Sharp HT-DV40H Service Manual page 91

Symbol Pin #
HOMESW/GPIO 63
LDSW/GPIO 64
Input/Output
Input/Output
Servo HOMESW
Priority selection
gpio_first[0][6] = 1
sft_cfg13[8:4] = 5'b00010
sft_cfg2[3:2] = 2
sft_cfg13[11:9] = 3'b001
sft_cfg13[11:9] = 3'b010
sft_cfg13[14:12] = 3'b011
sft_cfg13[14:12] = 3'b101
sft_cfg13[14:12] = 3'b110
sft_cfg1[8:6] = 3'b010
sft_cfg7[7:6] = 3
sft_cfg8[1] = 1'b1
sft_cfg7[11:8] = 4'b1101
sfg_cfg15[5:3] = 3'b011
sfg_cfg16[15:12] = 4'b1001
sfg_cfg17[3:0] = 4'b1000
sfg_cfg17[11:8] = 4'b0101
sfg_cfg17[11:8] = 4'b0110
sft_cfg18[5:4] = 3
sft_cfg9[14:13] = 1
(other)
Input/Output
Servo LDSW
Priority selection
gpio_first[0][7] = 1
sft_cfg13[3:0] = 4'b0100
sft_cfg13[8:4] = 5'b00011
sft_cfg2[3:2] = 2
sft_cfg13[11:9] = 3'b001
sft_cfg13[11:9] = 3'b010
sft_cfg13[14:12] = 3'b011
sft_cfg13[14:12] = 3'b101
sft_cfg13[14:12] = 3'b110
sft_cfg7[7:6] = 3
sft_cfg8[2] = 1'b1
sft_cfg7[11:8] = 4'b1110
sfg_cfg16[11:8] = 4'b0011
sfg_cfg17[3:0] = 4'b1000
sfg_cfg17[3:0] = 4'b1001
sfg_cfg18[3:0] = 4'b0101
sfg_cfg18[3:0] = 4'b0110
sft_cfg7[15:14] = 3
sft_cfg18[7:6] = 3
sft_cfg9[14:13] = 2
(other)
8 – 6
Description
Function
GPIO[6]
ADC_DATA
UA0_RXD
AT_CS_B[1]
AT_ADR[0]
AT_D[4]
AT_D[4]
AT_D[4]
FL_MEM_CSALL_B
FL_PCMCIA_IOW_B
DSP_FL0
VGA_CLK
FM_GPIOB[4]
FM_GPIOB[16]
FM_GPIOB[18]
FM_GPIOB[24]
FM_GPIOB[24]
CLK48_OUT
EXT_CLK48
GPIO[6] (default)
Function
GPIO[7]
IEC_RX
ADC_DATA
UA0_TXD
AT_CS_B[0]
AT_CS_B[1]
AT_D[11]
AT_D[11]
AT_D[11]
FL_PCMCIA_IOR_B
DSP_FL1
VGA_CLK
FM_GPIOB[11]
FM_GPIOB[19]
FM_GPIOB[17]
FM_GPIOB[31]
FM_GPIOB[31]
CLK27_OUT
CLK108_OUT
EXT_CLK48
GPIO[7] (default)
HT-DV40H
Dir
Input/Output
Input
Input
Output
Output
Input/Output
Input/Output
Input/Output
Output
Output
Output
Input
Input/Output
Input/Output
Input/Output
Input/Output
Input/Output
Output
Input
Input/Output
Dir
Input/Output
Input
Input
Output
Output
Output
Input/Output
Input/Output
Input/Output
Output
Output
Input
Input/Output
Input/Output
Input/Output
Input/Output
Input/Output
Output
Output
Input
Input/Output
