- Page 1 Installation Instructions for Frontload Washers Original Instructions Keep These Instructions for Future Reference. CAUTION: Read the instructions before using the machine. (If this machine changes ownership, this manual must accompany machine.) Part No. 806989ENR1 www.speedqueen.com March 2019...
-
Page 3: Table Of Contents
Installer Checklist.................12 © Copyright 2019, Alliance Laundry Systems LLC All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. -
Page 4: Washer Dimensions
27.73 in. [704 mm] K (with door closed) 1.59 in. [40 mm] 13.1 in. [333 mm] * For ADA compliance turn legs out from base 0.5 inches. © Copyright, Alliance Laundry Systems LLC - Part No. 806989ENR1 DO NOT COPY or TRANSMIT... -
Page 5: Installation
NOTE: Some moisture in the wash drum is normal. Wa- ter is used during testing at the manufacturer. NOTE: This appliance is suitable for use in countries having a warm, damp climate. © Copyright, Alliance Laundry Systems LLC - Part No. 806989ENR1 DO NOT COPY or TRANSMIT... -
Page 6: Remove Shipping Materials
Work each bolt and spacer out by hand using a circular motion. NOTE: Avoid backing bolts out completely or spacers might fall into cabinet. © Copyright, Alliance Laundry Systems LLC - Part No. 806989ENR1 DO NOT COPY or TRANSMIT... -
Page 7: Connect Fill Hoses
“C”. W029 5. Thread hose couplings onto valve connections finger tight. Then turn 1/4 turn with pliers. © Copyright, Alliance Laundry Systems LLC - Part No. 806989ENR1 DO NOT COPY or TRANSMIT... -
Page 8: Connect Drain Hose To Drain Receptacle
Install the drain hose into the drain receptacle (standpipe, wall or one of the fill hoses using the beaded strap from accessories bag. laundry tub) following the instructions below. Refer to Figure 9 . © Copyright, Alliance Laundry Systems LLC - Part No. 806989ENR1 DO NOT COPY or TRANSMIT... -
Page 9: Laundry Tub Installation
7. Remove rubber feet from accessories bag and place on all 2. Beaded Strap (tape if necessary) four leveling legs. 8. Verify that unit doesn’t rock. Figure 10 © Copyright, Alliance Laundry Systems LLC - Part No. 806989ENR1 DO NOT COPY or TRANSMIT... -
Page 10: Wipe Out Inside Of Wash Drum
FLW2466N_SVG receptacle rated 110/120 Volts AC (alternating current) 15 Amps. Figure 12 Refer to Figure 13 to determine correct polarity of the wall recep- tacle. © Copyright, Alliance Laundry Systems LLC - Part No. 806989ENR1 DO NOT COPY or TRANSMIT... -
Page 11: Earth/Ground Instructions
The appliance is equipped with a cord having an equipment earth/ ground conductor and a three-prong earth/ground plug. The plug must be plugged into an appropriate outlet that is properly instal- © Copyright, Alliance Laundry Systems LLC - Part No. 806989ENR1 DO NOT COPY or TRANSMIT... -
Page 12: Installer Checklist
Plug In the Washer. COLD CHECK CHECK FLW2304N_SVG TLW2289N_SVG Connect Drain Hose to Drain Receptacle. CHECK FLW2463N_SVG1 Refer to the manual for more detailed information © Copyright, Alliance Laundry Systems LLC - Part No. 806989ENR1 DO NOT COPY or TRANSMIT...
