- Page 1 SX2M-A-TT-B-DS SX2M-A-TT-B-DS SX2M-B-TT-S-DS SX2M-B-TT-B-DS Level 2Plus Ground Support Equipment (US) ltd., DBA Biomorph, 11 Broadway, New York, NY 10004. Tel and Fax 888 302 3375 info@biomorphdesk.com www.biomorph.com...
- Page 2 “Questions? Please call 917.328.8955 for support. IMPORTANT: Any issues at site must be reported to Biomorph immediately at 917 .328.8955, by text or phone and wait on site for response. Also, photos of completed desk(s) must be sent to 917 .328.8955 or vendors@biomorphdesk.com and wait ON SITE for approval. This will avoid potential revisits. Thank you.
-
Page 3: Assembly Overview
Assembly Overview Assembly Overview IMPORTANT: DO NOT BUILD THIS TABLE UPSIDE DOWN. FRAME MUST BE BUILT RIGHT SIDE UP , IN PLACE, AND TOPS THEN ATTACHED. If this procedure is not followed then tops will not line up with frame. DO NOT REMOVE PROTECTIVE MATERIAL FROM TOPS UNTIL FINAL ASSEMBLY. - Page 4 Leg Assembly Level 2Plus M6 x 12 Screw Qty. 4 M6 x 12 Screw Qty. 8 Note: Longer end of Foot must face toward front (user) side. Glide Qty. 4...
- Page 5 Crossbar Assembly Level 2Plus M6 x 12 Screw Qty. 4 LH Side RH Side Use these holes. Use these holes.
- Page 6 54” LH Side 54” RH Side Use these holes. Use these holes. 60” LH Side 60” RH Side Use these holes. Use these holes. M6 Flange Head Nut Qty. 4 M6 x 12 Screw Qty. 4...
- Page 7 Crossbar Assembly (continued) Level 2Plus 72” LH Side 72” RH Side Use these holes. Use these holes. 84” LH Side 84” RH Side Use these holes. Use these holes. M6 Flange Head Nut Qty. 4 M6 x 12 Screw Qty. 4...
- Page 8 Top Assembly Level 2Plus Note: Pro Plus assembly shown below. Personal plus assembles in the same manner. 5 x 25mm Wood Screw Qty. 10...
- Page 9 Cable Management & Electrical Level 2Plus Note: Pro Plus assembly shown below. Personal plus assembles in the same manner. 45˚ Digital Readout 16mm PH Switch and 45˚ Wood Screw Switch Bracket Qty. 2 Qty 1 Cable Cab 45mm PH 16mm PH...
- Page 10 Cable Diagram Level 2Plus IMPORTANT: All cables must be tacked up and made neat with supplied cable guides. NO cables may hang down ex- cept those passing through cable chains. Make sure cables have enough slack between surfaces to allow full height adjustment between surfaces.
- Page 11 Cable Diagram Level 2Plus Corner IMPORTANT: All cables must be tacked up and made neat with supplied cable guides. NO cables may hang down ex- cept those passing through cable chains. Make sure cables have enough slack between surfaces to allow full height adjustment between surfaces.
- Page 12 Questions? Call 888 302 3375 Operating your Biomorph Desk Level Series, Flexo Series, and Pro SuperPlus and Level 3Plus-95 desks with 5 legs. DPF1C control switch for MEMORY 1 MEMORY 3 DOWN MEMORY 2 DIGITAL DISPLAY STORE MEMORY NOTE: DPF1C may or may not have digital display To Raise or Lower Height in Regular Use.
-
Page 13: Troubleshooting Guide
Questions? Call 888 302 3375 Troubleshooting Guide DPF1C control switch for Biomorph Level, Flexo, and DPF4T control switch for Plus Series Desks . For dual surface Plus Series desks, you must reset both Check for obstructions above, below and around the desk that front and rear surfaces, by starting with the front then using may impede movement through the desk’s full adjustment...
