17.0 Grounding Instructions

A
Circuit grounding conductor
connected properly
B
Adapter
C
52 Grounding Instructions
Grounding prong
Grounding means
Metal mounting screw
Cover of grounded
outlet box
This appliance must be grounded while in use to
protect the operator from electrical shock� The
appliance is equipped with a 3-conductor cord and
a 3-prong grounding-type plug to fit the proper
grounding-type receptacle� The appliance has a
plug that looks like sketch
left side� An adaptor, sketch
connecting sketch-A plugs to two-prong receptacles�
The grounding tab which extends from the adaptor
must be connected to a permanent ground such as a
properly grounded outlet box as shown in sketch
using a metal screw�
A
in the figure on the
B , should be used for
C
