mr. steam Linear Steam Head 104216 Installation Instructions

Linear Steam Head
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Installation Instructions
R E A D M E F I R S T !
As you follow these instructions, you will notice
warning and caution symbols. This information
is important for the proper, safe and trouble free
installation of the Linear Steam Head. These are
types of potential hazards that may occur if in-
stallation instructions are not carefully followed.
! CAUTIONS
• Linear Steam Head model 104216 is suitable for MrSteam
generator models MS90 – MS400, MSSUPER1– MSSUPER3,
MX4 – MX6.
Do not use Linear Steam Head model 104216 for any other
MrSteam steam generator. Do not use the Linear Steam
Head with any steam generator that is not a MrSteam steam
generator. Failure to follow these instructions may result in a
leak within the wall cavity and cause problems associated
with leaks, moisture and property damage from leaks.
• Do not use the Linear Steam Head with any steam generator
that is not a MrSteam steam generator. Do not locate the
steam head in any location where the steam emission zone
is near a seat, bench or any space occupied by any persons.
Failure to follow these instructions may result in a
hazardous condition, scalding or personal injury.
Using model 104216 for any steam generator model larger
than the MX6, or for any non MrSteam brand generators
may result in an improper installation or hazardous
condition.
• Do not use the Linear Steam Head with any NON-MrSteam
equipment or devices, including but not limited to water
softeners, steam generators, etc. Using the Linear Steam
Head with any NON-MrSteam equipment or devices may
result in personal injury or, Linear Steam Head damage or
property damage.
• MrSteam steam generators Models MX4, MX5 and MX6
require two 104216 steam heads. Failure to use two steam
heads may result in steam head operation where incidental
contact by the bather with direct steam emission may occur.
Do not locate the steam head in any location where the
steam emission zone is near a seat, bench or any space
occupied by any persons. Failure to follow these
instructions may result in a hazardous condition, scalding or
personal injury.
mr . steam
® Sussman-Automatic Corp®
43-20 34th Street, Long Island City, NY 11101 tel: 1 800 76 STEAM
9410 S. La Cienega Blvd. Inglewood CA 90301 tel: 1 800 72 STEAM
®
! CAUTION
damage may occur if you do not follow instructions.
IMPORTANT NOTE: This highlights information that is espe-
cially relevant to a problem-free installation.
All information in these instructions is based on the latest informa-
tion available at the time of publication. Sussman-Automatic Corpo-
ration reserves the right to make changes at any time without notice.
• Because the steam head and direct steam emission
are very hot, locate the steam head where incidental
contact by the user with the steam head or direct
steam emission cannot occur.
• Model 104216 Linear Steam Heads are for residential
use only. Do not use Model 104216 Linear Steam
Heads for commercial installations, Day Spa, or with
commercial steam generators. Using Model 104216
Linear Steam Heads for commercial, Day Spa or
installations with commercial steam generators or any
installation with steam sessions exceeding 60 minutes
a day, may result in Linear Steam Head damage,
property damage or personal injury.
• Do not use any Linear Steam Head in any commercial
installation or with any commercial steam generator.
Using any Linear Steam Head in a commercial
installation or with any commercial steam generator
may result in Linear Steam Head damage, property
damage or personal injury.
• Install in a horizontal orientation only. Installation in a
non-horizontal orientation may concentrate the steam
and result in excessive temperatures. Failure to install
in a horizontal orientation may result in steam head
operation where incidental contact by the bather with
direct steam emission may occur. Failure to follow
these instructions may result in a hazardous condition,
scalding or personal injury.
• Insulate the steam head and piping as required to
reduce temperatures within the wall cavity. Do not
locate the steam head or plumbing near any materials,
including wiring, devices, or products that may be
adversely affected by elevated temperatures. Failure
to follow these instructions may result in the failure of
materials, including wiring, devices, or products.
hello@mrste m.com www.mrste m.com
mr
This signals a situation where injury or property
steam
.
®
Model 104216
(continued on next page
1
