Summary of Contents for ALDI FERREX 300W
- Page 3 4 12 4 13 4 14 4 10 4 15 4 11...
- Page 5 Scope of delivery/device components Securing clip Tension lever ON / OFF switch Vibration rate preselection Thread for additional handle Tool holder HCS plunge-cut saw blade (32 mm) Segment saw blade (85 mm) Sanding plate Scraper (50 mm) Sanding sheets Additional handle HSS plunge-cut saw blade (32 mm) Extraction channel Extraction adapter...
-
Page 6: General Information
300W multifunctional tool General information General information Reading and storing the user manual This user manual accompanies this 300W multifunctional tool. It contains important information on start-up and handling. For improved readability, the 300W multifunctional tool will be referred to only as the “multifunctional tool”... -
Page 7: Residual Risks
300W multifunctional tool Safety • Operation or maintenance of the multifunctional tool by persons not familiar with how to handle the multifunctional tool and/or who are not aware of the related risks. Residual risks Despite proper use, inconspicuous residual risks cannot be completely ruled out. The following risks may arise due to the nature of the multifunctional tool: •... -
Page 8: General Power Tool Safety Instructions
300W multifunctional tool Safety Wear protective goggles. Wear a dust mask. Wear ear protection. Wear suitable protective gloves. Read the user manual! The multifunctional tool complies with protection class II. Safety General power tool safety instructions WARNING Read all safety instructions and instructions. Failure to follow the safety instructions and instructions may result in an electric shock, fire and/or severe injury. -
Page 9: Electrical Safety
300W multifunctional tool Safety Electrical safety a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. - Page 10 300W multifunctional tool Safety clothing and gloves away from moving parts. g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards. h) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles.
- Page 11 300W multifunctional tool Safety Operational safety instructions for your multifunctional tool – Hold the multifunctional tool by the insulated handles when performing work where there is a risk of the fitted tool being used coming into contact with hidden power lines. Contact with a live line could also energise metallic parts of the device and inflict an electric shock.
-
Page 12: Safety Instructions For Sanding Paint
300W multifunctional tool Safety Safety instructions for sanding paint – Do not sand paints that contain lead. Determine whether the paint you intend to sand contains lead before beginning work. Dust from paints containing lead may cause lead poisoning. – A special test or a commercial painting contractor can determine whether a paint contains lead. -
Page 13: Safety Precaution For Fire Prevention
300W multifunctional tool Preparation – When disposing of dust, be particularly careful as the dust of some materials may be explosive. Do not dispose of sanding dust in fire. Mixtures of dust particles containing oil or water could spontaneously ignite over time. Safety precaution for fire prevention Keep an extinguisher on hand. -
Page 14: Familiarising Yourself With The Functional Principle
300W multifunctional tool Preparation Familiarising yourself with the functional principle The multifunctional tool does not rotate the fitted tool; instead, it oscillates it back and forth. Familiarising yourself with permissible materials You can use the following tools to process the listed materials: Plunge-cut saw blade •... -
Page 15: Mounting Tools
300W multifunctional tool Preparation Mounting tools CAUTION! Risk of injury! If you mount the tools incorrectly and they are therefore able to come into contact with your hand during use, there is a risk of injury. – Do not mount the tools such that there is a possibility of them coming into contact with your hand. -
Page 16: Operation
300W multifunctional tool Operation Operation Getting started Make sure that the multifunctional tool has been properly prepared as described in the chapter “Preparing the multifunctional tool”. Connect the multifunctional tool to a mains socket. Switch the extractor on. to switch the multifunctional tool on. (see fig. H) Use the On/Off switch to adjust the speed. -
Page 17: Cleaning And Maintenance
300W multifunctional tool Cleaning and maintenance Cleaning and maintenance WARNING! Burn hazard! Some tools become hot during operation. You could burn yourself. − Always let them cool off completely before cleaning! NOTICE! Risk of short circuit! Water that has penetrated the housing may cause a short circuit. −... -
Page 18: Storage And Transport
300W multifunctional tool Storage and transport Storage and transport NOTICE! Risk of damage! Improper storage or transport of the multifunctional tool could damage it. – Store and transport the multifunctional tool in a clean, dry and frost-free location. Always use the enclosed storage bag to store and transport the multifunctional tool and the accessories. -
Page 19: Troubleshooting
300W multifunctional tool Repairs Troubleshooting Some problems may be caused by minor faults that you can fix yourself. To do so, follow the instructions in the following table. If it is still not possible to resolve the problem with the multifunctional tool, contact After Sales Support. -
Page 20: Technical Data
300W multifunctional tool Technical data Technical data Product-specific data Model number: CGN300D-1 Article number: 807615 Electrical data Supply voltage: 230–240 V~ Mains frequency: 50 Hz Power consumption: 300 W Idle speed n 15000-21000 min Physical data Dimensions without accessories and cords: 285 × 70 × 100 mm Weight without tools: 1.47kg AFTER SALES SUPPORT... -
Page 21: Noise⁄Vibration Information
300W multifunctional tool Noise/vibration information Noise⁄vibration information WARNING! Health hazard! High levels of noise and vibrations may result in injury. – Wear ear protection and suitable protective clothing when working with the device. Noise emission values Measured as per DIN EN 60745-1. The noise at your workplace may exceed 85 dB (A); protective measures are necessary in this case (wear suitable ear protection). - Page 22 300W multifunctional tool Noise/vibration information ATTENTION! The aforementioned vibration emission level (vibration value) has been measured in accordance with a test method standardised in DIN EN 62841 -1 and can be used to compare one power tool to another. It is also suited for preliminary estimation of loading by vibration.
-
Page 23: Disposing Of The Packaging
300W multifunctional tool Disposal Disposal Disposing of the packaging Dispose of the packaging separated into single type materials. Dispose of cardboard and carton as waste paper and foils via the recyclable material collection service. Disposing of old devices (Applicable in the European Union and other European states with systems for the separate collection of reusable waste materials) Old devices must not be disposed of with household waste! If the multifunctional tool can no longer be used, it must not be... -
Page 24: Service Notes
300W multifunctional tool Service notes Service notes • Store the multifunction tool, the user manual and, if applicable, the accessories in the original packaging provided. • FERREX® devices are largely maintenance-free. For notes on cleaning and maintenance, refer to the chapter “Cleaning and maintenance”. •... - Page 25 300W multifunctional tool Declaration of conformity Original EU Declaration of Conformity UK Declaration of Conformity MEROTEC GmbH Otto-Brenner-Str. 8, 47877 Willich, Germany herewith declare under our own, sole responsibility that our product Multifunctional tool Model no. CGN300D-1 complies with the following directives: 2006/42/EC Machinery Directive/ Supply of Machinery (Safety) Regulations 2008 2014/30/EU EMC-Directive / Electromagnetic Compatibility Regulations 2016 EMC-Directive 2011/65/EU*) RoHS, amended by (EU) 2015/863 / The Restriction of the Use of Certain Hazardous...
