- Page 1 User Handbook Electric Top Loading Kilns For Ceramics - Controller ST535 ------------------------------------ TEL: 0030 210 6220520, 0030 210 6220521 Email. info@bonis.gr...
- Page 2 Dear Customer, Thank you for choosing a kiln made by Bonis SA. Your kiln is especially made for firing ceramics, it is a high performance product made by high quality raw materials, sourced from the best known European manufacturers. It features high quality insulation for low power consumption.
-
Page 3: Table Of Contents
1. KILN SPECIFICATIONS............4 2. SAFETY INSTRUCTIONS............4 2.1 Sign recognition............4 2.2 KILN PLACEMENT............5 3. CONNECTION TO POWER SUPPLY..........5 4. ABOUT THE KILN..............7 4.1 Knowing your kiln............7 4.2 Transport of kiln............10 4.3 Kiln Operation............10 4.4 Maintenance...............11 4.5 Insulation..............11 5. USING YOUR KILN.............11 5.1 Kiln shelves..............11 5.2 Kiln loading..............13 5.3 Kiln Cooling..............14... -
Page 4: Kiln Specifications
1. KILN SPECIFICATIONS A label with all kiln specifications is placed on the kilns control panel. 1. Year of manufacture 2. Type 3. Serial Number 4. Maximum temperature 5. Installed power - Kw 6. Amper (for single phase kilns) 7. Plug type / Power supply 8. -
Page 5: Kiln Placement
Declaration of Conformity This kiln is manufactured in accordance with EC directives Copyright by BONIS SA No responsibility is accepted for the correctness of this information. We reserve the right to make technical alterations. 2.2 KILN PLACEMENT • Do not place the kiln on a flammable table / floor •... - Page 6 Before proceeding to connecting the kiln please make sure that power supply is OFF Power supply: The phases are connected to the copper bridge of the relays. The copper bridges the contacts 2 / T1, 4 / T2, 6 / T3 of the relay. Depending on the type of furnace, the two phases are connected in red insulators, and the third phase in a copper relay truss.
-
Page 7: About The Kiln
4. ABOUT THE KILN 4.1 Knowing your kiln... - Page 8 1. Exhaust air Kiln features an exhaust air hole on the center of the lid. This hole must be always open. WARNING: Hot air will come through the hole. 2. Lid safety support Three position lid support. In the two lower positions the lid support keeps the lid open.
- Page 9 Please note: In case you need to move the assembled kiln, lift it from the kiln stand. Please ask for the kiln dis assemble manual if you need to move the kiln. Do not move the kiln while it is connected to the power supply Do not move the kiln with the lid open 7.
-
Page 10: Transport Of Kiln
4.2 Transport of kiln In case you need to move the assembled kiln, lift it from the kiln stand. Do not lift the assembled kiln from kiln handles or bottom handles. Do not move the kiln while it is connected to the power supply Do not move the kiln with the lid open Kiln handles and bottom handles are to be used during transportation of the kiln, ONLY IF the kiln is disassembled. -
Page 11: Maintenance
4.4 Maintenance Before proceeding to any maintenance or service operation Kiln main switch must be OFF, kiln must be unplugged or safety switch must be OFF 1. Kiln chamber must be kept clean, and any broken ceramic pieces must be taken out carefully. You can use a vacuum cleaner to clean the chamber. - Page 12 Kiln shelves must be smaller from the kiln interior diameter, as you need a gap between the shelf and kiln wall, for your hand to fit in, and for the hot air to circulate evenly. Supporting kiln shelves We advise you to support whole kiln shelves in 3 points. Always position the stilts one above the other for each layer, to avoid kiln shelf deformation or cracking.
-
Page 13: Kiln Loading
5.2 Kiln loading During loading / unloading of the kiln, the main switch must be OFF, the kiln must be unplugged from power, or the power switch must be also to OFF position Make sure the lid is well supported before loading / unloading the kiln. -
Page 14: Kiln Cooling
5.3 Kiln Cooling Your new kiln features a multilayer insulation, which ensures minimum heating loss, and very slow cooling. To cool the kiln faster you can use the quick cooling position of the kilns lid support. This position keeps the lid open for few centimeters, and it helps the kiln to cool faster. -
Page 15: Controller St 535
6. Controller ST 535 6.1 Controller ST215 Features · Multiple zone control (2 or 3) · 32 programs each with 32 segments · 1 controlled heating / cooling ramp + soak per segment · Soak times up to 99 hours 59 mins ·... -
Page 16: Controller Overview
6.2 Controller overview 6.3 Turning On When turned on the ST535 performs a display test by lighting all of the display segments and illuminating all of the front panel indicator lamps. -
Page 17: Quick Start Guide
The version number of the software embedded within the ST535 is now displayed. If you need technical support you might be asked for this code together with the serial number. Next displayed is the thermocouple type setting.This should match the type of... -
Page 18: Firing Program
(crystal glazing or glass-making for example). The ST535 ramps the kiln temperature at the required ramp rate until the kiln reaches the soak / target temperature It then soaks (dwells) at the soak temperature for the soak time. -
Page 19: Program Samples
6.6 Program Samples The below table shows three different programs: NORMAL rate– The basic program, suitable for most ceramics SLOW rate – Suitable for thick and large ceramics FAST / GLAZE – Suitable for small thin ceramics, as well as for Glaze firings ... - Page 20 ► The first push of the key flashes the program number display. ▲ ▼ The required firing program can now be selected with the & keys ▲ ▼ Note: holding down the keys causes rapid change of the displayed value ►...
- Page 21 Main display shows the segment final temperature. ▲ ▼ This can be altered with the & keys. The soak temperature indicator on the mimic panel will flash ( When the desired temperature is set press button ► Main display shows the soak time in hours:minutes.
-
Page 22: Altering, Reviewing A Program
► When END is displayed, to exit program data entry push key. The display shows the current kiln temperature. No indicators lit on the mimic panel and the run indicator is off Note 1: to exit programming without cycling through all of the above steps wait 10 seconds without pressing any keys - the ST215 will revert to the idle display. -
Page 23: Indications During Firing
Program start delay can be up to 99 hours: 59 minutes, and it is programmed when you select to start a firing. Note: Delayed time is AFTER how many hours you want the program to start, not what time you want it to start. Example: If the current time is 14.00 and you want the program to start at 19.00 you enter 05.00 (hh.mm) as delayed time ... -
Page 24: Functions During Firing
(advance) function. The ST535 will sound a short beep and the executing program will immediately advance one step as indicated by lamps on the mimic panel. The effect of this is as follows:- If ramping then the ST535 will switch to soak at the current kiln temperature. -
Page 25: Program Pause Facility
If soaking then the ST535 will advance to the next segment if any, or else it will end the firing. Changes made to the operation of the ST535 in this way are temporary and are not stored. Program Pause Facility: ▼... -
Page 26: Completion Of Firing
While the kiln temperature is above 40°C the display alternates every 5 seconds between the kiln temperature and Hot. Upon completion of firing the ST535 lights all lamps on the mimic display and the kiln is allowed to cool naturally. -
Page 27: Error Messages
6.14 Error Messages If the ST535 detects a problem the buzzer will sound and an error message will be displayed. This error message will alternate with a display of kiln temperature. The segment number display will show where the error occurred. - Page 28 ERROR 7 Maximum room temperature exceeded. The internal temperature of the ST535 has exceeded an installer selectable limit. Possible causes: kiln room vent fan failure, kiln room too small, ventilation grills blocked, damper or bung left open, controller mounted too close to kiln.
- Page 29 All these error messages cause the ST535 to terminate the firing. The alarm buzzer will sound once per second. To reset the ST535 turn off the power to the instrument and have the fault investigated and rectified by your installer or kiln service engineer.
-
Page 30: Kiln Drying - First Firing
7. Kiln Drying – First firing Before using your kiln for firing you ceramics you must complete a first firing, which will allow the kiln insulation material to dry, and will create a thin protecting layer over the heating elements, which will make them last longer. It is also recommended to place all your kiln shelves in the kiln, in order to dry them out. -
Page 31: Pre Installed Programs
8. Pre installed Programs Type Rate T Max Soak Duration PRO 1 BISQUE SLOW 00.10 14.17 PRO 2 BISQUE SLOW 1000 00.10 14.27 PRO 3 BISQUE SLOW 1020 00.10 14.37 PRO 4 BISQUE SLOW 1040 00.10 14.47 PRO 5 BISQUE SLOW 1200 00.10... -
Page 32: My Programs
9. My Programs... -
Page 33: Notes
10. Notes...
