- Page 1 SINGLE DISHDRAWER™ DISHWASHER CONTEMPORARY DD60SCTHX9, DD60SCHW9 INSTALLATION GUIDE...
-
Page 3: Safety And Warnings
SAFETY AND WARNINGS WARNING! WARNING! Electric Shock Hazard Cut Hazard Failure to follow this advice may result in Failure to use caution could result in injury. electrical shock or death. • Take care - panel edges are sharp. • Before installing the DishDrawer, remove the house fuse or open the circuit breaker. -
Page 4: Installation
SAFETY AND WARNINGS WARNING! Ensure the product is not plugged in when fitting custom panels. Installation of custom panels requires basic mechanical and electrical skills. To reduce the risk of fire, injury to persons or damage when using the appliance, follow the Installation must comply with your local building and electricity regulations. -
Page 5: Tools And Components
TOOLS AND COMPONENTS PARTS SUPPLIED TOOLS REQUIRED Keep all packing materials until the unit has been inspected. Not supplied Inspect the product to ensure there is no shipping damage. If any damage is detected contact the dealer or retailer you bought the product from to report the damage. Fisher &... -
Page 6: Product Dimensions
PRODUCT DIMENSIONS — DD60SC MODELS DD60SC DD60SCT PRODUCT DIMENSIONS A Overall height B Overall width C Overall depth D Depth of chassis PLAN ISOMETRIC E Height of door panel F Depth of door panel G Ventilation gap below door panel H Height from top of drawer panel to top of chassis I Max. -
Page 7: Cabinetry Dimensions
CABINETRY DIMENSIONS CLEARANCES Connections can be located in an adjacent cabinet on either side of the DishDrawer*** PLAN ISOMETRIC STD MODELS TALL MODELS CABINETRY CLEARANCES CABINETRY DIMENSIONS A Minimum clearance to adjacent cupboard door A Minimum inside height* min. 412 min. -
Page 8: Left Side
PLUMBING & ELECTRICAL CONSIDERATIONS Hose and cord lengths Your services can be installed to either the left-hand or right-hand side of the product in an adjacent cabinet. Refer to 'Cabinetry preparation' for service access requirements. If the drain hoses supplied are not long enough to reach your services, you may purchase a Fisher &... - Page 9 CABINETRY PREPARATION SERVICE ACCESS MOISTURE PROTECTION We recommend locating the service holes on either side of the DishDrawer as shown below. If the hole is created through wood, ensure the edges are smooth and rounded If the holes is created through metal, ensure the edge protector is fitted. Align the supplied moisture protection tape to the cabinetry as illustrated Ensure this area is free of debris...
- Page 10 SECURE TO CABINETRY VIA BRACKETS (METHOD A) Secure all four side brackets to the DishDrawer™ Dishwasher, aligning Secure to cabinetry via the brackets. bracket A with slot A and bracket B Pre-drilling a pilot hole may be required with slot B. depending on the cabinetry material.
- Page 11 SECURE TO CABINETRY VIA DRAWER REMOVAL (METHOD B) Push the product into the cavity, pulling the hoses through as you push to avoid Secure to cabinetry via all three fixing crushing or twisting them. locations in the chassis. Push the product in the positions Ensure sound insulation is illustrated to avoid denting the door.
- Page 12 PLUMBING & ELECTRICAL CONNECTION Ø38MM STANDPIPE INSTALLATION SINK TRAP/WASTE TEE INSTALLATION Install the drain hose support to the Install the drain hose support to the back wall, as close to the underside of back wall, as close to the underside of the countertop as possible.
-
Page 13: Installer Checklist
INSTALLER CHECKLIST TO BE COMPLETED BY THE INSTALLER Installation Electrical … Check all parts are installed correctly and are secure. … Ensure all electrical tests have been conducted in accordance with local regulations. … Ensure DishDrawer™ Dishwasher is securely fastened to the cabinetry and drawer opens and closes freely with no resistance. -
Page 14: Troubleshooting
TROUBLESHOOTING The DishDrawer is beeping continuously DISPLAY POSSIBLE CAUSE WHAT TO DO Refer to the ‘Fault codes’ section of your User guide Water 1 Ensure the water supply is turned on. Supply fault. 2 Press once to stop the beeping, No program indicator lights up when the drawer is opened then again to clear the fault. - Page 15 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2021. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue.
