- Page 1 MiniView™ Micro USB Audio 2 Port USB KVM Switch with Built-in KVM Cables Installation Manual (GCS712U) ®...
- Page 2 ® IOGEAR the IOGEAR logo, MiniView, VSE are trademarks or registered trademarks of IOGEAR Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. IBM is a registered trademark of International Business Machines, Inc. Macintosh, G3/G4 and iMac are registered ®...
- Page 3 ® With the MiniView™ Micro USB Audio by IOGEAR , you can access two computers from a single console (keyboard, mouse and monitor), and allow them share multimedia speakers.
-
Page 4: Table Of Contents
Table of Contents Package Contents Overview Features Requirements Pictorial Introduction Installation Operation Specification Troubleshooting Troubleshooting Con’d Tech Support Radio & TV Interference Statement Limited Warranty... -
Page 5: Package Contents
Package Contents This package contains: 1 MiniView Micro Micro USB Audio 2 Port KVM Switch 1 User Manual 1 Quick Start Guide 1 Warranty Registration Card If any items are damaged or missing, please contact your dealer. -
Page 6: Overview
Windows and Mac computers as well as Sun Solaris workstations. There is no better way to save time and money than with a GCS712U installation. By allowing a single console to manage both computers, the GCS712U eliminates the expense of purchasing a separate keyboard, monitor, and mouse for each computer. -
Page 7: Features
• The smallest 2 port KVM switch with audio support available • Use one keyboard, monitor and mouse to control 2 computers • Share multimedia speakers among two computers • 6' long molded-in cables to simplify setup • Microsoft Intellimouse, Logitech FirstMouse+, and the scrolling wheel on most mice •... -
Page 8: Requirements
Requirements Console • A VGA, SVGA, or Multisync monitor capable of the highest resolution that you will be using on any computer in the installation. • A PS/2 Style Mouse. • A PS/2 Keyboard. Computers The following equipment must be installed on each computer that is to be connected to the system: •... - Page 9 Requirements Cables For optimum signal integrity and to simplify the layout, high-quality 3-in-1 Custom KVM cables have been designed into the GCS712U. There is no need for a separate cable purchase. Note: The KVM cables have PS/2 style keyboard and mouse connectors. The GCS712U does...
-
Page 10: Pictorial Introduction
Pictorial Introduction 1. KVM Cables These 3-in-1 cables connect to the USB, video, and audio ports on the computers you are installing. 2. Port LEDs A LED lights to indicate its corresponding port is the one that has the KVM focus. Depending on the port’s status, the LED may flash according to a specific pattern. -
Page 11: Installation
Step 1. Before you begin, please turn off the computers you are going to connect to the MiniView™ Micro USB Audio Switch. NOTE: To prevent damage to your equipment due to static electric discharge, please make sure that all devices on the installation are properly grounded. - Page 12 Installation Step. 2 Connect the VGA cable that is built into the KVM cable of your MiniView™ Micro Audio to the VGA port on your computer. Connect USB cable to an available USB port on your computer Connect the speaker cable that is built into the KVM cable of your MiniView™...
- Page 13 Installation Step 3. Repeat step 2 for the rest of you computers. Step 4. Turn on the power to the computers.
-
Page 14: Operation
Operation Accessing both of your computers from a single console could not be easier. The GCS712U uses Hotkey combinations to provide KVM focus to the computers. The Hotkey combinations allow you to: • Select the Active Port • Invoke Auto Scan Mode •... - Page 15 Operation Auto Scan Mode The GCS712U’s Auto Scan feature automatically switches the KVM focus between the two computers at regular intervals so that you can monitor their activity without having to take the trouble of switching yourself. The default time interval is 5 seconds. To invoke Auto Scan Mode: Press and release the Left Shift key;...
- Page 16 Operation Changing the Scan Interval Before you invoke Auto Scanning you can change the amount of time Auto Scan dwells on each port. To do so, use the following Hotkey combination. [Left shift] [Right shift] Where n represents a number from 1 to 4 that specifies the desired scan interval time, as shown in the table below: Note: You must press and release the keys one at a time.
- Page 17 LED Display Activity On (Steady) Flashing Function Port is not selected Port is connected to an active computer Port is connected to an active computer, and is being accessed in AutoScan Mode Operation...
-
Page 18: Specification
Specification Specifications... -
Page 19: Troubleshooting
TroubleShooting Symptom Possible Cause Action Check all keyboard cable Keyboard Not Loose cables. Responding 1 connections to make sure they are completely seated in their sockets. Keyboard needs to Unplug the keyboard from the Console be reset. Keyboard Port, then plug it back in. Turn off the computers. -
Page 20: Troubleshooting Con'd
TroubleShooting Con’d TroubleShooting Con’d Symptom Possible Cause Mouse Not Switch needs to be reset. Detected, or Does Not Respond Correctly. Mouse set to Serial Mode. Incorrect Mouse Driver. Resolution and/or Video Bandwidth set too Problems high Action Turn off the computers and unplug the KVM cables. -
Page 21: Tech Support
Technical Support If you need technical support, please check out our IOGEAR Tech Info Library (T.I.L.) at www.iogear.com/support for the latest tips, tricks, and troubleshooting. The IOGEAR T.I.L. was designed to provide you with the latest technical information about our products. -
Page 22: Radio & Tv Interference Statement
Radio & TV Interference Statement WARNING!!! This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause interference to radio communications. This equipment has been tested and found to comply with the limits for a Class B computing device pursuant to Subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment. -
Page 23: Limited Warranty
Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR’S LIABILITY FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK OR ITS DOCUMEN- TATION EXCEED THE PRICE PAID FOR THE PRODUCT. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and especially disclaims its quality, performance, merchantability, or fitness for any particular purpose. - Page 24 ® Contact info. 23 Hubble • Irvine, CA 92618 • (P)949.453.8782 • (F)949.453.8785 • www.iogear.com...
