Page 1 Installation, Operation & Maintenance Manual Butler/Butler2/ ButlerX/Linear Table of Contents: iSteam3 Control PUR100514 1-15pg AromaSteam SteamHead PUR100421 16-17pg Linear SteamHead PUR103936 18-28pg SteamLinx Mobile App PUR100518 29-31pg MS/Super AutoFlush PUR100200E 32-34pg MX AutoFlush PUR100532 35-37pg Condensation Pan TS0012 38-39pg steam ®...
Page 2 Installation, Operation & Maintenance Manual iSteam ® 3 Control steam ® Feel Good Inc. PUR100514 5.22...
Page 3: Important Safety Instructions
When installing and using this electrical equipment, basic safety precautions R E A D M E F I R S T ! should always be followed, including the following: IMPORTANT SAFETY INSTRUCTIONS As you follow these instruc- WARNING tions, you will notice warning and caution READ AND FOLLOW ALL INSTRUCTIONS symbols.
Page 4: Table Of Contents
Table of Contents: Important Safety Instructions ......2 Box Contents: I N S T A L L E R I N F O R M A T I O N ® 3 Control Installation Template ........2 (30 ft.) Box Content ..........3 Dimensional Information ......
Page 5: Before Installing
Do not alter or modify with the MrSteam control’s intended use and function. any Mr. Steam products including the steam generator or iSteam3 control. Doing so may result in an inopera- CAUTION tive or hazardous installation and will void the warranty.
Page 6: Locating The Control
® INSTALLER INFORMATION Locating the Control Determine the desired installation location of the control. The iSteam ® controls are designed to be installed inside or outside the steam room as a matter of personal preference. If the control is installed inside the steam room: location representative of the desired steam bathing temperatures.
Page 7: Installation Without Rough-In Box
® INSTALLER INFORMATION Installation with Optional Rough-In Box (cont.) IMPORTANT NOTE: Be careful not to strain, staple, pinch or otherwise damage the cables. Route cables as required to permit replacement. Do not route cables inside conduit together with power lines or close to hot water or steam piping. STEP 6 Use the rough-in box as a guide to cut out the Rough-In box used as...
Page 8 ® INSTALLER INFORMATION Installation Instructions for iSteam ® STEP 1 PLUG the 30’ control cable into the iSteam3 control pigtail (1a). Turn the generator on and test the control to verify correct connection. With proper function, proceed to Step 2. Do not force or twist cable ends together.
Page 9 ® INSTALLER INFORMATION Installation Instructions for iSteam ® (cont.) STEP 2 Peel the double stick adhesive off the back of the iSteam3 control (2a). Apply a bead of silicone around the rear of the iSteam3 control to create a moisture seal (2b).
Page 10 steam ® H O M E O W N E R S E C T I O N When installing and using this electrical equipment, basic safety precautions R E A D M E F I R S T ! should always be followed, including the following: As you follow these instruc- WARNING...
Page 11: User/Homeowner Information
® USER/HOMEOWNER INFORMATION Operating Instructions Set the steam bathing duration and WARNING temperature according to personal preference, Touch anywhere to wake up control however it is highly recommended to begin steam bathing at a low temperature setting to gauge comfort and safety levels. Set the duration at 10 minutes max.
Page 12: Chromasteam
® USER/HOMEOWNER INFORMATION Set Temperature Screen 1 0 1 1 2 : 1 6 Press the TEMPERATURE button on the Dashboard to access the SET TEMPERATURE screen. Swipe The control is preset and will display a temperature Up and Down setting of 110 °...
Page 13 ® USER/HOMEOWNER INFORMATION AudioSteam 1 2 : 1 6 Press the music icon to access the AudioSteam screen. M U S I C Press the MUSIC button to turn on AudioSteam. When AudioSteam is ON, pressing the MUSIC button Press to turn will turn it OFF.
Page 14 ® USER/HOMEOWNER INFORMATION 1 2 : 1 6 Settings Screen S y s t e m S e t t i n g s The Setting Screen allows access to less frequently D a t e & T i m e used screens.
Page 15: System Log
® USER/HOMEOWNER INFORMATION AutoStart Turn AutoStart ON or OFF AutoStart will automatically turn the steam genera- WARNING tor on at your preset time. Activating the steam in an occupied 1 2 : 1 6 room may subject persons to the hazards described in this manual.
Page 16: Warranty
® USER/HOMEOWNER INFORMATION Care Tips Use only mild soap and water on a soft cloth to clean the control. Do not use abrasive cleansers. Safety and Operating Information A peel and stick warning sticker is provided WARNING in the MrSteam steam generator Installation, Operation and Maintenance Manual.
Page 17 Installation, Operation & Maintenance Manual AromaSteam SteamHead steam ® Feel Good Inc. PUR100421 5.22...
Page 18 steam ® S T E A M H E A D ___________________________________________________________________________________________________________________________________________ I N S TA L L AT I O N I N S T R U C T I O N S 1/8" minimum clearance required when Acrylic Shield is used. See installation instructions IMPORTANT: See the Installation and Operation Manual Use Teflon...
Page 19 Installation, Operation & Maintenance Manual Linear Steam Head Residential Model: 104480 IMPORTANT: Leave this material with the homeowner. steam ® Feel Good Inc. PUR103936 5.22...
Page 20 Linear Steam Head ® ® Installer Section Model 104480 READ ME FIRST! This highlights information that is especially As you follow these instructions, you relevant to a problem free installation. will notice symbols. This information is important for the proper, safe and trouble free All information in these instructions is based on the latest installation of the Linear Steam Head.
Page 21 Linear Steam Head ® ® Installer Section Model 104480 accessories...etc.). If the installation and operation manuals are Steambath controls feature an integral or remote temperature sensor that senses room temperature. not available go to www.mrsteam.com for an online copy, or contact MrSteam Customer or Technical Services at 800-767- Install the linear steam head in a location where steam 8326 or 800-727-8326 for free copies.
Page 22 Linear Steam Head ® ® Installer Section Model 104480 Bracket Adjustment Screws Adjustable Brackets P104481 - Linear Steam Head 104483 - Faceplate BOX CONTENTS: 104484 - Diverter • Linear Steam Head • AromaTray • Faceplate • Silicone Sealant 104482 - AromaTray •...
Page 23 Linear Steam Head ® ® Installer Section Model 104480 Steam Head Installation Linear SteamHead shown without the optional faceplate STEP 1. Confirm proper stud spacing: The studs or diverter. must have a minimum spacing of 14-1/8” and a maximum spacing 19". If the stud spacing is outside Copper Tubing the required range then shim or otherwise reposition or Brass Pipe...
Page 24 Linear Steam Head ® ® Installer Section Model 104480 Optional Faceplate Installation Thin Set The steam head is supplied with an optional faceplate. It is not required for the functional operation of the steam head. The faceplate is a decorative accessory and is Vapor Barrier Finished available in (8) finishes.
Page 25 Linear Steam Head ® ® Installer and Home Owner Section Model 104480 Steam Emission Zone The Steam Emission Zone is the area in front of the steam head that contains dense, hot steam as it exits the steam head. Steam dissipates as it moves away from the steam head, and becomes less hot. The steam zone is the area where contact with steam presentees a scalding hazard.
Page 26 Linear Steam Head ® ® Installer and Home Owner Section Model 104480 Diverter The Linear SteamHead is supplied with an optional steam diverter. The steam diverter is used to reduce the steam emission zone as required to avoid contact between a steam bather and direct steam emissions.
Page 27 Linear Steam Head ® ® Installer and Home Owner Section Model 104480 AromaTray The AromaTray is for use with MrSteam Essential Oils. Place a few drops of Rubber Portion for secure placement Essential Oils in the AromaTray as shown to provide a fragrant steam bath experience.
Page 28 Linear Steam Head ® Linear Steam Head ® ® ® Using MrSteam Essential Oils Model 104480 Using MrSteam Essential Oils Model 104480 Enjoy Mr.Steam essential oils by placing a drop or two, into your Mr.Steam AromaTray as shown in the illustration. Only use Enjoy Mr.Steam essential oils by placing a drop or two, into your Mr.Steam AromaTray as shown in the illustration.
Page 29 : 1 800 72 STEAM 2020 © MrSteam and des., A Lifetime of Pleasure, AirTempo, AromaFlo, AudioWizard, AutoFlush, AutoSteam, Butler Package, ChromaSteam, Clean Steam...Every Time, Club Therapy, CT Day Spa, Digital 1, Express Steam, Feel Good Inc., From Bathroom to Spa, HomeWizard, iButler, iGenie, iSpa Package, iSteam, iTempo, iTempo/Plus, Linear Steamhead, Making Wellness a Way of Life, Music Therapy, My Steam, SmartSizing, Spa Package, Steam Genie, Steam on Demand, Steam in a Box, Steam@Home, SteamStart, SteamTherapy, Tala, Tala Bath &...
Page 30 Installation, Operation & Maintenance Manual SteamLinx steam ® Feel Good Inc. PUR100518 5.22...
Page 31 Generator Cover Knock-out in the Generator Circuit Jacket Board Cover Screws...
Page 32 Home Router Power Supply 3’ Cable Ethernet Cable (3’) PUR100518 5.22 PUR 100518 5.22...
Page 33 Installation, Operation & Maintenance Manual S Su e Auto u ® steam ® Feel Good Inc. PUR100200E 5.22...
Page 34 mr . steam ® ® Optional AutoFlush System ____________________________________________________________________________________________________________________________________________ INSTA LLATION INSTRUCTIONS BOX CONTENTS: • AutoFlush System Valve with Cord • Installation Instructions. ® ASSEMBLY OF OPTIONAL AUTOFLUSH SYSTEM 3 Pin Connector for AutoFlush AutoFlush Cord Connector AutoFlush Cord Steam Generator AutoFlush Valve End "B"...
Page 35 AutoFlush Shown Fully Assembled INSTALLATION INSTRUCTIONS ® 1. Plumbing to be performed by a qualified plumber and shall be in accordance with applicable National and Local codes. Unit drains by gravity. A drain line that is lower than the AutoFlush assembly must be available.
Page 36 Installation, Operation & Maintenance Manual MX AutoFlush steam ® Feel Good Inc. PUR100532 5.22...
Page 37 mr . steam ® Optional AutoFlush ® System ____________________________________________________________________________________________________________________________________________ INSTA LLATION INSTRUCTIONS BOX CONTENTS: • AutoFlush System Valve with Cord • Installation Instructions. ® ASSEMBLY OF OPTIONAL AUTOFLUSH SYSTEM 3 Pin Connector for AutoFlush AutoFlush Cord Connector AutoFlush Cord Steam Generator AutoFlush Valve Drain Valve Nipple...
Page 38 AutoFlush Shown Fully Assembled INSTALLATION INSTRUCTIONS ® 1. Plumbing to be performed by a qualified plumber and shall be in accordance with applicable national and local codes. Unit drains by gravity. A drain line that is lower than the AutoFlush assembly must be available.
Page 39 Installation, Operation & Maintenance Manual Condensation Pan steam ® Feel Good Inc. TS0012 5.22...
Page 40 steam ® Technical Specifications Condensation Pan 103867 & 104402 Mr.Steam strongly recommends the use of a condensation pan in the unlikely event of a plumbing leak. Locate the condensation pan on a solid level surface and place the steam generator inside the condensation pan. Insure the steam generator is level.
Page 41 1 800 767 8326 I 1 800 72 STEAM 2017 © MrSteam and des., A Lifetime of Pleasure, AirTempo, AromaFlo, AudioWizard, AutoFlush, Butler Package, ChromaSteam, Clean Steam...Every Time, Club Therapy, Digital 1, Express Steam, Feel Good Inc., From Bathroom to Spa, iButler, iGenie, iSizing, iSteam, Making Wellness a Way of Life, Music Therapy, Spa Package, Steam on Demand, Steam@Home, iTempo, iTempo/Plus, SmartSizing, SteamStart, SteamStop, SteamTherapy, Tala, Bath &...
