Summary of Contents for Boundaryline SMARTWALL
- Page 1 SMARTWALL STEP-BY-STEP GUIDE A STEP-BY-STEP GUIDE TO INSTALLING YOUR FENCE INSTALL GUIDE...
-
Page 2: Tools List
STEP-BY-STEP GUIDE INTRODUCTION The recommendations detailed If you have any questions, Thank you for choosing Boundaryline SmartWall in this guide are formulated please contact our Technical along the lines of good Team on 0800 003 006. We Fencing. This product will building practice. - Page 3 If it isn’t possible to fix posts as Support post with temporary brace proposed here, please contact Fill hole with fully mixed, wet concrete us for further information. Vibrate and compact the concrete to remove voids. IMPORTANT 0800 003 006 boundaryline.co.nz...
- Page 4 Screw fix the bottom rail at this stage. NOTE Bottom rail SmartWall Vertical fence system is supplied with a Rail Support and this between is to be inserted inside the bottom rail prior to it being installed. C posts b.
- Page 5 STEP 4 – INSTALLING POST CAPS All SmartWall caps are supplied as a ‘double’ cap, which are designed to be snapped in half to create two single caps where required. Cut each side of the cap in line with the centre ridge.
-
Page 6: Technical Drawings
STEP-BY-STEP GUIDE TECHNICAL DRAWINGS SMARTWALL VERTICAL 10:1 POST CAPS 275.0 28.0 TOP RAIL CLT LAMINATED PALING 15.0 15.0 SCREW POST 10:1 POST CAP POST TOP RAIL CLT LAMINATED PALING 28.0 1800.0 2400.0 2250.0 POST CENTRE SLOPE TOP OF CONCRETE TO ALLOW... - Page 7 STEP-BY-STEP GUIDE TECHNICAL DRAWINGS SMARTWALL HORIZONTAL POST 10:1 POST CAPS TOP RAIL 10:1 POST CAP TOP RAIL CLT LAMINATED PALING 15.0 SCREW VERTICAL BEAD POST CLT LAMINATED PALING 275.0 VERTICAL BEAD 1800.0 2400.0 28.0 1830.0 SLOPE TOP OF 'GOOD GROUND' 100KPA...
- Page 8 CONTACT BOUNDARYLINE FENCING SmartWall Fencing is designed to withstand most wind conditions. The wind on the fence at your site will depend on a number of factors, including the number of surrounding properties and how exposed the location is. If your property is exposed to higher wind speeds, please contact us for further advice/recommendations.
