Suburban SRNA3 SERIES Installation, Operation And Service Manual
Recreational vehicle range and cooktops
Hide thumbs
Also See for SRNA3 SERIES:
- Installation, operation and service manual (13 pages) ,
- Installation, operation and service manual (12 pages)
Advertisement
RECREATIONAL VEHICLE RANGE AND COOKTOPS
IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY,
A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE,
PERSONAL INJURY OR DEATH.
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS
AND LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
● DO NOT TRY TO LIGHT ANY APPLIANCE.
● DO NOT TOUCH ANY ELECTRICAL SWITCH.
● DO NOT USE ANY PHONE IN YOUR RECREATIONAL VEHICLE.
● CLEAR THE RECREATIONAL VEHICLE OF ALL OCCUPANTS.
● TURN OFF THE GAS SUPPLY TANK VALVE(S) OR MAIN GAS
SUPPLY.
● IMMEDIATELY CALL YOUR GAS SUPPLIER FOR INSTRUCTIONS.
● IF YOU CANNOT REACH YOUR GAS SUPPLIER, CALL THE FIRE
DEPARTMENT.
HAVE THE GAS SYSTEM CHECKED AND LEAKAGE SOURCE
CORRECTED BY A QUALIFIED INSTALLER, SERVICE AGENCY,
MANUFACTURER OR DEALER OR THE GAS SUPPLIER.
INSTALLER: Provide this manual to the owner/user of the recreational vehicle.
OWNER: Retain these instructions and warranty for future reference. Read this manual carefully
before operating appliance. Follow all safety notices and warnings. All technical and warranty
questions should be directed to the company listed on the warranty, or rating plate located
underneath the main top.
Part Number 203705
05-05-2014
INSTALLATION, OPERATION AND
SERVICE MANUAL
All SRNA3 and SRSA3 Model Variations
(Short and Long Oven)
All SCN3, SCNA3, SCS3 and
SCSA3 Slide-In Cooktop Model Variations
WARNING
WHAT TO DO IF YOU SMELL GAS
IMPORTANT:
For
AIRXCEL, INC. - SUBURBAN DIVISION
676 Broadway Street
Dayton, Tennessee 37321
423-775-2131
Fax: 423-775-7015
www.RVComfort.com
Advertisement
Table of Contents
Related Manuals for Suburban SRNA3 SERIES
Summary of Contents for Suburban SRNA3 SERIES
-
Page 1: What To Do If You Smell Gas
AIRXCEL, INC. - SUBURBAN DIVISION 676 Broadway Street Dayton, Tennessee 37321 423-775-2131 Fax: 423-775-7015 www.RVComfort.com RECREATIONAL VEHICLE RANGE AND COOKTOPS INSTALLATION, OPERATION AND SERVICE MANUAL All SRNA3 and SRSA3 Model Variations (Short and Long Oven) All SCN3, SCNA3, SCS3 and... -
Page 2: Installation
WARNING! Installation of this appliance must be made in accordance with the written instructions provided in this manual. No agent, representative or employee of Suburban or other person has the authority to change, NOTE: The appliance must be disconnected from the gas supply piping system modify or waive any provision of the instructions contained in this during any pressure testing of that system at test pressure in excess of 1/2 PSIG. -
Page 3: Oven Burner
For broiling, a 2-piece porcelain broiler pan can be purchased from into the RV. Remember, gas flow to each burner is controlled manually, Suburban: you must turn gas flow “ON” and “OFF”. 1. Center the broiler pan underneath the oven burner flame. b. A boil over could occur and the spill could ignite. -
Page 4: Parts And Service
TO REMOVE THE WIRE GRATE AND MAIN TOP FOR SERVICE AND CLEANING 1. Remove the wire grate by raising straight up. Use caution not to dislodge the Contact a conveniently located recommended Suburban Service Center. grommets in the top (one at each corner). Describe to them the nature of your problem, make an appointment, if necessary, 2. -
Page 5: Two Year Limited Warranty
TWO YEAR LIMITED WARRANTY This Suburban product is warranted to the original purchaser to be free from defects in material and workmanship under normal use and maintenance for a period of two years from date of purchase whether or not actual use begins on that date. All porcelain parts, including top burner grates, are warranted as commercially accept- able only as of the date the product was manufactured. - Page 6 UL LABEL BACK WALL MOUNTING SURFACE (COUNTER TOP) MUR ARRIERE SURFACE DE MONTAGE (PLAN DE TRAVAIL) ETIQUETTE UL 9.000 OF BURNER DU BRULEUR 6.000 C L OF BURNER DU BRULEUR Figure 1 Figure 1A MIN. DIM. TO EITHER SIDE WALL DÉGAGEMENT DE SÈCURITÈ...
- Page 7 OVEN VENT OPENINGS OVEN VENT OPENINGS OUVERTURES D'AÉRATION (FOUR) OUVERTURES D'AÉRATION (FOUR) HIGH INPUT BURNER HIGH INPUT BURNER BRÛLEUR DE HAUTE PUISSANCE BRÛLEUR DE HAUTE PUISSANCE CONVENTIONAL BURNER SEALED BURNER BRÛLEUR CONVENTIONNEL BRÛLEUR SCELLÉ Figure 4 GRATE GRATE GRILLE GRILLE REAR REAR ARRIÈRE...
