- Page 1 User Manual 20520001 Antidrastiras CG05 Jacketed Crystallization Reactor User Manual Version 1.0...
-
Page 2: Table Of Contents
Disclaimer & Warranty ..................... 4 LIMITED WARRANTY & DISCLAIMER..................4 LIMITATION OF LIABILITY ......................6 Safety ........................8 III. Antidrastiras CG05 Introduction ..................10 After Sales Support .....................11 Proper Use .........................11 Technical Specifications ....................12 Standards and Conformity ....................12 Inspection ........................13 VII. - Page 3 User Manual 10.2 Cleaning of the main body of the crystallization reactor ..........19 XI. Equipment Decommissioning and Waste Disposal ..............19 11.1 Equipment decommissioning ..................19 11.2 Waste disposal ......................19 XII. Transport and storage ......................20 12.1 Transport ........................20 12.2 Storage ........................20 Version 1.0...
-
Page 4: Disclaimer & Warranty
User Manual Disclaimer & Warranty ● The intellectual property rights for this manual belong to Holland Green Science Corporation (hereinafter referred to as “the Company”). ● Products of the company are under the patent protection of China and other countries and regions (inclusive of obtained patents and patents currently under application). - Page 5 User Manual product-specific handling instructions, then, if applicable, Buyer may return the defective Products to the Company with all costs prepaid by Buyer. Replacement parts may be new or refurbished, at the election of the Company. All replaced parts shall become the property of the Company.
-
Page 6: Limitation Of Liability
User Manual ASSIGNMENT OR ALIENATION OF THE LIMITED WARRANTIES PROVIDED BY THE COMPANY HEREIN TO ANY OTHER PARTY OTHER THAN BUYER, INCLUDING BUT NOT LIMITED TO, SUCCESSORS, HEIRS, SUBSIDIARIES OR ANY OTHER THIRD PERSON. THE WARRANTIES IDENTIFIED ABOVE ARE THE SOLE AND EXCLUSIVE WARRANTIES WITH RESPECT TO THIS PRODUCT AND ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. - Page 7 User Manual its licensor, as the case may be, retains all rights and interest in software products provided hereunder. See the Terms & Conditions of purchase for details regarding such license. Version 1.0...
-
Page 8: Safety
User Manual Safety IMPORTANT Safety Items to be Observed. Safety Warnings ! DANGER (may cause serious damage to property and / or casualties) 1. Please carefully read this User Manual prior to operating the instrument and observe the instructions on safe operation. 2. - Page 9 User Manual those selected or approved by the Company shall operate to void any warranty contained hereinabove for the product 17. Only accredited and qualified professional repair technicians can open the instrument or conduct required repairs. Persons performing repairs on the instrument other than those selected or approved by the Company shall operate to void any warranty contained hereinabove for the product 18.
-
Page 10: Antidrastiras Cg05 Introduction
III. Antidrastiras CG05 Introduction Antidrastiras CG05 is a jacketed crystallization reactor that combines the functions of a chemical reactor and a Nutsche filter. The processing is thermoregulated. The filtered liquid is collected in a (detachable) filtrate bottle and agitation and mixing are achieved through an overhead suspended impeller. -
Page 11: After Sales Support
User Manual After Sales Support If problems are encountered or technical support is required when installing or using the instrument, please contact serviceusa@hollandgreenscience.com The Company may provide technical assistance and information regarding the instrument or equipment or Service without charge at its sole discretion. Buyer assumes sole responsibility for any reliance on or use of such assistance and information, and the Company makes no warranty thereon. -
Page 12: Technical Specifications
User Manual Technical Specifications Model 20520001 20520002 20520003 20520004 20520005 Antidrastiras Antidrastiras Antidrastiras Antidrastiras Antidrastiras Product Name CG05 CG10 CG20 CG50 CG100 10 L 20 L 50 L 100 L Volume 1.5 L 16 L 30 L Jacket Volume 100x50x17 120x50x17 130x50x185 140x60x20... -
Page 13: Inspection
User Manual Inspection Packing List Unpack the equipment carefully and check for any damage which may have arisen during transport. In the event of identified damage, please contact serviceusa@hollandgreenscience.com. The package includes the following items Type Quantity Glass Crystallizer System Reactor Vessel Condenser Collection Bottles... -
Page 14: Installation Requirements
User Manual VII. Installation Requirements 7.1 Location of reactor (installation) The reactor location must meet the following requirements: ● The reactor should be installed on a solid and level surface, in a preferably air- conditioned environment. Tie downs may be used to secure the reactor if required. ●... -
Page 15: Installation Of Filter Bottom Plate And Main Body Bottom Valve
User Manual 7.7 Installation of filter bottom plate and main body bottom valve Put the filter plate on the filter bottom plate, install it on the bottom of the crystallization reactor, and fasten the filter bottom plate with the bottom support ring. Install the bottom valve of the crystallization reactor on the filter floor. -
Page 16: Opening And Closing Chamber
User Manual 8.2 Opening and Closing Chamber There is a serious health risk that may occur if the hot and possibly poisonous steam is inhaled. ● Stay clear of steam generated during the distillation process. ● Remove steam by venting in an area with adequate ventilation or using high performance extraction equipment. -
Page 17: Fault Diagnosis
User Manual Fault Diagnosis Fault Remedies Check the power cables for loose connections and breaker box for tripped breakers and/or blown fuse. Check the power switch for No display on LCD screen damage and contact service if equipment fails to turn on. after the power is turned on After power on, LCD screen Check the connection of the impeller motor and the connection... - Page 18 User Manual Why does the speed Over torque protection action. The torque required exceeds the set display panel show torque maximum value. Check the torque correlation parameters and "E0L2"? external torque. Why does the speed Low voltage. The power supply voltage is too low. Please check display panel show "ELU"? supply voltage.
-
Page 19: Maintenance And Cleaning
User Manual Maintenance and Cleaning ● Only a suitably skilled and trained operator should carry out the maintenance and cleaning work described in this chapter. ● Only the original materials and spare parts should be used to replace old or damaged parts and to maintain the products warranty. - Page 20 User Manual XII. Transport and storage 12.1 Transport ● Ensure that the equipment has been disassembled and all parts of the equipment are packed in a safe manner to prevent breakage. The equipment should be repacked in the original packing box if possible. ●...
