Summary of Contents for Supermicro SuperServer SYS-111AD-HN2

  • Page 1 SuperServer ® SYS-111AD-HN2 USER’S MANUAL Revision 1.0a...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...

  • Page 4: Table Of Contents

    Preface Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 System Features ........................9 Front View ...........................9 Control Panel .........................10 Rear View ..........................11 1.3 System Architecture ......................12 Main Components ......................12 System Block Diagram ......................13 1.4 Motherboard Layout ......................14 Quick Reference Table ......................15 Chapter 2 Server Installation 2.1 Overview ..........................17 2.2 Unpacking the System .......................17...
  • Page 5 Preface Installing the CPU Heatsink ..................27 3.5 Memory ..........................29 Memory Support ........................29 Memory Installation Sequence ..................29 General Memory Population Requirements ..............29 General Guidelines for Optimizing Memory Performance ..........30 DIMM Installation ......................31 DIMM Removal .........................31 3.6 Motherboard Battery ......................32 3.7 Storage Drives ........................33 Installing Drives .........................33 Installing M.2 Solid State Drives ..................34 3.8 System Cooling ........................35...
  • Page 6 7.8 Where to Get Replacement Components ................81 7.9 Reporting an Issue ......................81 Technical Support Procedures ..................81 Returning Merchandise for Service ...................81 Vendor Support Filing System ..................82 7.10 Feedback ...........................82 Contacting Supermicro ......................83 Appendix A Standardized Warning Statements for AC Systems Appendix B System Specifications BSMI/RoHS ........................106...
  • Page 7 San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 8: Chapter 1 Introduction

    1U Rackmount 1.7 x 17.2 x 11.3in. / 43 x 437 x 287mm (HxWxD) Notes: A Quick Reference Guide can be found on the product page of the Supermicro website. The following safety models associated with the SYS-111AD-HN2 have been certified as...

  • Page 9: System Features

    Chapter 1: Introduction 1.2 System Features The following views of the system display the main features. Refer to Appendix B for additional specifications. Front View Control Panel System Fans Figure 1-1. Front View System Features: Front Feature Description Control Panel One control panel (see Control Panel for details)

  • Page 10: Control Panel

    Chapter 1: Introduction Control Panel Information LED Power Power LED NIC LED NIC LED Reset Figure 1-2. Control Panel Control Panel Features Feature Description Information LED Alerts operator to several states, as noted in the table below. NIC (LAN1) LED Indicates network activity on LANs when flashing.

  • Page 11: Rear View

    Chapter 1: Introduction Rear View Display Ports IPMI LAN Port VGA Port HDMI Port USB Ports DVI Port Power Supply Two Audio Connectors PCIe 5.0 x16 slot 2.5GbE LAN Ports Figure 1-3. System: Rear View System Features: Rear Feature Description Power Supply One power supply module Four USB 3.2 ports...

  • Page 12: System Architecture

    Chapter 1: Introduction 1.3 System Architecture This section covers the locations of the system's main components. Main Components DIMM Slots Processor Backplane System Fans System Fan PCIe 5.0 x16 slot (HHHL) Power Supply Figure 1-4. Main Component Locations System Features: Top Feature Description Power Supply...

  • Page 13: System Block Diagram

    Chapter 1: Introduction System Block Diagram The block diagram below shows the connections and relationships between the subsystems and major components of the overall system. SVID PCIe5.0_x16/PCIe5.0_x8x8 PCIe x16 SLOT IMVP9.1 32.0GT/s PCIe4.0_x4 Digital port 1 M.2 M KEY SN65DP159 DDI B HDMI 2.0b 16.0GT/s...

  • Page 14: Motherboard Layout

    Chapter 1: Introduction 1.4 Motherboard Layout Below is a layout of the X13SAZ-F motherboard with the jumper, connector, and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information, and jumper settings, refer to Chapter 4 or the Motherboard Manual.

  • Page 15: Quick Reference Table

    Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting (*) JBT1 CMOS Clear Open (Normal) Pins 1-2: SATA (Customized BIOS Needed) JNS1 NVMe/SATA Mode Select Pins 2-3: NVMe (Default) JPAC1 Audio Enable Pins 1-2 (Enabled) JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPL1 LAN1 Enable/Disable Pins 1-2 (Enabled)
  • Page 16 Chapter 1: Introduction Connector Description JMD1 M.2 M-Key PCIe 4.0 x4 Slot (2280/22110 form factor) JPH1 4-pin HDD Power Connector JPI2C1 Power System Management Bus (SMB) I C Header 8-pin 12V DC Power Connector for CPU (Required) or alternative single power for special JPV1 enclosure when the 24-pin ATX power is not in use JPW1...

  • Page 17: Chapter 2 Server Installation

    Chapter 2: Server Installation Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory, etc., refer to Chapter 3 for details on installing those specific components.

  • Page 18: Rack Precautions

    Chapter 2: Server Installation • This product is not suitable for use with visual display workplace devices according to §2 of the German Ordinance for Work with Visual Display Units. Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are extended to the floor so that the full weight of the rack rests on them.

  • Page 19: Airflow

    Chapter 2: Server Installation Airflow Equipment should be mounted into a rack so that the amount of airflow required for safe operation is not compromised. Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading.

  • Page 20: Installing The System Into A Rack

    Chapter 2: Server Installation 2.4 Installing the System into a Rack The following is a basic guideline for installing the system into a rack with the rack mounting hardware provided. You should also refer to the installation instructions that came with the specific rack you are using.

  • Page 21: Chapter 3 Maintenance And Component Installation

    Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components requires that power first be removed from the system.

  • Page 22: Accessing The System

    Chapter 3: Maintenance and Component Installation 3.2 Accessing the System The CSE-510FT-203B chassis features a removable top cover, which allows easy access to the inside of the chassis. Removing the Top Cover 1. Press the release button and slide the cover toward the rear. 2.

  • Page 23: Static-Sensitive Devices

    Chapter 3: Maintenance and Component Installation 3.3 Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid damaging your motherboard, it is important to handle it very carefully. The following measures are generally sufficient to protect the system PCBs from ESD. Precautions •...

  • Page 24: Processor And Heatsink Installation

    CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. • Refer to the Supermicro website for updates on CPU support. Installing the Processor(s) Begin by removing power from the system as described in Section 3.1.

  • Page 25: Installing The Lga1700 Processor

    Chapter 3: Maintenance and Component Installation Installing the LGA1700 Processor 1. Press the load lever down to release the load plate from its locking position. Plastic Protective Cover Load Plate Load Lever 2. Gently lift the load lever to open the load plate. Remove the plastic protective cover. Do not touch the CPU socket contacts.
  • Page 26 Chapter 3: Maintenance and Component Installation 1. Carefully lower the CPU straight down into the socket. Do not drop the CPU on the socket, or move it horizontally or vertically to avoid damaging the CPU or socket. Inspect the four corners of the CPU to make sure that the CPU is properly installed. 1.

  • Page 27: Installing The Cpu Heatsink

    Chapter 3: Maintenance and Component Installation Installing the CPU Heatsink Notes: • If you bought a CPU separately, use an Intel-certified multi-directional heatsink only. • Do not apply any thermal grease to the heatsink or the CPU die; the required amount has already been applied.
  • Page 28 Chapter 3: Maintenance and Component Installation Removing a Heatsink We do not recommend removing the heatsink. If necessary, please follow the instructions below to prevent damage to the CPU or the CPU socket. 1. Unscrew and remove the heatsink screws from the motherboard in the sequence as show in the figure below.

  • Page 29: Memory

    UDIMM, ECC DDR5 UDIMM with speeds up to 4000MT/s. For validated memory, use our Product Resources page. Check the Supermicro website for possible updates to memory support. Memory Installation Sequence Memory for this motherboard is populated using the "Fill First" method. The DIMM slots with blue release tabs are considered the first DIMM of their channel, and those with white release tabs are the second of the channel.

  • Page 30: General Guidelines For Optimizing Memory Performance

    Chapter 3: Maintenance and Component Installation General Guidelines for Optimizing Memory Performance • The blue slots must be populated first. DIMM slots must be populated in the following order: DIMMB2, DIMMA2, then DIMMB1, DIMMA1. • Always use DDR5 memory of the same type, and size. •...

  • Page 31: Dimm Installation

    Chapter 3: Maintenance and Component Installation DIMM Installation UID SW UID LED 1. Insert DIMM modules in the following LED3 HDMI/DP1 USB4/5 (3.2) order: DIMMA2, DIMMB2 and then AUDIO FP DVI-D/VGA BMC_LAN LAN1/LAN2 USB6/7 (3.2(10Gb)) LEDBMC DIMMA1, DIMMB1. SRW2 SRW2 JPL1 JPL2 MAC CODE 22110...

  • Page 32: Motherboard Battery

    Chapter 3: Maintenance and Component Installation 3.6 Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system.

  • Page 33: Storage Drives

    Chapter 3: Maintenance and Component Installation 3.7 Storage Drives The storage drives are mounted in tool-less drive carriers that simplify their removal from the chassis. These carriers also help promote proper airflow. For compatible storage drives, see SYS-111AD-HN2 product page. Installing Drives Figure 3-6.

  • Page 34: Installing M.2 Solid State Drives

    Chapter 3: Maintenance and Component Installation Installing M.2 Solid State Drives The X13SAZ-F motherboard has one hybrid PCIe 4.0 and NVMe slot (JMDI). M.2 allows for a variety of card sizes, increased functionality, and spatial efficiency. The M.2 slot on the motherboard supports PCIe 4.0 x1 devices in the 2280 and 22110 form factors.

  • Page 35: System Cooling

    Chapter 3: Maintenance and Component Installation 3.8 System Cooling Fans Four 4-cm heavy-duty fans provide cooling for the system. Fans are hot-swapped and can be replaced without powering down the system. The electrical connections are automatically made when a fan is inserted into its slot. Make sure the chassis cover is only off for a short time and makes a good seal when replaced for the cooling air to circulate properly through the system.
  • Page 36 Chapter 3: Maintenance and Component Installation Figure 3-10. Removing the Fan Housing 1. Disconnect the fan wiring from the connectors and carefully lift the fan housing out of the chassis. 2. To remove the fans from the fan housing, gently push upwards on the fan from the underside of the fan housing.

  • Page 37: Air Shrouds

    Chapter 3: Maintenance and Component Installation Air Shrouds Air shrouds concentrate airflow to maximize fan efficiency. The SYS-111AD-HN2 includes one air shroud for the CPU. Air Shroud for Memory An air shroud cools the DIMM slots controller. 1. Remove the system from the rack and remove the cover as described previously. 2.

  • Page 38: Expansion Cards

    Chapter 3: Maintenance and Component Installation 3.9 Expansion Cards The SYS-111AD-HN2 includes one riser card to support the use of expansion (add-on) cards. PCIe 5.0 x16 slot Figure 3-13. Expansion Card Chassis Slots Riser Cards This system includes a riser card that provides PCIe capabilities. PCIe Slots per Riser Card Location Part Number...

  • Page 39: Installing Expansion Cards

    Chapter 3: Maintenance and Component Installation Before following the procedure below to install expansion cards, first turn off and remove power from the system as described in Section 3.1 then remove the top cover. Installing Expansion Cards 1. Remove any slimline SAS cables connected to the riser card and pull up the riser card brackets.

  • Page 40: Power Supply

    100V - 240V input voltage. If the power supply unit fails, the system will shut down and you will need to replace the unit. Replacement units can be ordered directly from Supermicro. Rear Mounting Screws Power Supply...

  • Page 41: Power Supply Failure

    Chapter 3: Maintenance and Component Installation Power Supply Failure With only one power supply unit in the chassis, power must be completely removed from the server before removing and replacing the power supply unit. Removing the Power Supply If the power is on, removing power from the system as described in Section 3.1. 1.

  • Page 42: Chapter 4 Motherboard Connections

    Chapter 4: Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.
  • Page 43 Chapter 4: Motherboard Connections 4-pin HDD Power Connector JPH1 is a 4-pin power connector that provides power to onboard HDD devices. Refer to the table below for pin definitions. 4-pin HDD Power Pin Definitions Pin# Definition 4-pin GPU Card Power Connector JPWR1 is a 4-pin power connector for a GPU card.

  • Page 44: Headers And Connectors

    Chapter 4: Motherboard Connections 4.2 Headers and Connectors Fan Headers There are six 4-pin fan headers on the motherboard. Although pins 1-3 of the fan headers are backward compatible with the traditional 3-pin fans, we recommend you use 4-pin fans to take advantage of the fan speed control via Pulse Width Modulation through the thermal management.
  • Page 45 Port 80 connection. Use this header to enhance system performance and data security. Refer to the table below for pin definitions. Please go to the following link for more information on the TPM: http://www.supermicro.com/manuals/other/TPM.pdf. Trusted Platform Module Header Pin Definitions...
  • Page 46 Chapter 4: Motherboard Connections Power SMB (I C) Header The Power System Management Bus (I C) connector (JPI C1) monitors the power supply, fan, and system temperatures. Refer to the table below for pin definitions. Power SMB Header Pin Definitions Pin# Definition Clock...
  • Page 47 Chapter 4: Motherboard Connections NVM Express Connector The motherboard supports a PCIe 4.0 x4 NVMe connection. This connector provides high- speed and low-latency connections directly from the CPU to NVMe Solid State (SSD) drives. This greatly increases SSD data-throughput performance and significantly reduces PCIe latency by simplifying driver/software requirements resulting from direct PCIe interface from the CPU to the NVMe SSD drives.
  • Page 48 Chapter 4: Motherboard Connections COM Headers The motherboard has two COM headers (COM1/2 and COM3/4) that provides serial connections, utilizing Supermicro PN: CBL-CDAT-0604 or CBL-CUSB-0984 (not included). COM1/2 support RS-232/422/485 and COM3/4 support RS-232. COM Header (COM1/2, COM3/4) Pin Definitions...

  • Page 49: Input/Output Ports

    Chapter 4: Motherboard Connections 4.3 Input/Output Ports Figure 4-1. I/O Port Locations and Definitions Rear I/O Ports Description Description Description BMC LAN (F SKU) LAN2 HDMI 2.0b USB7 (3.2) LAN1 DisplayPort++2 USB6 (3.2) LINE_OUT USB5 (3.2) DVI-D MIC_IN USB4 (3.2) DisplayPort++1 DVI-D/VGA A DVI-D and a VGA port are located next to LAN ports on the I/O back panel.
  • Page 50 Chapter 4: Motherboard Connections LAN Ports Two Gigabit Ethernet ports (LAN1, LAN2) are located on the I/O back panel. In addition to the LAN ports, the X13SAZ-F has a dedicated BMC LAN on the back panel. All these ports accept RJ45 cables. LAN1/LAN2 BMC LAN Pin Definition...
  • Page 51 Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website at https://www.supermicro.com/ support/manuals/. UID Switch UID LED...

  • Page 52: Front Control Panel

    JF1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis. These connectors are designed specifically for use with Supermicro chassis. See the figure below for the descriptions of the front control panel buttons and LED indicators.
  • Page 53 Chapter 4: Motherboard Connections Overheat (OH)/Fan Fail Connect an LED cable to pins 7 and 8 of the Front Control Panel to use the Overheat/Fan Fail LED connections. The LED on pin 8 provides warnings of overheating or fan failure. Refer to the tables below for pin definitions.
  • Page 54 Chapter 4: Motherboard Connections NMI Button The non-maskable interrupt (NMI) button header is located on pins 19 and 20 of JF1. Refer to the table below for pin definitions. NMI Button Pin Definitions (JF1) Pins Definition Control Ground...

  • Page 55: Jumpers

    Chapter 4: Motherboard Connections 4.5 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identified with a square solder pad on the printed circuit board. See the diagram below for an example of jumping pins 1 and 2.
  • Page 56 Chapter 4: Motherboard Connections Watch Dog Timer Watchdog (JWD1) is a system monitor that can reboot the system when a software application hangs. Close pins 1-2 to reset the system if an application hangs. Close pins 2-3 to generate a non-maskable interrupt (NMI) signal for the application that hangs. Refer to the table below for jumper settings.
  • Page 57 Chapter 4: Motherboard Connections Mini-SAS HDD NVMe/SATA Mode Select Use jumper JNS1 to select the Mini-SAS hard disk drive mode to NVMe or SATA. NVMEe/SATA Mode Select Jumper Settings Jumper Setting Definition Pins 1-2 SATA Pins 2-3 NVMe (Default) ME Manufacturing Mode Close pins 2-3 of jumper JPME2 to bypass SPI flash security and force the system to operate in the manufacturing mode, which allows you to flash the system firmware from a host server for system setting modifications.

  • Page 58: Led Indicators

    Chapter 4: Motherboard Connections 4.6 LED Indicators LAN LEDs Two LAN ports (LAN 1 and LAN 2) are located on the rear I/O panel of the motherboard. Each Ethernet LAN port has two LEDs. The green LED indicates activity, while the other Link LED may be green, amber, or off to indicate the speed of the connection.
  • Page 59 Chapter 4: Motherboard Connections BMC Power and Fan LED LED3 is the BMC Power and Fan LED. When LED3 is solid red, there is a PWR or FAN fail. Refer to the table below for more information. BMC PWR/FAN LED State LED Color Definition Soild Red...

  • Page 60: Chapter 5 Software

    USB/SATA DVD drive, or a USB flash drive, or the IPMI KVM console. 2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 61 Chapter 5: Software 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 5-2.

  • Page 62: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wdl/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to a USB flash drive or a DVD.

  • Page 63: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 64: Bmc

    There are several BIOS settings that are related to BMC. For general documentation and information on BMC, visit our website at: www.supermicro.com/en/solutions/management-software/bmc-resources BMC ADMIN User Password For security, each system is assigned a unique default BMC password for the ADMIN user.

  • Page 65: Chapter 6 Optional Components

    Chapter 6: Optional Components Chapter 6 Optional Components This chapter describes alternate configurations and optional system components. Optional Parts Storage drive options Cable Management Arm TPM security module 6.1 Storage Drive Options The storage drive bays can support SATA, and SAS in any combination. To enable SAS, an additional hardware is required.

  • Page 66: Cable Management Arm

    Chapter 6: Optional Components 6.2 Cable Management Arm The system supports a cable management arm (CMA), which keeps the rear cables organized and clear of the rail mechanisms when the system is extended out the front of the rack for maintenance.
  • Page 67 Chapter 6: Optional Components Figure 6-2. Installing the Connectors 3. Slide CMA connector #3 forward onto the two posts on the rear of the left middle rail. It snaps into place. 4. For CMA connector #4, align the metal tabs with the slots on the rear of the left outer rail and push it forward.

  • Page 68: Tpm Security Module

    The JTPM1 header is used to connect a Trusted Platform Module (TPM). A TPM is a security device that supports encryption and authentication in hard drives. It enables the motherboard to deny access if the TPM associated with the hard drive is not installed in the system. Details and installation procedures are at: http://www.supermicro.com/manuals/other/TPM.pdf. • AOM-TPM-9671V...

  • Page 69: Chapter 7 Troubleshooting And Support

    Chapter 7 Troubleshooting and Support 7.1 Information Resources Website A great deal of information is available on the Supermicro website, supermicro.com. Figure 7-1. Supermicro Website • Specifications for servers and other hardware are available by clicking the menu icon, then selecting the Products option.

  • Page 70: Baseboard Management Controller (Bmc)

    Security Center for recent security notices Supermicro Phone and Addresses 7.2 Baseboard Management Controller (BMC) The system supports the Baseboard Management Controller (BMC). BMC is used to provide remote access, monitoring and management. There are several BIOS settings that are related to BMC.

  • Page 71: Troubleshooting Procedures

    Chapter 7: Troubleshooting and Support UID SW UID LED 7.3 Troubleshooting Procedures LED3 HDMI/DP1 USB4/5 (3.2) AUDIO FP DVI-D/VGA Use the following procedures to troubleshoot your system. If you have followed all of the BMC_LAN LAN1/LAN2 USB6/7 (3.2(10Gb)) LEDBMC procedures below and still need assistance, refer to the Technical Support Procedures SRW2 SRW2...

  • Page 72: No Video

    Chapter 7: Troubleshooting and Support No Video If the power is ON but you have no video, remove all the add-on cards and cables. System Boot Failure If the system does not display POST (Power-On-Self-Test) or does not respond after the power is turned ON, check the following: Turn ON the system with only one DIMM module installed.
  • Page 73 Chapter 7: Troubleshooting and Support Note: Refer to the product page on our website at http://www.supermicro.com for memory and CPU support and updates. 3. HDD support: Make sure that all hard disk drives (HDDs) work properly. Replace the bad HDDs with good ones.

  • Page 74: Post Codes

    7.4 POST Codes The AMI UEFI BIOS supplies checkpoint codes, which are documented online at http://www. supermicro.com/support/manuals/ ("AMI BIOS POST Codes User's Guide"). When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, the POST codes can be viewed from the BMC using the Post Snooping function.

  • Page 75: Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 76 USB device or a writable CD/DVD. Note 1: If you cannot locate the "Super.ROM" file in your drive disk, visit our website at www.supermicro.com to download the BIOS package. Extract the BIOS binary image into a USB flash device and rename it "Super.ROM" for the BIOS recovery use.
  • Page 77 Chapter 7: Troubleshooting and Support Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below. 4. When the screen as shown above displays, use the arrow keys to select the item "Proceed with flash update"...
  • Page 78 Chapter 7: Troubleshooting and Support 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the toolbar, select Boot to enter the submenu. From the submenu list, select Boot Option #1 as shown below. Then, set Boot Option #1 to [UEFI AP:UEFI: Built-in EFI Shell]. Press <F4>...
  • Page 79 Chapter 7: Troubleshooting and Support Note: Do not interrupt this process until the BIOS flashing is complete. 9. The screen above indicates that the BIOS update process is complete. When you see the screen above, unplug the AC power cable from the power supply, clear CMOS, and plug the AC power cable in the power supply again to power on the system.

  • Page 80: Cmos Clear

    Chapter 7: Troubleshooting and Support 7.7 CMOS Clear JBT1 is used to clear CMOS, which will also clear any passwords. Instead of pins, this jumper consists of contact pads to prevent accidentally clearing the contents of CMOS. To Clear CMOS 1.

  • Page 81: Where To Get Replacement Components

    7.8 Where to Get Replacement Components If you need replacement parts for your system, to ensure the highest level of professional service and technical support, purchase exclusively from our Supermicro Authorized Distributors/System Integrators/Resellers. A list can be found at: http://www.supermicro.com.

  • Page 82: Vendor Support Filing System

    For issues related to Red Hat Enterprise Linux, since it is a subscription based OS, contact your account representative. 7.10 Feedback Supermicro values your feedback as we strive to improve our customer experience in all facets of our business. Please email us at techwriterteam@supermicro.com to provide feedback on our manuals.

  • Page 83: Contacting Supermicro

    San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 84: Appendix A Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 85 Appendix A: Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 86 Appendix A: Warning Statements . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 87 Appendix A: Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 88 Appendix A: Warning Statements Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 89 Appendix A: Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告 システムコンポーネントの取り付けまたは取り外しのために、...
  • Page 90 Appendix A: Warning Statements ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
  • Page 91 Appendix A: Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 92 Appendix A: Warning Statements Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 93 Appendix A: Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 94 Appendix A: Warning Statements ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 95 Appendix A: Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 96 Appendix A: Warning Statements Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 97 Appendix A: Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 98 Appendix A: Warning Statements ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 99 Appendix A: Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 100 Appendix A: Warning Statements Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 101 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 102 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 103 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 104: Appendix B System Specifications

    Appendix B: System Specifications Appendix B System Specifications Processors Single 12th/13th Generation Core™ i9/i7/i5/i3 processor (LGA1700), up to 80W Chipset Intel® PCH R680E BIOS 512Mb AMI BIOS SPI Flash BIOS ® ACPI 6.0, Plug and Play (PnP), SPI dual/quad speed support, and Real Time Clock (RTC) wake up Memory Four DIMM slots, up to 128GB unbuffered ECC/non-ECC UDIMM, ECC DDR5 UDIMM with speeds up to 4000MT/s Storage Drives...
  • Page 105 Appendix B: System Specifications Operating Environment Operating Temperature: 0º to 40º C (32º to 104º F) Non-operating Temperature: -40º to 70º C (-40º to 158º F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) Regulatory Compliance FCC, ICES, CE, UKCA, VCCI, RCM, NRTL, CB Applied Directives, Standards...

  • Page 106: Bsmi/Rohs

    Appendix B: System Specifications BSMI/RoHS 限 限 用 用 物 物 質 質 含 含 有 有 情 情 況 況 標 標 示 示 聲 聲 明 明 書 書 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱：伺服器/ Server Equipment name 型號（型式）：510F-S2X13 (系列型號: 510- 2, SYS-111AD-HN2 )
  • Page 107 Appendix B: System Specifications 警告: 為避免電磁干擾, 本產品不應安裝或使用於住宅環境。 輸入額定 100-240V ~, 60-50Hz, 2.6A Max *使用者不能任意拆除或替換內部配備 *報驗義務人之姓名或名稱：美超微電腦股份有限公司 *報驗義務人之地址：新北市中和區建一路 150 號 3 樓...
