Maintenance - Suburban SDN2 Installation, Operation And Service Manual

1. Know which knob controls which burner. Always be sure the correct burner is
turned on.
2. Depress knob and turn fully counter-clockwise
a. Verify sufficient gas supply before attempting to light the burner. Air
in the gas line will significantly delay burner ignition. The burner may light
unexpectedly as the air in the line clears and is replaced by LP gas. This
unexpected ignition could burn you. Air in the gas lines may occur after the
vehicle gas bottle and/or tank is refilled, during and after servicing other
appliances on same gas line, etc.
b. Do not attempt to light more than one burner at a time.
c. Immediately light burner by holding a long match near the burner ports.
CAUTION: Hand held ignitors may be used but be sure they are the type
designed for lighting open flame burners.
3. If any burner should extinguish after initial lighting or due to accidental
blow-out, turn gas off by turning control knob clockwise
five (5) minutes before attempting to relight the burner. Failure to follow these
instructions could result in a fire or explosion.
If the burner should go out while cooking, or if there is an odor of gas, turn
control knob(s) clockwise to "OFF". Wait five (5) minutes for gas odor to
disappear. If gas odor is still present - Do not relight burners. See "What To Do If
You Smell Gas" on the front cover of this manual.
4. To turn burner(s) "OFF", turn the appropriate control knob clockwise
"OFF".
WARNING! Be sure all control knobs are turned "OFF" when you are not
cooking. Someone could be burned or a fire could start if a burner is
accidently left on or unattended even if only momentarily.
WARNING! If the user of this appliance fails to maintain it in the
to "Lite" position.
condition in which it was shipped from the factory or if the appliance is
not used solely for its intended purpose or if appliance is not maintained
in accordance with the instructions in this manual, then the risk of a
fire and/or the production of carbon monoxide exists which can cause
personal injury, property damage or loss of life.
1. Make sure all controls are "OFF" and the drop-in cook top is cool before
cleaning.
2. Make sure that all cook top surfaces, burner grates and burners are cool
before cleaning or disassembling cook top.
3. Do not use oven cleaners, bleach or rust removers on the cook top or burner
grates.
to "OFF", wait
4. Do not obstruct the flow of combustion and ventilation air.
5. Clean all surfaces as soon as possible after boil overs or spill overs.
6. Use warm soapy water only to clean the burner grates, cook tops, painted
surfaces, porcelain surfaces, stainless steel surfaces and plastic items on your
drop-in cook top. Do not use grit or acid-type cleaners.
7. Do not use steel wool or abrasive cleaners. They will damage your drop-in
cook top. Use only non-abrasive plastic scrubbing pads.
8. Do not allow foods containing acids (such as lemon or tomato juice, or vinegar)
to
to remain on porcelain or painted surfaces. Acids may remove the glossy finish.
9. Do not wash warm porcelain surfaces. Allow these areas to cool before
cleaning. You could burn yourself or the porcelain could crack.
10. Pitting and discoloration will result if spills are allowed to remain for any
length of time on stainless steel.
11. Do not allow spill overs to remain on the burner caps. The caps could be
permanently stained if spill overs are not cleaned up promptly.
12. If any of the burner ports or the orifice are clogged, carefully clean with a
small wire or needle. Be sure not to enlarge ports. Never use a wire brush for
cleaning burner ports or orifice. Never use any brush which may "shed" bristles,
which may become lodged in the orifice or burner ports and cause a fire or
explosion.
TO REMOVE THE STOVE TOP
1. Remove the two (2) thumb screws from the sides of the stove top. Lift the
stove top clear of the burner box.
2. To reinstall top, reverse the procedure.
TO REMOVE GRATE(S)
1. Remove the top.
2. Squeeze opposite sides of the grate together and lift free of the drop-in top.
3. To reinstall grate(s) reverse the procedure.
5

MAINTENANCE
