Related Manuals for BEITONG ZEUS ELITE
Summary of Contents for BEITONG ZEUS ELITE
- Page 1 USER MANUAL ZEUS ELITE GAME CONTROLLER...
- Page 2 USER MANUAL ZEUS ELITE GAME CONTROLLER...
- Page 3 USER MANUAL ZEUS ELITE GAME CONTROLLER...
- Page 4 USER MANUAL ZEUS ELITE GAME CONTROLLER...
- Page 5 USER MANUAL ZEUS ELITE GAME CONTROLLER...
- Page 6 USER MANUAL ZEUS ELITE GAME CONTROLLER...
- Page 7 USER MANUAL ZEUS ELITE GAME CONTROLLER...
- Page 8 USER MANUAL ZEUS ELITE GAME CONTROLLER...
- Page 9 USER MANUAL ZEUS ELITE GAME CONTROLLER...
- Page 10 USER MANUAL ZEUS ELITE GAME CONTROLLER...
- Page 11 Software Configuration Introduction ["Controller Assistant" Software Configuration] Download and install the software "T6 Assistant" 1. Download the software "T6" from BEITONG official website: https://www.betop-cn.com/en/#/down , and install it on the computer. 2. Use USB cable to connect the Gamepad and computer together a.
- Page 12 USER MANUAL Main Interface of T6 Assistant [Lighting Adjustment] Main interface > Default > Basic > Lighting ※ Configuration name can be modified ZEUS ELITE GAME CONTROLLER...
- Page 13 4. Brightness adjust of lights: 5 levels are optional [Vibration Adjustment] Main interface > Default > Basic > Vibration Gamepad 1. Adjust the intensity of vibration feedback of the 2. Enable vibration feedback of RETURN and MENU button ZEUS ELITE GAME CONTROLLER...
- Page 14 Click the input box after the arrow of Key [A] to delete the key value; Press Key B on the gamepad to map Key [ A] to Key [ B] 2. TURBO Setting ※ The frequency of the key can be set up to 18 times per second. ZEUS ELITE GAME CONTROLLER...
- Page 15 3. Macro Programming One button can be set to have a maximum of 30 actions You can record the [Action], [Duration] and [Interval] between each action in combo operations in real-time, and fine-tune them in milliseconds. ZEUS ELITE GAME CONTROLLER...
- Page 16 The LT/RT key is a linear trigger button, and the trigger stroke can be adjusted. ※ Factory default settings B Key Y Key A Key X Key [ Joystick Mapping Setting ] Main interface > Default > Analog Stick ZEUS ELITE GAME CONTROLLER...
- Page 17 [Somatosensory Settings] Main interface > Default > Motion Controls 1. 6-Axis gyro sensor, BEITONG somatosensory mapping technology support. 2. Can be mapped to [Joystick] or [Key]. 3. The somatosensory function can be turned off at any time through the motion control button of the gamepad.
- Page 18 ※ Default State FN Key: Open/Close Mouse Mode Left Joystick: Mouse Movement Right Joystick: Mouse Wheel Motion Control Switch: Open/Close Somatosensory of Mouse Somatosensory: Mouse Movement A Key: Left Mouse Button B Key: Right Mouse Button ZEUS ELITE GAME CONTROLLER...
- Page 19 [FN key] support to set the key combination, such as volume control, Back to the desktop, and screenshot record. Shortcut on PC Open the Flying Mouse A Key Left Mouse Button B Key Right Mouse Button FN + Up Sound + FN + Down Sound - FN + BACK Back to Desktop ZEUS ELITE GAME CONTROLLER...
- Page 20 USER MANUAL Shortcut on Switch *Short Press: Screenshot *Short Press: Back to Desktop *Long Press: Screen Recording *Long Press: Menu ZEUS ELITE GAME CONTROLLER...
-
Page 21: Joystick Calibration
LB + LEFT +DOWN Step 3: Turn the Power Button to ON to enter the calibration. * When the indicator light of BEITONG LOGO flashes in three colors, and the indicator of left and right grip are off, enter the calibration mode successfully. - Page 22 Step 4: Turn the left and right Joystick clockwise 2-3 turns, fully press the LT and RT and release them. Step 5: After completing the above operations to complete the calibration, long press the A key to exit the joystick calibration. ZEUS ELITE GAME CONTROLLER...
-
Page 23: Customer Service
Customizing professional control solutions for different types of games Creating the stronger experience of game control for gamers CUSTOMER SERVICE Official website: www.betop-cn.com Service Email: beitong-oversea@betop-cn.com More products and game information, please follow BEITONG official social media accounts. ZEUS ELITE GAME CONTROLLER...
