- Page 1 ELITEWALL STEP-BY-STEP GUIDE A STEP-BY-STEP GUIDE TO INSTALLING YOUR FENCE INSTALL GUIDE...
- Page 2 1.8m, please seek further Make sure you are aware of Check the delivered material advice from Boundaryline. underground services before for the correct number of Describe your site details you start digging! These could components and general when ordering materials.
-
Page 3: Components List
END POST CAPPING & MASONRY ANCHOR EXTERNAL POST T TOP CAPPING CHANNEL SUPPORT BRACKET WALL PANEL 50MM FLUSH POST TOP ALUMINIUM JOINER AND 70MM END POST WITH WALL PANEL & JOINER END POST INFILL POST INFILL 0800 003 006 boundaryline.co.nz... -
Page 4: Post Installation
Cyclonic wind area, on the top of a hill, adjacent to an escarpment, on a ridge, or in terrain category 1, you will need engineering advice beyond the scope of this publication. 0800 003 006 boundaryline.co.nz... - Page 5 1200mm * 3000mm high walls may not be suitable for all regions. Please consult Boundaryline prior to the design stage so we can ascertain if additional materials are required example – Shortened free end spacing’s, deeper footings, core filling of posts etc.
- Page 6 IMPORTANT If you are installaing a Boundaryline Wall within 1.5 Kilometers from the seaside we reccomend to apply a bitumen sealer to the post. The area to apply the bitumen coating to will be 100mm above the concrete line and 100mm below where the concrete will finish on the post.
- Page 7 If you have a wall with Flush Capping, take 25mm off the above Flush Capping* heighhts Suggested cleat height for your new wall SUPPORT BRACKET TEK SCREW We recommend to go for the expossed join look as it gives a far superior finish to the complete wall. IMPORTANT 0800 003 006 boundaryline.co.nz...
- Page 8 Alternatively you can use a tape measure between the face of the posts and use something rigid to sit across the top of the posts to sit the spirit level on. POST CENTRES 2350 SPACER 2410 NOTE: This example is based on a 2400mm panel being installed. 0800 003 006 boundaryline.co.nz...
-
Page 9: Panel Installation
8mm rebate panels. 20mm rebate 8mm rebate HOW TO ACHIEVE A STANDARD 20mm rebate JOIN Insert the Aluminium Box Section aluminium box section into the 20mm 20mm rebate rebate in the panels. 8mm rebate CAPPING CHANNEL 0800 003 006 boundaryline.co.nz... - Page 10 If it does not align correctly with light downward pressure it may be necessary to ‘Tap’ the top panel down using a heavy block of wood in a ‘pivoted slapping action’ to bring it together completely, see picture below. 0800 003 006 boundaryline.co.nz...
- Page 11 NOTE: - These are designed to be inserted with a small amount of force. Where your wall is stepped, this insert can be cut to size to suit the step and inserted in the exposed recess. 0800 003 006 boundaryline.co.nz...
- Page 12 Seal around the post top with an exterior (paint able) polyurethane sealant prior to painting (Sika flex pro is recommended). This will provide a water tight seal and prevent the top from lifting with expansion and contraction. Finished sealed and painted 0800 003 006 boundaryline.co.nz...
-
Page 13: Additional Information
Support bracket height = Normal Example of a 100mm fall over this distance placement for a 1800mm wall Support bracket height = Normal placement for a 1800mm wall + 100mm for step in wall 0800 003 006 boundaryline.co.nz... - Page 14 1800mm wall on both sides of the post Cut panel to suit the slope of the ground NOTE: On a large rake/slope a longer base channel maybe required. Cutting of a panel to suit a 100m rake/slope. 0800 003 006 boundaryline.co.nz...
- Page 15 Cut panel to suit the slope of the ground NOTE: On a large rake/slope a longer base channel maybe required. Cutting of a panel to suit a 100m rake/slope. 0800 003 006 boundaryline.co.nz...
- Page 16 The 2 halves of the post extension will not quite meet in the middle of the post, this is to allow a small amount of concrete to enter the centre of the post before actual core filling. 0800 003 006 boundaryline.co.nz...
- Page 17 ‘cutting in’ dry and apply a second ‘cutting in’ coat prior to the second and final roller coat. On a large job a spray application may be justified. Please see the paint manufacturer for advice on spray application. 0800 003 006 boundaryline.co.nz...
- Page 18 Prepare the surface by ensuring that the Fibre Cement Panels are clean, dry and free of contaminants. This can be achieved by means of a brush down with a stiff brush or rubbing lightly with a ‘Scotch Bright’ pad. 0800 003 006 boundaryline.co.nz...
- Page 19 0800 003 006 boundaryline.co.nz...
