  • Page 2 Welcome to the JOBOBIKE family! We are happy that you have chosen the HENRY JOBOBIKE This top-quality electric bike will give you comfortable and fun rides. This manual you have received contains the guide for assembling and using your bike.

  • Page 3: Manual Use Instruction

    Before you start using your new bike, it is necessary to read through the instructions. If you are unclear about any steps, you can always find additional information and instructions on our website: www.jobobike.pl The purpose of this manual is to inform you the safe ways to operate this bike.

  • Page 4: Table Of Contents

    Table of Contens Manual use instruction............................2 General Information............................4 Assembly Instructions............................9 Battery Charging..............................19 Operation.................................22 Maintenance..............................29 Troubleshooting...............................34 Warnings and Safety............................37 After Sales Policy .............................44...

  • Page 5: General Information

    JOBOBIKE recommends having a certified bike mechanic to check your work. NOTICE: If you do not have the experience, skill, or tools to assemble the bike, JOBOBIKE highly recommends having a certified bike mechanic to complete the assembling procedures as well as any future adjustments or tuning for you.
  • Page 6 NOTICE: A critical aspect of assembling your JOBOBIKE is securing the front wheel and checking the tightness of the rear wheel axle nuts. All JOBOBIKEs use quick-release front wheels with bolt on rear wheels. These mechanisms may become less secured during shipment and after use.
  • Page 7 E-bike to not conform with laws pertaining to operating your bike. Chargers produced by JOBOBIKE are the ONLY chargers that can be used for your bike. Using chargers that are NOT produced by JOBOBIKE would void your warranty. If any damages occur, our company does not take any responsibility.
  • Page 9 Accessory name Accessory name Accessory name Saddle Chain cover Suspension fork Seat post Spoke Front fender Seat post clamp Kickstand Front light Lock Headset Rear rack Chain Stem Rear light Middle motor Display Fender support Crank set Grips Rear fender Pedal Brake lever Brake rotor...

  • Page 10: Assembly Instructions

    If there are any missing parts, please contact Jobobike. S tep 2 install handlebar onto stemas shown in the assembly video for the Henry JOBOBKE located on the web page JOBOBIKE.pl/instructions/. Use 4# L-shaped wrench to loosen the four stem faceplate bolts. Place the handlebar on the stem correctly.
  • Page 11 Trace the front brake cable directly up from the front brake caliper to the left handlebar and ensure that the cables and wires are not twisted. Centre the handlebar and tighten the four stem faceplate bolts evenly. Adjust the stem angle using the Allen bolts on the side of the stem if desired. Adjust the handlebar so the grips are approximately parallel to the rear rack.
  • Page 12 S tep 3 Install the front wheel as shown in the HENRY Assembly Video available on the web page JOBOBIKE.pl/instructions/ 3.1. Put the E-bike in a safety, stable position – under the hard foam that came in carton box under the fork.
  • Page 13 Step 4 Install the front fender and headlight as shown in the assembly video available on the web page JOBOBIKE.pl/instructions/ 41. Remove the fender and headlight mounting bolt from the fork arch and set aside. 4.2. Place the fender in position.
  • Page 14 The right pedal is threaded to tighten by turning clockwise (towards the bike’s front). Carefully thread the right pedal onto the crank on the right side of the bike by hand. Do not cross thread or damage the threads. The left pedal is reverse-threaded and tightens counterclockwise (towards the bike’s back). Ensure that the remaining pedal has notches on the exterior of the axle and a “L”...
  • Page 15 Step 6: Inflate the tyres. Check that the tyre beads and tyres are evenly seated on the rims. Use a pump with a Schrader valve and pressure gauge to inflate each tyre to the recommended pressure value indicated on the tyre sidewall, 30-65 psi (2.0 – 4.5 bar). Do not overinflate or underinflate tyres.
  • Page 16 Step 9 Ensure all hardware is tightened properly following recommended torque values. Recommended Torque Values Hardware Location Hardware Torque Required (Nm) Handlebar Area Handlebar Stem Clamp Bolts Handlebar Area Handlebar Stem Faceplate Bolts Handlebar Area Brake Lever Clamp Bolt Handlebar Area Shifter Clamp Screw Brakes Calliper Adapter to Frame...
  • Page 17 Step 10 Review the remainder of the manual. Once the bike has been assembled following the instructions above, read, understand, and follow the procedures outlined in the remainder of the manual before operating the bike. NOTICE: If you have any questions regarding the assembly of your bike, contact JOBO Bikes. If you are unsure if all the assembly steps in the assembly video are performed properly, or you are unable to view the assembly video, please consult a certified local bike mechanic for assistance in addition to contacting JOBO Bikes for help.
  • Page 18 NOTICE: If you have any questions regarding the proper fit of your bike, please consult a certified local bike mechanic for assistance or contact JOBOBIKE. Adjusting the Seat Height For most users, the seat height should be set by placing the ball of their foot on the pedal when the pedal is at its lowest point.
  • Page 19 release properly, close the quick release lever fully so it looks like the image below and the seat cannot move up, down, to the left, or right. Before using the bike, always check to ensure all latches, levers, and quick releases are properly secured and undamaged.

  • Page 20: Battery Charging

    Battery Charging Charging Procedure: The battery can be charged both when it is located inside of the frame or when you take it out of the frame. 1. When battery is located inside of the frame: a. Turn E-bike power off. b.
  • Page 21 • Always charge in a safe place that is cool, dry, indoors, away from direct sunlight, dirt, or debris, in a clear area away from potential to step on the charging cords and possible damage to the bike, battery, or charging equipment while parked and/or charging. Always charge your battery when the surrounding temperature is between 10 °C–25 °C (50 °F–77 °F).
  • Page 22 Use caution to avoid damage to battery connector terminals, which are exposed when the battery is unlocked or removed from the frame of the bike. In the case of damage to the terminals or battery mounts, please discontinue the use of your bike and contact JOBOBIKE Product Support immediately.

  • Page 23: Operation

    JOBO Bikes Product Support. Charge the battery only with the charger originally supplied with the bike, or a charger purchased directly from JOBOBIKE, designed for your specific bike serial number. Never use an aftermarket charger, which can result in damage, serious injury, or death.
  • Page 24 accidents, injury to you and others, damage to the bike, damage to your property, injury, or death. Contact JOBO Bikes if you have any questions about assembly or operation. Users must become accustomed to the bike’s power control system before operating. Handlebar Features 1 LCD Display Remote 2 Bell...
  • Page 25 Mode select: single-trip distance (TRIP) → total distance ODO → maximum speed (MAX) → average speed (AVG) →remaining distance (RANGE) → energy consumption (CALORIES) → time (TIME). 6. Battery level display: Display current battery level value. 7. Voltage display/percentage display: Display actual voltage level value;...
  • Page 26 Press the power button to turn on the E-bike system.When holding the power button for 2s, the E-bike system would be switched off. When turned off, the E-bike system no longer uses battery power.When parking the E-bike for more than 10 minutes, the E- bike system switches off automatically.
  • Page 27 We suggest that you select a lower assistance level when you first get your bike from JOBOBIKE to get to know your bike and travel routes.
  • Page 28 Total maximum payload: 1 30 kg (2 86 lb) Optional rear rack maximum payload: 18 kg (39 lb) Optional front rack maximum payload: 10 kg (22 lb) You MUST hold onto the bike when loading passengers or cargos. The kickstand is not designed to be used for loading passengers or cargos. Do not assume the bike is stable and balanced when using the kickstand.
  • Page 29 Do not use the front brake by itself. Apply the rear brake first, and then the front brake. Use both brakes for all braking operations. Braking with only the front brake can cause excessive stress on components, damage to the bike and parts, and/or loss of control.

  • Page 30: Maintenance

    Maintenance Basic Bike Care To ensure safe riding conditions, you must maintain your bike properly. Follow these basic guidelines and see a certified bike mechanic at regular basis to ensure your bike is safe for use and comfortable to ride. See the Safety Checklist and Recommended Service Intervals sections of this manual for more detailed information.
  • Page 31 - Check hardware for proper torque:See - Clean frame by wiping frame - Replace any components Recommended Torque Values chart. down with damp cloth. confirmed by JOBOBIKE - Check drivetrain for proper alignment and - Use barrel adjuster(s) to Technical Support or a Weekly...
  • Page 32 Before every ride, and after every 32-80 km (20-50 mi), we recommend following this safety checklist. Safety Check Basic Steps Ensure that front and rear brakes work properly. Check brake pads for wear and ensure that they are not over worn. Brakes Ensure that brake pads are correctly positioned in relation to the brake rotors.
  • Page 33 Proper inflation, care, and timely replacement ensure that your bike’s operational characteristics are maintained, avoiding unwanted, unsafe situations. JOBOBIKE recommends 30 - 65 psi/2.0 – 4.5 bar for both the front and rear tyres. Always stay within the manufacturer’s recommended air pressure range as listed on the tyre...
  • Page 34 It is critically important that proper air pressure is always maintained in pneumatic tyres. Do not underinflate or overinflate your tyres. Low pressure may result in loss of control, and overinflated tyres may burst. Failure to always maintain the air pressure rating indicated on pneumatic tyres may result in tyre and/or wheel failure.

  • Page 35: Troubleshooting

    Troubleshooting Symptoms Possible Causes Most Common Solutions 1. Insufficient battery power 1. Charge the battery 2. Faulty connections 2. Clean and repair connectors The bike does not work 3. Battery not fully seated in tray 3. Install battery correctly 4. Improper turn on sequence 4.
  • Page 36 Error code Detection Your bike is equipped with an error detection system integrated into the display and controller. In the case of an electronic control system fault, an error code should display. The following error codes are the most common and can aid troubleshooting. If your bike has an error code displayed at any time, it is recommended that you cease operation and contact JOBOBIKEs immediately.
  • Page 37 1. Restart the system 2. Check that the magnet attached to the spoke is aligned with the speed sensor and that the distance is between 10 mm and 20 mm. 3. Check that the speed sensor connector is connect edcorrectly. Error with wheel speed detecting sensor 4.

  • Page 38: Warnings And Safety

    1. Check if all connections on the pedelec are correctly connected. 2. Use the BESST Tool to run a diagnostics test, to see if it can pinpoint the problem. Communication problem 3. Change the display to see if the problem is solved. 4.
  • Page 39 • Be careful at intersections when preparing to pass other vehicles or other cyclists. •Familiarize yourself with all features and operations of the bike by JOBOBIKE. Practice and become proficient at shifting gears, applying brakes, using power assist system, and using twist power assist in a controlled setting before riding in riskier conditions.
  • Page 40 •Maintain a comfortable stopping distance from all other objects, riders, and vehicles. Safe braking distances vary based on factors such as road surface and lighting conditions. Safety Notes The following safety notes provide additional information on the safe operation of your bike and should be closely reviewed. Failure to review these notes can lead to serious injury or death.
  • Page 41 riding, including but not limited to jumps, stunts, etc., should not be performed as it can damage your bike’s components and/or cause or lead to dangerous riding situations in which you may be seriously injured or killed. • Failure to perform and confirm proper installation, compatibility, proper operation, or maintenance of any component or accessory can result in serious injury or death.
  • Page 42 ride, regardless of age. If you have an impairment or disability such as a visual impairment, hearing impairment, physical impairment, cognitive/language impairment, a seizure disorder, or any other physical condition that could impact your ability to safely operate a vehicle, consult your physician before riding any bike.

  • Page 43: After Sales Policy

    Return policy Should your purchased Jobobike model not meet your needs (such as the size of the bike not being suitable for you) you can return it back to us within 14 days from the delivery date. When returning your ebike, please mind that it must be re-sent in the original box and be in the exact same condition in which it was sent (it cannot be scratched, dirty, etc.).
  • Page 44 If you have any more questions, please contact JOBOBIKE Technical Support Team at support@jobobike.pl or using contact form at www.jobobike.plThe guarantee can not be claimed if changes have been made to the original construction, if the wheel is not used as intended or if there is any other overuse. Also, there is no claim for late damage resulting from previous falls or...
