- Page 1 General Guidelines for Installing the Mr.Steam Steambath System ®...
- Page 2 ____________________________________________ For additional and important detailed Installation, Operation and Maintenance information, it is strongly recommended that reference be made to the Mr.Steam ® Residential Steambath Generator Manual PN 101289 or contact Mr.Steam at 1-800-76-Steam, ® hello@mrsteam.com or visit www.mrsteam.com ____________________________________________...
- Page 3 Locating the Mr.Steam Generator ® Select a location as near as practical to the steam room. Typical locations include: closet, vanity cabinet, heated attic or basement. 1 .Locate steambath generator within 50 feet of steam room. Note: The standard In-Showwer Control length of the cable for connecting the control to the steam generator is 30 feet.
- Page 4 field wired Steam Outlet * Super 1 is not internally fused Please refer to the wiring diagram in the Mr.Steam Installation Manual for 1" Air Gap Indirect Drain System. complete wiring information. Check local plumbing code for receptor, trap and vent requirements.
-
Page 5: Water Feed
Water Feed 1. Connect hot or cold water line. Hot water line is preferable, however hot water should not exceed 160˚ F. 2. Provide a shut off valve in the water supply line upstream of the steambath generator. 3. Do not overheat inlet solenoid valve with solder connections. - Page 6 Steam Outlet Pipe Steam Outlet ( " NPT) ⁄ 1. Do not install any valve in steam line. Flow of steam must be unobstructed. Steam Generator 2. Use -inch brass pipe or copper tubing ⁄ from unit to steam head as permitted by codes.
- Page 7 Manual Drain Line Drain ( " NPT) ⁄ Steam Generator NOTE: A drain valve is provided to facilitate servicing. Provide a drain line connection from steambath generator drain valve according to National and local Codes. Check local plumbing code for recep- tor, trap and vent requirements.
-
Page 8: Operation
Operation 3 Pin Connector The optional AutoFlush System feature automatically drains the for AutoFlush Mr.Steam system following each use. A time delay allows the water ® to cool down (about two hours) before it drains by gravity for a safe AutoFlush and gentle operation. - Page 9 Drip Pan PN 103867 Typical Steam Generator Unit Drain Pan 3/4" Outlet For Illustrative purposes only. Consult with qualified designer, architect or contractor for steamroom construction details.
-
Page 10: Express Steam
Express Steam (only available factory installed) Suitable for all MS Models. Express steam is equipped with a low power heating element and thermostat to keep the water in the tank warm enough to bring up steam quicker. All express steam compo- nents and wiring are installed at the factory. - Page 11 Parts Power Block Fuses Liquid Level MS SUPER 2E shown Control Board Contactor Transformer Liquid Level Probe Water Feed Solenoid Power Supply Knock-Out Water Inlet Plug and Play Connection Access Cover Safety Valve Steam Outlet AutoFlush Express Steam Valve Heater (optional) (optional) Heating Element Stainless Steel Tank...
- Page 12 Tandem Steam Generator Installation (MS Super 4E, 5E & 6E) Refer to the Mr.Steam Installation manual for additional installation information. • Standard Tandem Cable for Connecting (2) Units PN 103904 • Optional Tandem Cable for Connections up to (5) Units...
- Page 13 ® ® Locate control where it will sense general room temperature and NOT direct steam emission from the steam head. Refer to the Mr.Steam Installation manual for additional control installation information. Typical Steam Generator Installation For Illustrative purposes only. Consult with qualified designer,...
- Page 14 Installing the eTempo or eTempo/Plus Control ® ® 1" hole 1. Firmly connect the connector to the control. 2. Remove & discard peel-off paper to expose 4. Insure the mounting surface is clean and dry Turn on power to the steam generator and test adhesive liner as required for good adhesion.
- Page 15 Connecting the Control Cable to the Steam Generator Route the control cable (provided with the control) from the wall cutout to the steam generator. IMPORTANT: Do not strain, staple, pinch or otherwise damage the con- trol cable. Route cable as required to permit replacement.
- Page 16 Temperature Sensor room temperature and NOT direct steam emission from the steam head. Refer to the Mr.Steam Installation manual for additional control installation information. For Illustrative purposes only. Consult with qualified designer, architect or contractor for steamroom construction details.
- Page 17 • Penetrates walls! Radio Frequency activated. Can be easily connected with any Mr.Steam bath generator ® • Adapts to standard Mr.Steam ® generator. No upgrade required • Easy Plug & Play connection • Can be used inside the shower • Removable lanyard for convenience...
- Page 18 The Acrylic Shield (PN 103938) is for use when acrylic or other non-heat resistant materials are used for the A 1.5" diameter hole in the steamroom is required to mount the steamhead. steamroom enclosure. Refer to the Mr.Steam Installation Manual for additional installation information.
- Page 19 Use essential oils with caution. CAUTION: Place the drops into the Mr.Steam AromaSteam steamhead well prior to turning on the steambath. Do not place drops in a hot steam head as SERIOUS INJURY CAN RESULT IF YOU DO NOT FOLLOW THIS WARNING.
- Page 20 Typical Installation Electronic Oil delivery system evenly infuses aroma into steam for an aro- Steam Line matherapy experience. Complete with Typical Mr.Steam Steam Generator in-shower control, oil container caddy, hoses, fittings and oil atomizer. 90˚ T AromaSteam Essential oils are available in one-liter bottles.
- Page 21 ™ ChromaSteam System LED light suffuses steam environment with multiple colors, from airy blue to sensual red. Ceiling mounted, vapor-sealed, low-voltage LED module for steam/shower enclosure of any size. The ChromaSteam system is com- plete with LED light and color election microprocessor. UL Listed.
- Page 22 Speakers MS-Speakers Silicone RTV Brackets Two 5 ⁄ " diameter flush-mount two-way speakers for steam/shower use, polypropylene cones, ABS frames with grills. Suitable for almost any source of audio input. Rated 60W peak power 8 ohms impedance with 1" tweeter for full range sound.Use only CL2 or CL3 UL listed wires to connect speakers to audio source.
- Page 23 Shower Seat MS-Seat Teak wood, seat drops for use, folds for storage ⁄ ⁄ ⁄ Dimensions: 19 "W x 13 "D x 1 " Max 250 lbs. rated Polished Chrome brackets Wall Brackets Note correct orientation as shown #12, 3 inch long flat head screw Wall Bracket Cover Hinge Pin Caps...
- Page 24 steam ® Sussman-Automatic Corporation ® hello@mrsteam.com www.mrsteam.com 43-20 34th Street, Long Island City, NY 11101 Tel: 718 937 4500 Fax: 718 472 3256 9410 S. La Cienega Blvd. Inglewood CA 90301 Tel: 310 216 6565 Fax: 310 216 2944 Fan us on Follow us on Facebook Twitter...
