5. Check gear box oil level--YEARLY
Turn the power switch to the ―OFF‖ position. Open the rear door and remove the
rear battery. Remove the gearbox oil plug through the access hole in the gearbox
mounting bracket. The oil level of each gearbox should be at the bottom of the plug
hole. If the oil level is low, fill the gearbox with 80W90 gear oil to the oil plug l Tighten
the plugs and reinstall the rear battery. Do not remove the low oil plug. Filling the
gearbox only to the low oil plug level will result in severe gearbox damage

1. Machine does not move

Possible Cause
Receiver fuse is blown
Corrosion on battery
connections
Discharged or faulty batteries
Loose wire in electrical box
Battery charger not properly
attached
Faulty power switch

Trouble shooting

Check fuse and replace with a 3 amp fuse if
necessary
Clean battery connections as outlined in the
Maintenance section
Charge or replace batteries as necessary.
Check connections in electrical box
Check if the charger receptacle wires are connected
to batteries.
Check power switch. Refer to Electrical service-
Checking the power switch.
6
Check/Repair
