Permaban AlphaJoint Installation Guide
Using AlphaFeet Method
Installation Guide Issue V1.0
05/10/21
Alpha foot
03 Fix joints together
Position joints end to end, unscrew the wing nut and nylon, push the 60mm offsets together and
re-assemble.
Note: The 4010 top strip may move laterally during transit and require minor realignment during
installation.
60mm
Offset
Joints must be flush with one another.
✖
Note: Ideal placement for the feet as shown above
✔
Alpha foot
Nylon bolt
Joints fit together
All content found within this installation guide is approximate. RCR Flooring Products Ltd reserves the right to
amend this installation guide at any time. For further details, please contact RCR Flooring Products Ltd.
Alpha foot
Butterfly/wing nut
RCR Flooring Products Ltd is registered in England & Wales - No. 02815314.
