Tyco T1200-C Series Application Manual page 8

T1200
MARINEC-P-A
3 02/14
4.1.2 Replacement Part Order Codes and Descriptions
Tyco Part No.
509.023.006 C1626 – 4-zone panel motherboard. With AC PSU
509.023.007 C1626 – 4-zone panel motherboard. With no PSU
509.023.008 C1627 – T1216-C panel motherboard
509.023.009 C1627 – T1232-C panel motherboard
509.023.012 C1626 – Repeater motherboard
C1628 – 4-zone panel display 2605041 fitted with 4 zone overlay
509.023.021
[No inserts]
C1628 – 16-zone panel display 2605043 fitted with 16 zone overlay
509.023.022
[No inserts]
C1629 – 32-zone panel display 2605044 fitted with 32 zone overlay
509.023.023
[No inserts]
C1628 – 16-zone repeater display 2605054 fitted with 16 zone overlay
509.023.031
[No inserts]
C1629 – 32-zone repeater display 2605055 fitted with 32 zone overlay
509.023.032
[No inserts]
2605061 C1631 – Repeater interface Board
2605060 C1630 – Output Expansion Interface Board
509.023.042 C1632 – 16-zone expansion board (provides zones 17 to 32)
2605064 C1634 Relay Output Board
508.023.035 C1665 – Muster interface (Optional add-on)
509.023.071 C1714 VDR Interface Board
509.023.052 24 VDC PSU [PS40-1-09]
509.023.051 110/230V AC PSU [PS136-1-09]
509.023.061 T1200/T1200-C Spare key set - 2 off access controls keys
PAGE 8 of 67
Description Used in
T1204A1
T1204A2
T1204DC
T1216-C
T1232-C
T1216R-C
T1232R-C
T1204A1
T1204A2
T1204DC
T1216-C
T1232-C
T1216R-C
T1232R-C
T1216-C [with repeater]
T1232-C [with repeater]
T1216R-C
T1232R-C
T1216-C
T1232-C
T1232-C
T1216-C
T1232-C
T1216-C
T1232-C
T1216R-C
T1232R-C
T1216-C
T1232-C
T1204DC
T1216-C
T1232-C
All panels and repeaters
