Item Part #
Description
F
A
T
AN
SSEMBLIES AND
HERMOSTATS
,
8 Ft, 10 Ft, 12 Ft
14 Ft & 16 Ft
A. 12W Standard Fan Assembly
0047000
Fan Motor, Evaporator
(MO.4410103)
0142780
Fan Blade (FB.0142780)
embossing toward motor
12W Energy Efficient Fan Assembly
0477655
Fan Motor, Evaporator
(MO.4410546)
0142780
Fan Blade (FB.0142780)
B. Optional Adjustable Refrigeration Thermostat (2)
0448347
(CT.4481631)
Note: Changed items are underlined.
©2006 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
B
A
Wiring Item #
(1)
(1)
®
E
Item Part #
H
EATERS
C.
0487118
L
B
AMPS AND
ALLASTS
D. Ballast, Electronic
0355398
0355716
0447740
E.
Technical Data Sheet
P/N 0492427_B
NSF
®
Certified
October 2006
C
E
Serial Plate
Description
Wiring Item #
Anti-Sweat Heater
(HE.4850668)
(BA.4480118)
(BA.0355716)
(BA.4481278)
Fluorescent Lamp
Replace with like fixtures
P/N 0492427_B
RI2
(3)
(4)
(5)
