E
(Optional
Lights)
Item
Part #
Description
F
A
T
AN
SSEMBLIES AND
HERMOSTATS
A.
0392457
Fan Motor, Evaporator (120V)
0425336
Fan Blade (120V)
embossing toward motor
0436517
Fan Motor, Evaporator (220V)
0440141
Fan Blade (220V)
embossing toward motor
B.
0404551
Fan Motor, Ambient (120V)
0404552
Fan Motor, Ambient (220V)
C.
0137880
Optional Adjustable
Refrigeration Thermostat
Note: Changed items have been underlined.
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
®
Merchandisers
B
Wiring Item #
T'Stat Bulb
Location
C
A
Item
Part #
L
B
AMPS AND
ALLASTS
(1)
D.
0355716
D.
0355398
D.
0440215
D.
0428652
(2)
0385104
(3)
E.
SMGT
Data Sheet Set
P/N 0420064A
NSF
®
Certified
May, 2003
D
Description
Wiring Item #
Ballast, Electronic, 2 lamps
(120V)
Ballast, Electronic, 3 lamps
(120V)
Ballast, Electronic, 2 lamps
(230V 50-60 Hz)
Ballast, Electronic, 3 lamps
(230V 50-60 Hz)
Ballast Transformer
(230V 50-60 Hz, per ballast)
Fluorescent Lamp
Replace with like fixtures
P/N 0420064A
(4)
(5)
(4)
(5)
(6)
