RECREATIONAL VEHICLE RANGE AND COOKTOPS
ALL SRNA3 and SRSA3 MODEL VARIATIONS
SLIDE-IN COOKTOP MODEL VARIATIONS
IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY,
A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE,
PERSONAL INJURY OR DEATH.
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS
AND LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
WHAT TO DO IF YOU SMELL GAS
● DO NOT TRY TO LIGHT ANY APPLIANCE.
● DO NOT TOUCH ANY ELECTRICAL SWITCH.
● DO NOT USE ANY PHONE IN YOUR RECREATIONAL VEHICLE.
● CLEAR THE RECREATIONAL VEHICLE OF ALL OCCUPANTS.
● TURN OFF THE GAS SUPPLY TANK VALVE(S) OR MAIN GAS
SUPPLY.
● IMMEDIATELY CALL YOUR GAS SUPPLIER FOR INSTRUCTIONS.
● IF YOU CANNOT REACH YOUR GAS SUPPLIER, CALL THE FIRE
DEPARTMENT.
HAVE THE GAS SYSTEM CHECKED AND LEAKAGE SOURCE
CORRECTED BY A QUALIFIED INSTALLER, SERVICE AGENCY,
MANUFACTURER OR DEALER OR THE GAS SUPPLIER.
INSTALLER: Provide this manual to the owner/user of the recreational vehicle.
OWNER: Retain these instructions and warranty for future reference. Read this manual carefully
before operating appliance. Follow all safety notices and warnings. All technical and warranty
questions should be directed to the company listed on the warranty, or rating plate located
underneath the main top.
Part Number 203705
08-09-2016
INSTALLATION, OPERATION AND
SERVICE MANUAL
(SHORT and LONG Oven)
ALL SCN3, SCNA3, SCS3 and SCSA3
WARNING
IMPORTANT:
AIRXCEL, INC. - SUBURBAN DIVISION
676 Broadway Street
Dayton, Tennessee 37321
423-775-2131
Fax: 423-775-7015
www.Airxcel.com
FOR
