Configuring the McPC 10/100

Before installing, configure the McPC 10/100 using the DIP switch
located as shown below on the printed circuit board (PCB). The following
illustration shows the location of the DIP switch as well as its default
settings. Consult the chart below for the function of each switch.
The table below shows the DIP switch settings for McPC 10/100:
F S
EATURE WITCH
LFD
AN
Force
10/100
Note: Switch #'s 1 - 4 are factory configured — DO NOT CHANGE
#
5
Link Fault Detection (Available in Force modes only)
Auto-Negotiation Mode (Valid only when Force
6
mode is disabled)
Force Mode — Forces the converter to operate at
7
10 or 100 Mbps as determined by switch 8
When ON, the converter operates at 10 Mbps.
When OFF, the converter operates at 100 Mbps.
8
8 is only valid in Force Mode, i.e. when switch 7 is
ON
F
UNCTION
2
D
EFAULT
OFF
ON
OFF
OFF
