DO NOT
use or place the transceiver in areas with tem-
peratures below -30°C or above +60°C or, in areas subject
to direct sunlight, such as the dashboard.
AVOID
operating the transceiver without running the vehi-
cle's engine. The vehicle's battery will quickly run out if the
transceiver is in transmission while the vehicle's engine is
OFF.
AVOID
placing the transceiver in excessively dusty envi-
ronments.
AVOID
placing the transceiver against walls. This will ob-
struct heat dissipation.
AVOID
the use of chemical agents such as benzine or al-
cohol when cleaning, as they damage the transceiver sur-
faces.
BE CAREFUL!
The transceiver will become hot when
operating continuously for long periods.
For U.S.A. only
CAUTION: Changes or modifications to this transceiver, not ex-
pressly approved by Icom Inc., could void your authority to operate
this transceiver under FCC regulations.

TABLE OF CONTENTS

IMPORTANT ........................................................................ i
EXPLICIT DEFINITIONS ..................................................... i
CAUTIONS .......................................................................... i
TABLE OF CONTENTS ...................................................... ii
1 PANEL DESCRIPTION ............................................. 1-5
Front panel ............................................................................ 1
Function LED ........................................................................ 2
Programmable function keys ................................................ 3
2 OPERATION ............................................................. 6-8
Turning power ON ................................................................ 6
Channel selection ................................................................. 6
Receiving and transmitting ................................................... 7
D Transmitting notes .......................................................... 7
D DTMF transmission ........................................................ 8
D Scrambler function ......................................................... 8
User set mode ...................................................................... 8
D Entering user set mode .................................................. 8
3 CONNECTION AND MAINTENANCE .................... 9-12
Rear panel and connection ................................................... 9
Supplied accessories .......................................................... 10
Mounting the transceiver...................................................... 11
Optional UT-96/UT-105/UT-109/UT110 installation ............. 11
Optional OPC-617 installation ............................................. 12
Antenna ............................................................................... 12
Fuse replacement ............................................................... 12
Cleaning ............................................................................. 12
4 OPTIONAL SmarTrunk II™ OPERATION ........... 13-15
SmarTrunk II™ and conventional modes ........................... 13
SmarTrunk II™ operation ................................................... 13
5 OPTIONS .................................................................... 16
