HT-DV40H
NO. PARTS CODE
[9] RESISTORS
RR734 VRS-CY1JB332J
RR735 VRS-CY1JB332J
RR736 VRS-CY1JB332J
RR737 VRS-CY1JB332J
RR743 VRS-CY1JB472J
RR752 VRS-CY1JB103J
RR774 VRS-CY1JB103J
RR780 VRS-CY1JB332J
RU703 VRS-CY1JB103J
RU729 VRS-CY1JB103J
RU753 VRS-CY1JB103J
RU754 VRS-CY1JB103J
RU755 VRS-CY1JB103J
RU756 VRS-CY1JB103J
RU757 VRS-CY1JB103J
RU781 VRS-CY1JB103J
RU785 VRS-CY1JB103J
[10] OTHER CIRCUITRY PARTS
Bi5 QCNWNA873AWPZ
Bi8 QCNWNA876AWPZ
Bi9 QCNWNA877AWPZ
Bi12 QCNWNA878AWPZ
Bi402 QCNWNA694AWPZ
Bi403 QCNWN2393AWZZ
Bi502 QCNWNA691AWPZ
Bi706 QCNWNA351AWPZ
BI901 QCNWNA874AWPZ
BI902 QCNWNA872AWPZ
CNM1 92LCONE3P53253
CNM5 92LCONE8P53253
CNP1 QCNCW804ZAFZZ
CNP2 QCNCM704FAFZZ
CNP3 QCNCWYH07AWZZ
CNP4 QCNCWZY25AWZZ
CNP5 92LCONE6P5268
CNP6 QCNCM704DAFZZ
CNP7 QSOCZA072WJZZ
CNP8 QCNCM890HAFZZ
CNP9 92LCONEDP53254
CNP12 QCNCM890GAFZZ
CNP13A 92LCONE6P53254
CNP13B 92LCONE6P53253
CNP201 92LCONE4P53254
CNP301 QCNCWZX15AWZZ
CNP701A QCNCWZX15AWZZ
CNP701B QCNCWZX15AWZZ
CNP702 QCNCW010EAWZZ
CNP801 92LCONE7P5267X
CNP901 92LCONEBP53253
CNP902 QCNCM035FAWZZ
CNP903 92LCONE3P53253
! CNP904 QCNCM049BAWZZ
CNS2 QCNWNA923AWPZ
CNS4 QCNCWZX25AWZZ
CNS13 QCNWNA869AWPZ
QCNWNA425AWPZ
CNS201
! F900 QFS-C402AAWNL
FFC1 QCNWNA879AWPZ
FFC4 QCNWNA871AWPZ
FFC301 QCNWNA779AWPZ
FFC701 QCNWNA875AWPZ
! FH900 92LFSHOLD1652T
! FH901 92LFSHOLD1652T
FL501 VVKNV12MM61-1
FW905 QCNWNA870AWPZ
JK201 QSOCJA025AWZZ
JK202 QSOCJ0120AWZZ
JK203 QSOCZ2102REZZ
JK404 QTANAA010AWZZ
JK690 QSOCJA021AWZZ
JK702 QSOCZA008AWZZ
JK900 QJAKM0004AWZZ
LUG601 QLUGP0001AWZZ
LUG602 QLUGP0001AWZZ
LUG603 QLUGP0001AWZZ
LUG604 QLUGP0001AWZZ
! LUG900 QLUGP0001AWZZ
LUG901 QLUGP0001AWZZ
LUGK1 QLUGP0001AWZZ
LUGA1 QLUGP0001AWZZ
! PC901 RH-FXA003WJZZ
PSH1 PSHEMA020AWZZ
PSH2 PSHEMA021AWZZ
! RL900 RRLYDA002AWZZ
RX501 VHLK2013TH2E1
RXM1 VHPGP1F31RK-1
RXM2 VHPGP1F31RK-1
PRICE NEW PART
RANK MARK RANK
3.3 kohms,1/16W
AA
3.3 kohms,1/16W
AA
3.3 kohms,1/16W
AA
3.3 kohms,1/16W
AA
4.7 kohms,1/16W
AA
10 kohms,1/16W
AA
10 kohms,1/16W
AA
3.3 kohms,1/16W
AA
10 kohms,1/16W
AA
10 kohms,1/16W
AA
10 kohms,1/16W
AA
AA 10 kohms,1/16W
10 kohms,1/16W
AA
10 kohms,1/16W
AA
10 kohms,1/16W
AA
10 kohms,1/16W
AA
10 kohms,1/16W
AA
Connector Ass'y,6 / 7 Pin with CNS5
AL
AL Connector Ass'y,8 / 9 Pin with CNS8
Connector Ass'y,13 / 14 Pin with CNS9
AM
Connector Ass'y,4 / 5Pin with CNS12
AM
Connector Ass'y,7 Pin with CNS402
AK
Connector Ass'y,7 Pin with CNS403
AG
Connector Ass'y,3 Pin with CNS502
AE
Connector Ass'y,4 Pin with CNS706
AK
Connector Ass'y,11 / 12 Pin with CNS901
AL
Connector Ass'y,6 / 7 Pin with CNS902
AK
Connector,3 Pin
AB
Connector,8 Pin
AC
Connector,24 Pin
AF
AB Connector,6 Pin
Connector,7 Pin
AC
Connector,25 Pin
AD
Connector,6 Pin
AC
Connector,4 Pin
AB
AH Connector,23 Pin
Connector,8 Pin
AE
Connector,13 Pin
AD
Connector,7 Pin
AE
Connector,6 Pin
AC
Connector,6 Pin
AC
Connector,4 Pin
AC
Connector,15 Pin
AD
Connector,15 Pin
AD
Connector,15 Pin
AD
Connector,5 Pin
AD
Connector,7 Pin
AC
AC Connector,11 Pin
Connector,6 Pin
AC
Connector,3 Pin
AB
Connector,2 Pin
AC
Connector Ass'y,6 Pin with CNS2A
AH
AD Connector,25 Pin
Connector Ass'y,6 Pin with CNS13A / CNS13B
AL
AE Connector Ass'y,4 Pin
Fuse T4A H,250V
AD
Flat Cable,24 Pin
AG
Flat Cable,23 Pin
AF
Flat Cable,15 Pin
AD
AE Flat Cable,15 Pin
Fuse Holder
AB
Fuse Holder
AB

FL Display

AT
Flat Wire, 5 Pin
AE
AK Component Out
Video Out Jack
AD
Scart Out Audio / Video
AK
Subwoofer Speaker Terminal
AE
Aux In
AD
USB Jack
AF
Headphone Jack
AK
Lug Terminal
AC
Lug Terminal
AC
Lug Terminal
AC
Lug Terminal
AC
Lug Terminal
AC
Lug Terminal
AC
Lug Terminal
AC
Lug Terminal
AC
Photo Coupler
AE
Copper Sheet
AF
Copper Sheet
AE
Relay
AF
AG Remote Sensor
Digital In
AL
Digital In
AL
17
DESCRIPTION
