7.0 Technical Specifications

7.1 Power / Probe Overload Cutoff

The Apollo CW4000 system is classified by the U.S. Code of
Federal Regulations as a Class I device. In Europe the Apollo
system is classified as a Class IIa device. In Canada it is Class II.
Power is provided to the Apollo CW4000 system via a Hospital
Grade external power supply included with the purchased system:
• External, Universal AC input (100-240 vac 47-63 hz),
100 watts, DC-out: 12 V, 8.33 A.
• For U.S. applications, the AC mains plug is
Hospital Grade, NEMA 5-15P-HG
• Contact Care Wise or your Care Wise distributor to
supply or replace the proper AC mains plug/cable for
your application or governmental/country requirements.
• The guidelines set forth by your recognized National
Certification Body (NCB) may require additional
certification. If required, contact Care Wise or your
Care Wise distributor for assistance.
CAUTION: Use only a power supply provided by Care Wise
specifically for the C-Trak
®
occurrence of shock, fire or product damage.
Bias voltage supplied to the probe is generated by a stable, high
voltage supply embedded within the C-Trak
The voltage is set at 900 vdc and the current is always less than
10 µA. Any current exceeding this threshold will immediately turn
OFF this voltage. The system can only be turned back ON via
direct user interaction as directed by the displayed error message.
Unauthorized attempts to repair the probe, cable or the C-Trak
Apollo computer system can result in a minor electrical shock.
Neither the external power supply nor the power supply
inside the computer are serviceable by the user.
CAUTION: Use only the hospital grade power supply and
power cord provided by Care Wise. The use of any other
power supply or power cord may cause harm to the
user, damage the equipment and void the warranty.
Contact Care Wise for repair or replacement parts.
Automatic shutoff is a safety feature of the C-Trak
system. Ten micro amperes (10 µA) is the international standard
for the maximum allowable leakage current from a medical
device operating off of an external power source that contacts a
patient's body during use. If current greater than 10 µA were to
flow to the probe, the C-Trak
shut off all current to the probe to prevent any risk to patient
or surgeon. A warning dialog would then appear on screen
instructing the user how to proceed safely.
www.carewise.com
|
30
Apollo System to prevent the
Apollo system.
®
Apollo
®
Apollo system would immediately
®

7.2 LCD Display

The 17" LCD Resistive Touch display is integral to the C-Trak
Apollo CW4000 System. The screen is sensitive to finger pressure
and does not require a stylus. Resolution is 1280 x 1024.
7.3 Probe Connector
Series 'MHV' coaxial connector for ALL probes
[CAUTION: This is NOT a "BNC" style connector.]

7.4 Size

420 mm (W) x 360 mm (H) x 80 mm (D)

7.5 Weight

Approximately 7 kg (15.4 lbs).

7.6 Finish

Anti-bacterial coated plastic.

7.7 Mode of Operation

Continuous operation.

7.8 Serial Numbers

The serial number of the analyzer is located on the back of the
unit on the Product Label. The serial number for the probe is
engraved on the side of the probe at the base of the probe
body, near the cable connection.
®

7.9 Environmental Limits

Operational Temperature
Storage Temperature
Operation Relative Humidity
Storage Relative Humidity
Atmospheric Pressure
Operational Altitude

7.10 Label Legibility

In normal use, the operator of the CW4000 views the product
from the front, facing the computer screen usually at a distance
no greater than nine (9) feet. The ID/Serial Number Label is on
the rear of the product and is intended to be viewed in a normal,
room lighting environment (500 lux or greater) by a person with
a visual acuity (corrected, if necessary) of 20/20 at a distance
of approximately 12-18 inches (a normal reading distance).
Aside from the serial number, the information included on
this label is also available in the printed User's Guide
(included with each product).
®
10-40˚ C (50˚ F to 104˚ F)
10-40˚ C (50˚ F to 104˚ F)
30% - 75%, non-condensing
30% - 75%, non-condensing
700 hPa to 1060 hPa
less than 2000 meters
(~6000 ft)
