D
We reserve the right to change or revise specifications
and product design in connection with any feature of
our products. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
Item Part #
Description
F
A
T
AN
SSEMBLIES AND
HERMOSTATS
,
8 Ft, 10 Ft, 12 Ft
14 Ft & 16 Ft
A. 12W Standard Fan Assembly
0047000
Fan Motor, Evaporator
(MO.4410103)
0142780
Fan Blade (FB.0142780)
embossing toward motor
12W Energy Efficient Fan Assembly
0477655
Fan Motor, Evaporator
(MO.4410546)
0142780
Fan Blade (FB.0142780)
embossing toward motor
B. Optional Adjustable Refrigeration Thermostat (2)
0448347
(CT.4481631)
Note: Revision C changed the ballast information on Pages 1 and 6.
©2006 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
®
B
A
Wiring Item #
(1)
(1)
C
Item Part #
Description
L
B
AMPS AND
ALLASTS
C. Ballast, Electronic
0459491
Canopy (BA.4481566)
D. Ballast, Electronic
0447739
T5 Shelf Lamp (BA.4480900)
0466234
T8 Shelf Lamp (2) (BA.4480823)
0466235
T8 Shelf Lamp (3) (BA.4480901)
E.
Fluorescent Lamp
Replace with like fixtures
RI4
Technical Data Sheet
P/N 0492425_C
NSF
®
Certified
January 2007
E
Serial Plate
Wiring Item #
P/N 0492425_C
(3)
(4)
(5)
Advertisement
Table of Contents
Related Manuals for Hussmann RI4
Summary of Contents for Hussmann RI4
- Page 1 0448347 (CT.4481631) Note: Revision C changed the ballast information on Pages 1 and 6. ©2006 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM ® Wiring Item # Item Part # AMPS AND C.
- Page 2 Schedule 40 PVC drip pipe Refrigeration Outlet LH end of case to center of refrigeration outlet RH end of case to center of refrigeration outlet 2 of 6 HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A. Refrigeration & Coil Stubout Drains Front...
-
Page 3: Load Limit Profile
Air flow between the shelves, from the CAD to the return, must be maintained at all times for optimum operating efficiency and to prolong product shelf life. At no time should merchandisers be stocked beyond the load limits indicated. P/N 0492425_C HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM 1 /8 (1019) 13451-... -
Page 4: Electrical Data
115V Lighting Circuit Total = Standard Lighting + Total Optional Lighting + Optional Shelf Lighting 230V Lighting Circuit Total = Multiply 115V Lighting Circuit Total by 4 of 6 HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A. 8 ft 10 ft 12 ft... - Page 5 All components must have mechanical ground, and the merchandiser must be grounded. R = Red Y = Yellow G = Green BL = Blue B = Black W = White = 120V P OWER P/N 0492425_C HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM Fans WARNING IRCLED NUMBERS ARTS...
- Page 6 R = Red = 120V P = 120V N OWER 6 of 6 HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A. RANGE OR WARNING Circled Numbers = Parts List Item Numbers G = Green BL = Blue B = Black W = White...
