- Page 1 AOC-ATGC-i2TM User's Guide Revision 1.0...
- Page 2 Santa Clara County in the State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
- Page 3 Based on the Intel X710-AT2 network controller with performance- ® enhancing features and power management technologies, the AOC-ATGC-i2TM provides a quality networking choice for data centers while reducing CPU utilization and power consumption. With the added NC-SI feature, this adapter also can func- tion as a secure networking port for remote server management.
- Page 4 Super AOC-ATGC-i2TM Add-on Card User's Guide Conventions Used in the User's Guide Pay special attention to the following symbols for proper system installation and to prevent damage to the system or injury to yourself: Warning: Important information given to ensure proper system installation or to prevent damage to the components or injury to yourself.
- Page 5 Super AOC-ATGC-i2TM Add-on Card User's Guide Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.
-
Page 6: Table Of Contents
Jumpers and Connectors ................2-5 Chapter 3 Installation Static-Sensitive Devices .................. 3-1 Before Installation ................... 3-2 Installing the Add-on Card AOC-ATGC-i2TM (with 0.5U bracket) ....3-3 Installing Drivers on Windows ................. 3-6 Installing Drivers on Linux ................3-7 Installing Drivers on FreeBSD ................ 3-8... -
Page 7: Chapter 1 Overview
Overview Congratulations on purchasing your add-on card from an acknowledged leader in the industry. Supermicro products are designed with the utmost attention to detail to provide you with the highest standards in quality and performance. For product support and updates, please refer to our website at http://www.supermicro.com/... -
Page 8: 1-3 Specifications
Super AOC-ATGC-i2TM Add-on Card User's Guide 1-3 Specifications General • Advanced I/O Module (AIOM) Form Factor • Intel X710-AT2 controller ® • 2x RJ45 connectors with speed up to 10Gbps per port • PCIe Gen3 X8 Networking Features • IEEE 802.3ad, 802.1AX Link Aggregation •... - Page 9 Chapter 1: Overview • GENEVE Management Features • Asset Management support with thermal sensor • NC-SI for remote management • Preboot eXecution Environment (PXE) • iSCSI remote boot • PLDM Power Savings • ACPI compliant power management • Energy Efficient Ethernet (IEEE 802.3az) OS Support •...
- Page 10 Super AOC-ATGC-i2TM Add-on Card User's Guide Operating Conditions • Storage temperature: -40°C to 70°C (-40°F to 158°F) • Storage humidity: 90% non-condensing relative humidity at 35°C Physical Dimensions • PCB dimensions: 76mm x 115mm (W x D) Available SKUs SKUs...
-
Page 11: Chapter 2 Hardware Components
Chapter 2: Hardware Components Chapter 2 Hardware Components Add-On Card Image and Layout AOC-ATGC-i2TM Image... - Page 12 Super AOC-ATGC-i2TM Add-on Card User's Guide LAN2 LAN1 JPAUX1 JDB1 AOC-ATGC-i2TM DESIGNED IN USA REV:1.00 AOC-ATGC-i2TM Layout...
-
Page 13: Major Components
Chapter 2: Hardware Components Major Components AOC-ATGC-i2TM Major Components Component Name Definition Intel X710-AT2 Ethernet LAN Controller ® JPAUX1 1-2: Enable AUX Power in S5 (Default) 2-3: Disable AUX Power in S5 JDB1 Debug Header LAN1 RJ45 Port 1 LAN2... -
Page 14: Lan Ports And Lan Led Indicators
Super AOC-ATGC-i2TM Add-on Card User's Guide LAN Ports and LAN LED Indicators LAN Ports There are two LAN ports on the AOC-ATGC-i2TM. These LAN ports support con- nection speeds of 10Gbps. Use a direct-attach RJ45 type LAN cable. AOC-ATGC-i2TM Image Each LAN has one bi-colored LED per port (RJ45) at the bottom of PCB. -
Page 15: Jumpers And Connectors
Enable = Enable jumper to WoL is supported but limited to plat- Standby power connect standby forms with sufficient airflow when it is to AOC NIC power to AOC NIC in standby mode (S5 state). Please consult Supermicro before enabling it. -
Page 16: Chapter 3 Installation
Chapter 3: Installation Chapter 3 Installation Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid dam- aging your add-on card, it is important to handle it very carefully. The following measures are generally sufficient to protect your equipment from ESD. Precautions •... -
Page 17: Before Installation
Super AOC-ATGC-i2TM Add-on Card User's Guide Before Installation Before you install the add-on card, follow the instructions below. 1. Power down the system. 2. Unplug the power cord. 3. Use industry-standard anti-static equipment such as gloves or a wrist strap and follow the precautions on page 3-1 to avoid damage caused by ESD. -
Page 18: Installing The Add-On Card Aoc-Atgc-I2Tm (With 0.5U Bracket)
Chapter 3: Installation Installing the Add-on Card AOC-ATGC-i2TM (with 0.5U bracket) Follow the steps below to install an add-on card into your system. (If the system is fixed onto a rack, the removal of server top cover is not required. If the system... - Page 19 Super AOC-ATGC-i2TM Add-on Card User's Guide B. Installing an AIOM module 1. Position the AIOM module in front of the empty slot and gently push onto the metal bracket. The AIOM module should slide into the chassis until the card is securely seated in the connector.
- Page 20 Chapter 3: Installation C. Installing an AIOM module (An AIOM slot with an AIOM slot cover) 1. Remove the AIOM slot cover by unscrewing the knob and screw that attaches the bracket to the chassis. Pull the bracket away and set it aside. 2.
-
Page 21: Installing Drivers On Windows
Follow the steps below to install the drivers for Windows. Download the drivers from the Supermicro FTP site at ftp://ftp.supermicro.com/Networking_Drivers/. 1. Run CDR-NIC. 2. When the SUPERMICRO window appears, click on the computer icon next to the product model. 3. Click on INSTALL DRIVERS AND SOFTWARE. -
Page 22: Installing Drivers On Linux
Chapter 3: Installation Installing Drivers on Linux Follow the steps below to install the drivers for Linux. 1. Download the driver from the Supermicro CDR-NIC LAN driver CD or ftp://ftp. supermicro.com/Networking_Drivers/CDR-NIC_1.62_for_Add-on_NIC_Cards/ Intel/LAN/PRO40GB/LINUX. Due to the continuous development of the Linux kernel, the drivers are updated more often than the bundled releases. -
Page 23: Installing Drivers On Freebsd
<x.x.x> is the driver version as indicated in the name of the driver tar file. Note: You must have kernel sources installed in order to compile the driver module. Download the driver from the Supermicro CDR-NIC LAN driver CD or ftp:// ftp.supermicro.com/Networking_Drivers/CDR-NIC_1.62_for_Add-on_NIC_ Cards/Intel/LAN/PRO40GB/FreeBSD. - Page 24 Chapter 3: Installation 8. If you want the driver to load automatically when the system is booted: cd ixl-x.x.x/src make make install 9. Edit /boot/loader.conf, and add the following line: ixl_load="YES" compile the driver into the kernel (see item 10) Edit /etc/rc.conf, and create the appropriate ifconfig_ixl<interface_num>...
- Page 25 Super AOC-ATGC-i2TM Add-on Card User's Guide Notes 3-10...
- Page 26 (Disclaimer Continued) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.
