET, SUFFOLK, CB8 8XY TEL: +44 (0)1440 820 327 EMAIL: info@claydondrill.com www.claydondrill.com...
  • Page 2 DOC0017 REV-01 CLAYDON YIELD-O-METER LTD © BUNTERS ROAD, WICKHAMBROOK, NEWMARKET, SUFFOLK, CB8 8XY TEL: +44 (0)1440 820 327 EMAIL: info@claydondrill.com www.claydondrill.com...
  • Page 3 CONTENTS WARRANTY REGISTRATION DECLARATION OF CONFORMITY IDENTIFICATION OF MACHINE INTRODUCTION SAFETY DIRECTIVE PROVISIONS PRE-WORK PREPARATION IN FIELD OPERATION CARE AND MAINTENANCE OPERATORS MANUAL - HYBRID - M3F & M4RF...

  • Page 5: Warranty Registration Card

    WARRANTY REGISTRATION CARD Your Claydon product warranty cover will begin on the date of installation and last 12 months. Receive updates about your product including safety updates. Download your documents Get support In order to activate your Claydon Warranty this page & the Warranty check sheet and...
  • Page 7 Warranty registration document is completed & the end user has signed it and the document is sent to Claydon. In the event of a dealer not being present it is the customers responsibility to return this form to the following address.

  • Page 9: Declaration Of Conformity

    We: Claydon Yieldometer Ltd of: Gaines Hall in accordance with the following Directive(s): 2006/42/EC The Machinery Directive Hereby declare that Equipment: Claydon Drills Model number: Hybrid Serial Number: 3mFH0001 - 3mFH**** is in conformity with the applicable requirements of the following documents Ref.
  • Page 10 IDENTIFICATION OF MACHINE Identification Plate UK / GERMAN FRENCH Claydon Yield-O-Meter LTD, Claydon Yield-O-Meter LTD, Gaines Hall, Wickhambrook, Gaines Hall, Wickhambrook, Newmarket, Suffolk, CB8 8XY Newmarket, Suffolk, CB8 8XY TEL: 0044 1440 820327 TEL: 0044 1440 820327 CLAYDON Marque Category / Kategorie...

  • Page 11: Warranty Registration

    *With level boards removed MAXIMUM ROAD SPEED Maximum permissible road speed for the Claydon machine is 40kmh empty. 20kmh fully loaded. Always consult and abide by local traffic laws regarding speed limits for agricultrial vehicles on the public highway. OPERATORS MANUAL - HYBRID - M3F & M4RF...
  • Page 12 Claydon Yield-O-Meter Ltd using the contact details given on the front cover. The Claydon M3F & M4RF will give many years of excellent service with little maintenance due to its robust construction and its small number of moving parts. However, regular routine maintenance will give you the optimum efficiency and working machine life of your drill.
  • Page 13 SAFETY Decal Locations Safety decals can be found located on your machine in numerous locations, these decals must be observed to ensure your safety and that the machine is operated in a safe manner. If any of the decals become illegible or damaged, new decals can be ordered and attached in the appropriate position.
  • Page 14 SAFETY Decal Location DC0091 OPERATORS MANUAL - HYBRID - M3F & M4RF...
  • Page 15 SAFETY Decal Locations SAFETY DECALS IF BOUT MARKERS ARE FITTED OPERATORS MANUAL - HYBRID - M3F & M4RF...
  • Page 16 SAFETY Decal Meanings DECAL MEANING Read the operating manual carefully. Prior to operating the machine the manual must be read fully and understood. Special attention should be applied to the Warnings and Cautions section. DC0026 Do not stand between the tractor and the machine. Standing between tractor and the drill is especially prohibited during coupling and uncoupling.
  • Page 17 SAFETY Decal Meanings DECAL MEANING Risk of crushing Gaps between components may become smaller or disappear completely. DC0029 Risk of crushing. Gaps between or under components may become smaller or disappear completely. DC0030 Re-tighten all nuts and bolts. All nuts should be checked and re-tightened after a few operating hours.
  • Page 18 SAFETY Decal Meanings DECAL MEANING Calibration. Calibration instructions. DC0012 Electric warning. Beware of overhead cables when using or working on the machine. DC0091 DC0091 OPERATORS MANUAL - HYBRID - M3F & M4RF...
  • Page 19 DIRECTIVE PROVISIONS Machine Overview The terms ‘front’ ‘rear’ ‘left’ and ‘right’ in this manual refer to the machine as follows: ‘Front’ indicates the attachment end of the machine ‘Rear’ indicates the machine end when viewed from the rear ‘Left’ indicates the left of the machine as you look at the machine from the rear ‘Right’...
  • Page 20 DIRECTIVE PROVISIONS Machine Overview 1. Hopper. 2. Distribution head. 3. Ladder platform. 4. Start stop sensor. 5. Leading tines. 6. Seeding tines. 7. Depth wheel. 8. Ski boards. 9. Rear harrow tines. 10. Rear lights / Pre-Emergence markers (Depending on specification) OPERATORS MANUAL - HYBRID - M3F &...

  • Page 21: Airborne Noise Emissions

    DIRECTIVE PROVISIONS Directive Provisions Directive Provisions This Claydon Hybrid Seed Drill conforms to Machinery Directive 2006/42/EC (see Declaration of Conformity at the front of the manual). AIRBORNE NOISE EMISSIONS The A-weighted emission sound pressure level of measurements taken directly at the fan is 94dBA.
  • Page 22 2 x M16 U-Bolts for Tine 1 x Control Unit and Cable 1 x Control Unit Mounting Bracket and Bolts 1 x Tractor Power Cable 1 x Claydon Instruction Manual 1 x Claydon Instruction DVD 1 x Parts Catalogue 1 x Calibration Tongs...

  • Page 23: Electrical Connections

    PRE-WORK PREPARATION Connecting the Drill to the Tractor The Claydon Drill can be mounted onto any CATIIIN or CATIVN compatible three point linkage with the linkage pins supplied. Once the drill is attached and at the correct working depth, the top link should be set at an angle in which the convergence point between the upper and lower link arms should fall at the front axle.

  • Page 24: Hydraulic Connections

    ISO. Incase of difficulty knowing the correct connections available on the rear of your tractor consult your tractor operators manual or Claydon dealer immediately for assistance. Failure to connect tractor to drill correctly can result in serious damage to hydraulic components on both drill and tractor.
  • Page 25 PRE-WORK PREPARATION Transporting the Drill When the drill is in transport, the Hydraulic valve taps (located on the hydraulic cylinders) should be locked off to prevent the marker arms being unfolded. This will only be applicable to M3F machine’s fitted with marker arms.
  • Page 26 PRE-WORK PREPARATION Pre-work Preparation ACCESSING THE HOPPER WARNING TO PREVENT DAMAGE TO THE MACHINE ENSURE THE LADDER IS RETURNED TO ITS UP POSITION WHILST MACHINE IS IN USE. Access to the hopper for loading seed and fertiliser is by means of the ladder and hopper access platform. 1.
  • Page 27 PRE-WORK PREPARATION Pre-work Preparation OPENING THE HOPPER ENSURE HOPPER COVER IS CLOSED WHEN THE MACHINE IS WORKING To fill the hopper with seed or fertiliser is by means of removing the hopper cover. 1. Hopper cover The hopper cover is To release the hopper Slowly release the Once finished pull the...
  • Page 28 PRE-WORK PREPARATION Pre-work Preparation SETTING THE MARKER ARM WIDTH (WHERE FITTED) On delivery of the drill the marker arms may be in their shortest position for transport. Both marker arms will have to be set up for the working width of the machine. Additionally, should the driving position not be central (either through driver’s choice or position of the seat) it may be necessary to adjust the two markers to avoid gaps or over drilling.
  • Page 29 IN FIELD OPERATION Field Use of the Drill SETTING MACHINE LEVEL It is important that the seeding chassis is set level from front to rear to gain accurate and consistent seed depth between the front and rear seeding tines. This is done by altering the length of the top link on the tractor until the front and the rear seeding tines are the same height as shown in the diagram below.
  • Page 30 IN FIELD OPERATION Field Use of the Drill SETTING THE START STOP In work the Top Link must always be higher at the drill than it is at the tractor. See page 29 for an example. OUT OF WORK (NOT SEEDING) 150mm The start stop finger switch should be set so that when the drill is lifted out of work the switch is in the off position.

  • Page 31: Setting The Seed Depth

    IN FIELD OPERATION SETTING THE SEED DEPTH The depth control of the machine is controlled by the depth wheels. To obtain the desired depth alter the three top links on the depth wheel axles. Use a tape measure to ensure all three axles are the same. Once the correct depth is achieved it is possible to lock off the top links using the locking tab on the top thread on the links.
  • Page 32 IN FIELD OPERATION ADJUSTING THE LEADING TINE Set the leading tine using the diagram below as a general guide to obtain the correct depth. 75 - 100mm 100mm 125mm 120 -150mm Spring Beans Cereals Autumn Beans Oilseed and Maize Rape The top hole should not be used on brand new tines;...
  • Page 33 IN FIELD OPERATION SETTING THE SEED DEPTH A quick guide to correct drilling depth is to check the A-Shares relative to the soils surface. The diagram below displays the recommended A-Share (2) depth for Oilseed rape (shoulder of A-Share should coincide with soils surface) and Wheat (top of A-Share should coincide with ground surface).
  • Page 34 IN FIELD OPERATION SKI BOARDS AND TINES ADJUSTMENT SETTINGS The Ski Board height is altered on the adjuster located on the swivel beams (as shown below). The Ski Boards can be lifted completely out of work with this adjuster or have some downward pressure applied to them. Depending on the field conditions the following Ski Board settings are recommended and should be achieved using the adjuster: Wet conditions - Remove pressure from Ski Boards...
  • Page 35 IN FIELD OPERATION PRE-EMERGENCE MARKERS Depending on your machines specifications pre-emergence markers may be fitted to your machine. This optional extra allows tramline marks to be made visible behind the drill, therefore making it easier to apply pre-emergence sprays. Images of the markers can be seen below. 1.
  • Page 36 IN FIELD OPERATION SETTING THE HOPPER LEVEL SENSOR Ensure that the Hopper mesh is removed to gain access to the Hopper level sensor then secured back in place upon completion. 1. Hopper level sensors The seed level sensor can be set in three positions for different seed rates: the upper for high seed rates, the middle setting for medium seed rates and the lower position for low seed rates i.e.

  • Page 37: Setting The Fan Speed

    Claydon recommend that the fan speed is set between 3500rpm to 4000rpm. The fan speed is adjusted by changing the flow of oil on the hydraulic spool valve on the tractor.
  • Page 38 IN FIELD OPERATION AIR FLOW SPLITTER BOX Air Flow Splitter Box Location The air flow splitter box provides the availability to increase and decrease flow of air to the distribution heads to achieve the desired airflow for each product used. Adjust air flow and balance between seed hoses by adjusting butterflies in splitter box.
  • Page 39 IN FIELD OPERATION SETTING UP METERING UNITS Metering unit location Metering unit location Prior to explaining the calibration process an overview of the metering units highlighting the various components can be seen in the diagrams below. 4. 5. 7. 1. Hopper emptying flap 8.
  • Page 40 IN FIELD OPERATION SETTING THE SEED SIZE SOWING RATE Set the seed rate required on the ISOCAN unit in the tractor. Now set the metering unit to the corresponding setting using the table located on the side of the machine. Adjust the metering unit to the correct position using the decal as a guide.
  • Page 41 IN FIELD OPERATION Seed Rate Calibration Chart - M3F OPERATORS MANUAL - HYBRID - M3F & M4RF...
  • Page 42 IN FIELD OPERATION Seed Rate Calibration Chart - M4RF OPERATORS MANUAL - HYBRID - M3F & M4RF...
  • Page 43 IN FIELD OPERATION Calibrating the Seed / Fertiliser rate CALIBRATING THE DRILL IMPORTANT Always ensure that the machine is stationary on level ground, correctly connected to the tractor with handbrake applied before commencing calibration. Calibrating the drill ensures the correct amount of seed is distributed over the area required. Tools required for Calibration: Basket ISOCAN Unit...
  • Page 44 IN FIELD OPERATION Application Rate Setting The ISOCAN system allows for you to manually set your application rates for each metering unit channel. Note: All application rates are set in metric units ‘Kg/Ha’ Step 1: Cycle through until you are on the screen shown in ‘Figure 1’. Figure 1 - Application Rate Screen Step 2: Select by using either the touch screen or the side keys to highlight (highlighted in blue) the appropriate metering channel you wish to set - as shown in ‘Figure 2’.
  • Page 45 IN FIELD OPERATION Application Rate Setting Step 4: Enter the required rate followed by the button as seen in ‘Figure 4’. Note: The ISOCAN system can be programmed for use with up to 4 metering channels. Be careful to set the correct application rate for the correct metering channel.
  • Page 46 IN FIELD OPERATION CALIBRATING THE DRILL IMPORTANT Always ensure that the tongs are fitted correctly and ensure hands are kept away from the moving parts of the metering unit during the calibration process. Always ensure the seed rate is set on the ISOCAN screen before commencing calibration.
  • Page 47 IN FIELD OPERATION Step 3 Place bucket or appropriate container under venturi as per image. 1. Container IMPORTANT Prior to initiating the calibration process it is important to purge the metering unit. (This only needs to be done once). Press and hold the calibration button until the metering has started.
  • Page 48 IN FIELD OPERATION IMPORTANT ACCURATE SCALES ENSURE ACCURATE CALIBRATION. ENSURE YOUR SCALES ARE TESTED AND WORKING ACCURATELY AND CORRECTLY. Step 5 Weigh the amount of seed dispensed and take note of the weight. Note: Ensure the scales are properly zeroed or allow for the weight of the bucket / container used.
  • Page 49 IN FIELD OPERATION Step 7 Enter the weight from the scales (Step 5). Press Note: When entering the weight data it is recommended to use all 3 decimal places for input after the decimal point if possible. If the weighing scales only use 2 decimal places this will suffice.
  • Page 50 IN FIELD OPERATION HOPPER TO HOPPER TRANSFER KIT If fertiliser is not required to be sown alongside seed the Hopper to Hopper transfer kit can be attached. This optional extra allows for seed to be transferred from the fertiliser hopper to the seed hopper. 1.
  • Page 51 IN FIELD OPERATION HOPPER TO HOPPER TRANSFER KIT Step 3 Step 4 Fit the yellow bypass plate and tighten the wing Re-fit the transfer pipe and jubilee clip so that it is nuts so it is securely fastened (See image below). secure.

  • Page 52: Care And Maintenance

    CARE AND MAINTENANCE LUBRICATING POINTS LUBRICATING POINTS Lubrication should be performed using Lithium Complex 3 grease for all grease points. An overview of the greasing points for the M3F Machine can be seen below. Wheel bearings should be greased every 50 hours and all other grease points should be greased daily.
  • Page 53 CARE AND MAINTENANCE LUBRICATING POINTS LUBRICATING POINTS Lubrication should be performed using Lithium Complex 3 grease for all grease points. An overview of the greasing points for the M4RF Machine can be seen below. Wheel bearings should be greased every 50 hours and all other grease points should be greased daily.
  • Page 54 CARE AND MAINTENANCE CHANGING WEARING PARTS IMPORTANT IF WORK IS REQUIRED TO BE CARRIED OUT WHILST THE DRILL IS RAISED, ENSURE A SUBSTANTIAL PROP IS POSITIONED SAFELY UNDER THE DRILL PREVENTING IT FALLING UNDER ITS OWN WEIGHT. CHANGING LEADING TINE To change the front tine, simply remove the lynch pin and remove the 19mm pin, slide the entire tine out and replace the entire tine with a new one.
  • Page 55 CARE AND MAINTENANCE CHANGING WEARING PARTS IMPORTANT NEVER HIT THE TUNGSTEN CARBIDE TILES WITH A HAMMER, WEAR GLOVES AND SAFETY GLASSES WHEN WORKING WITH THE TUNGSTEN CARBIDE PARTS. NEVER HIT THE LOCKING PIN WITH A HAMMER AND PUNCH OR ANYTHING SIMILAR AS THIS WILL DAMAGE THE SPRING.
  • Page 56 CARE AND MAINTENANCE CHANGING WEARING PARTS IMPORTANT NEVER HIT THE TUNGSTEN CARBIDE TILES WITH A HAMMER, WEAR GLOVES AND SAFETY GLASSES WHEN WORKING WITH THE TUNGSTEN CARBIDE PARTS. NEVER HIT THE LOCKING PIN WITH A HAMMER AND PUNCH OR ANYTHING SIMILAR AS THIS WILL DAMAGE THE SPRING.

  • Page 57: Tyre Pressures

    CARE AND MAINTENANCE TYRE PRESSURES The depth wheel tyres should be inflated to a pressure of 1.5 Bar (22 psi). Ensure depth wheel nuts are tightened to a torque setting of 210Nm. Marker arm tyres should be inflated to a pressure of 0.6 Bar (8.70 psi). Ensure marker arm wheel nuts are tightened to a torque setting of 110Nm.

  • Page 58: Winter Storage

    CARE AND MAINTENANCE WINTER STORAGE IMPORTANT TO MAINTAIN THE LIFESPAN OF YOUR DRILL, IT IS IMPORTANT TO TAKE THE RIGHT PRECAUTIONS WHILST STORING IT OVER THE WINTER PERIOD. 1. Empty the metering unit and hopper of all seed or fertiliser products. (Trapdoors must be left open and the metering unit should be wound out so the gap is at its greatest).
  • Page 59 CARE AND MAINTENANCE PAGE LEFT BLANK OPERATORS MANUAL - HYBRID - M3F & M4RF...
  • Page 60 CLAYDON YIELD-O-METER LTD BUNTERS ROAD, WICKHAMBROOK, NEWMARKET, SUFFOLK, CB8 8XY TEL: +44 (0)1440 820 327 EMAIL: info@claydondrill.com www.claydondrill.com...
