- Page 1 OPERATORS MANUAL TERRABLADE Authorised Representative DOC0022 REV-01 CLAYDON YIELD-O-METER LTD BUNTERS ROAD, WICKHAMBROOK, NEWMARKET, SUFFOLK, CB8 8XY TEL: +44 (0)1440 820 327 EMAIL: info@claydondrill.com www.claydondrill.com...
- Page 2 DOC0022 REV-01 CLAYDON YIELD-O-METER LTD © BUNTERS ROAD, WICKHAMBROOK, NEWMARKET, SUFFOLK, CB8 8XY TEL: +44 (0)1440 820 327 EMAIL: info@claydondrill.com www.claydondrill.com...
- Page 3 CONTENTS WARRANTY REGISTRATION DECLARATION OF CONFORMITY IDENTIFICATION OF MACHINE INTRODUCTION SAFETY DIRECTIVE PROVISIONS PRE-WORK PREPARATION IN FIELD OPERATION CARE AND MAINTENANCE OPERATORS MANUAL - TERRABLADE...
-
Page 5: Warranty Registration Card
WARRANTY REGISTRATION CARD Your Claydon product warranty cover will begin on the date of installation and lasts 12 months. Receive updates about your product including safety updates. Download your documents Get support In order to activate your Claydon Warranty this page & the Warranty check sheet and... - Page 7 Warranty registration document is completed & the end user has signed it and the document is sent to Claydon. In the event of a dealer not being present it is the customers responsibility to return this form to the following address.
-
Page 9: Declaration Of Conformity
We: Claydon Yieldometer Ltd of: Gaines Hall in accordance with the following Directive(s): 2006/42/EC The Machinery Directive Hereby declare that Equipment: Claydon Drills Model number: Terrablade Serial Number: TB00001 - TB***** is in conformity with the applicable requirements of the following documents Ref. -
Page 10: Identification Plate
PTAC - Technically permissible maximum laden mass Serial No - Serial number of machine of the vehicle in ‘Kg’ Year - Year of manufacture 1 - Max weight on axle 2 - N/A 3 - N/A 4 - Max weight on hitch OPERATORS MANUAL - TERRABLADE... -
Page 11: Identification Of Machine
MACHINE (APPROX) REQUIREMENTS WIDTH WIDTH HEIGHT WORKING ROWS UNLOADED (ESTIMATED) 3.3M 2.6M 1.8M 450KG 4.3M 2.9M 1.8M 610KG TB4.8 5.1M 2.9M 2.2M 654KG 6.3M 2.9M 2.8M 724KG 8.3M 2.9M 3.7M 796KG MTB3 3.3M 2.7M 1.3M 320KG OPERATORS MANUAL - TERRABLADE... - Page 12 Claydon Yield-O-Meter Ltd using the contact details given on the front cover. The Claydon Terrablade will give many years of excellent service with little maintenance due to its robust construction and its small number of moving parts. However, regular routine maintenance will give you the optimum efficiency and working life of your machine.
-
Page 13: Decal Locations
If any of the decals become illegible or damaged, new decals can be ordered and attached in the appropriate position. The decals must not be removed. 3m Only 3m Only DC0082 OPERATORS MANUAL - TERRABLADE... - Page 14 SAFETY Decal Locations 3-Section DC0082 Terrablades Only Terrablades DC0038 DC0038 OPERATORS MANUAL - TERRABLADE...
- Page 15 High pressure fluid can puncture skin causing serious injury or death. DC0037 Keep clear of slewing range. There is an extreme risk of injury or death from slewing or folding machine parts. DC0039 OPERATORS MANUAL - TERRABLADE...
- Page 16 Nuts may come loose due to machine vibration. DC0035 Keep a safe distance. Ensure that no one is allowed to stand within the operating range of the machine. DC0033 Avoid overhead cables. DC0038 Folding Terrablade. DC0082 Operating instructions (Folding) DC0082 OPERATORS MANUAL - TERRABLADE...
-
Page 17: Machine Overview
‘Left’ indicates the left of the machine as you look at the machine from the rear. ‘Right’ indicates the right of the machine as you look at the machine from the rear. Front Left Rear Right OPERATORS MANUAL - TERRABLADE... - Page 18 SAFETY Machine Overview 1. Depth wheel 2. Folding ram 3. Hoe blade 4. Manual holder 5. Hydraulic connections OPERATORS MANUAL - TERRABLADE...
-
Page 19: Airborne Noise Emissions
DIRECTIVE PROVISIONS Directive Provisions Directive Provisions This Claydon Terrastar conforms to Machinery Directive 2006/42/EC (see Declaration of Conformity at the front of the manual). AIRBORNE NOISE EMISSIONS WARNING AND CAUTION These warnings and cautions must be observed when operating the Terrablade •... - Page 20 Front Mounting Once the Terrablade is attached and at the correct working depth, the top link should be set at an angle so that the upper link point on the Terrablade is higher than the upper link point on the tractor. This can be achieved by altering the top link pin attachment points on the tractor and Terrablade.
-
Page 21: Hydraulic Connections
PRE-WORK PREPARATION HYDRAULIC CONNECTIONS Terrablade fold connections Terrablade unfold connections DC0082 To connect the Terrablade: 1. Connect the fold and unfold 1/2” ISO connectors (1 & 2) to the tractor. OPERATORS MANUAL - TERRABLADE... - Page 22 ENSURE ADEQUATE GROUND CLEARANCE BEFORE FOLDING AND DURING TRANSPORT TO AVOID GROUNDING THE MACHINE Raise the machine off the ground and fold the wings fully upright before transporting. TERRABLADE SHOULD ALWAYS BE PARKED / DROPPED OFF IN ITS FOLDED POSITION. OPERATORS MANUAL - TERRABLADE...
- Page 23 FLOAT POSITION The Terrablade has been designed to scalp weeds at the growing crowns. This requires the blade to dig into the ground 2cm to effectively kill weeds. This 2cm working depth is achieved by the inclination of the blade, the blade angle and setting the working depth.
- Page 24 The top link is the fine adjustment and the front hole is the coarse adjustment. The depth wheel setting should remain the same once the machine has been set. Bottom of box section 345mm 325mm OPERATORS MANUAL - TERRABLADE...
- Page 25 In wet weather and soft ground, the blades require less pressure. If too much pressure is put on them they will dig in aggressively. This will cause the blade to uproot the weed without cutting and not kill the weed. OPERATORS MANUAL - TERRABLADE...
- Page 26 Driving the Terrablade FRONT OR REAR MOUNTING The Terrablade can be front mounted using the three point linkage. When using the 3m, Claydon recommends mounting the Terrablade to the front of the tractor for more accurate results. Alternatively the 3m Terrablade can be rear mounted. Towing the Terrablade will require reversing the blade bars and refitting.
- Page 27 REAR MOUNTING THE TERRABLADE (3m ONLY) ENSURE SAFETY BOOTS AND GLOVES ARE WORN WHILST WORKING ON THIS MACHINE To change from front orientation of the Terrablade to rear orientation, please follow the steps as shown below. STEP 1 Locate wheels...
-
Page 28: Field Use
For the best results the Terrablade width should be matched to the drill width, and follow in the same tracks as the drill. This avoids problems with operational misalignment. However, the end blade should always overlap, and in some circumstances, may slightly damage the end row of the adjacent drilling. -
Page 29: Care And Maintenance
Lubrication should be performed using Lithium complex 3 grease for all grease points. An overview of the greasing points for the Terrablade can be seen below. Note: Grease in intervals of 10 hours. Increase greasing when drill is used in extreme conditions (e.g. dust &... -
Page 30: Winter Storage
IS IMPORTANT TO TAKE THE RIGHT PRECAUTIONS WHILST STORING IT OVER THE WINTER PERIOD. 1. Wash machine down and wait for it to dry 2.Ensure all lubricating points are greased. (See pages 29 for grease points) 3. Ideally store inside a building OPERATORS MANUAL - TERRABLADE... - Page 31 CARE AND MAINTENANCE OPERATORS MANUAL - TERRABLADE...
- Page 32 CLAYDON YIELD-O-METER LTD BUNTERS ROAD, WICKHAMBROOK, NEWMARKET, SUFFOLK, CB8 8XY TEL: +44 (0)1440 820 327 EMAIL: info@claydondrill.com www.claydondrill.com...
