Hardware; Assembly Instructions - LOCO COOKERS LCTFKESB30 Owner's Manual & Assembly Instructions

Tools required: Phillips head screwdriver • Adjustable wrench
A
M5x10 Screw
1
A
x4
NOTE: Electrode and sensor wires not pictured for
2
clarity of illustration. Remove factory zip ties from
wires during assembly and before lighting burner.
A
NOTE: Remove hex nut
x4
from sensor and attach to
tab on burner.
8

ASSEMBLY INSTRUCTIONS

Assembly Hardware
5
A
9
B
8 M5x30 Screw
7
A
A
(Not included)
4
A
CAUTION: Make sure
valve orifi ce fi ts inside
of burner tube.
9
