Summary of Contents for W-Tec Teneur 10
- Page 1 USER MANUAL – EN IN 22340 E-scooter W-TEC Teneur 10”...
-
Page 2: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS ........................3 PRODUCT DESCRIPTION ........................4 CONTROL PANEL ..........................5 DISPLAY ..............................5 DISPLAY .............................. 6 SETTINGS ............................7 FOLDING AND UNFOLDING ........................9 BATTERY ..............................9 BATTERY CAPACITY ........................10 BATTERY CHARGING .......................... 10 USE ............................... 10 RIDING TECHNIQUE .......................... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS • Read the manual carefully and keep it for future reference. • The scooter is designed to carry one person at the same time. • Wear a helmet and other protective equipment, incl. proper boots. • Do not ride on dangerous or ineligible roads. •... -
Page 4: Product Description
• Weight limit: 120 kg PRODUCT DESCRIPTION Quick release lever Button for folding / unfolding the handlebars Charging port Footboard Reflections Drive Stand Front wheel Brake Light Display Speed control lever Brake Handle Brake Light control Flashing light... -
Page 5: Control Panel
Horn CONTROL PANEL Turn on / off Mode Battery indicator Press the button for 3 seconds to turn on. Once the scooter is running, pressing the button, the gear level will start flashing and use the Mode button to adjust the gear (1, 2 and 3). To turn off, press the button for 3 seconds. -
Page 6: Display
DISPLAY Battery status Multi-function area display • ODO – total mileage • TRIP – current mileage • V – real time voltage • TIME – operation time • E – error code If error starts to flicker, press ON/OFF button, the display will show current error message ERRO 1 Motor problem ERRO 2... -
Page 7: Settings
Gear • Press MODE to change gear from 0 to 3 highest (highest gear allows you to increase speed limit) Headlight • Hold the MODE button to turn on/off headlight. Cruise control • After riding in constant speed for 5 seconds, cruise symbol will show and turn on. If you want to turn off the cruise control, speed up or slow down. - Page 8 0 off P16 Cruise control 1 on When you enter P99 setting, hold MODE button P99 Restore default setting for 5-6 seconds When you enter ODO settings, press MODE and ODO Reset total distance then hold it for 5-6 seconds To turn on the scooter, press ON/OFF button.
-
Page 9: Folding And Unfolding
FOLDING AND UNFOLDING 1. Raise the handlebars slightly 2. Press the button 3. Raise the handlebars 4. Unfold the handles 5. Set the desired handlebar height To fold, repeat the steps in reverse order of the layout BATTERY 6-month battery warranty – we guarantee that battery's nominal capacity does not fall below 70% of its total capacity within 6 months of the product’s sale. -
Page 10: Battery Capacity
• Battery lifespan is limited. If you use a battery that exceeds normal lifespan, the charging frequency may increase, and the scooter range will be reduced. • Do not open or throw of the battery in a fire. Do not insert foreign objects into the battery. •... -
Page 11: Riding Technique
• Moisture reduces braking efficiency. RIDING TECHNIQUE • Know the scooter before first use and test your ability to control this product. • Turn continuously and brake safely having enough free space. • Practice your first ride in an open area without obstacles. •... -
Page 12: Technical Specifications
TECHNICAL SPECIFICATIONS Wheel size 10“ Speed 35-40 km/h Charging time 6-7 h Power 500W Charger INPUT 100-240VAC / 50 ~ 60HZ, OUTPUT DC54,6V / 2A Battery 48V 13Ah Range 35 km 15° Maximum incline Maximal load capacity 120 kg Weight 19,2 kg Folded dimensions 110x26x37 cm... - Page 13 “The Buyer who is the End Customer” or simply the “End Customer” is the legal entity that does not conclude and execute the Contract in order to run or promote his own trade or business activities. “The Buyer who is not the End Customer” is a Businessman that buys Goods or uses services for the purpose of using the Goods or services for his own business activities.
- Page 14 The Seller shall settle the Warranty Claim within 30 days after the delivery of the defective Goods, unless a longer period has been agreed upon. The day when the repaired or exchanged Goods is handed over to the Buyer is considered to be the day of the Warranty Claim settlement. When the Seller is not able to settle the Warranty Claim within the agreed period due to the specific nature of the Goods defect, he and the Buyer shall make an agreement about an alternative solution.
