Hussmann SMBT Technical Data Sheet

F
C
(Optional
Lights)
We reserve the right to change or revise specifications
and product design in connection with any feature of
our products. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
Item Part # Description
F A T
AN SSEMBLIES AND HERMOSTATS
A. 0392457 Fan Motor, Evaporator (120V)
(MO.4410101)
0409512 Fan Blade (120V) (FB.0409512)
embossing toward motor
0436517 Fan Motor, Evaporator (220V)
(MO.4410105)
0409513 Fan Blade (220V) (FB.0409513)
embossing toward motor
B. 0404551 Fan Motor, Ambient (120V)
(MO.0404551)
0404552 Fan Motor, Ambient (220V)
(MO.4410590)
C. 0382028 Standard Non-adjustable
Defrost Thermostat
(CT.0382028)
D. 0137880 Optional Adjustable
Refrigeration Thermostat
(CT.4481084)
Note: Changed items have been underlined.
©2007 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
®
Merchandisers
B
Wiring Item #
T'Stat Bulb
Location
A
Item Part #
L B
AMPS AND ALLASTS
(1) E. 0355716
E. 0355398
E. 0440215
E. 0428652
0385104
(2)
F.
(3)
(4)
SMBT
Technical Data Sheet
P/N 0420063_B
D NSF
®
January 2007
E
Description Wiring Item #
Ballast, Electronic, 2 lamps
(120V) (BA.0355716)
Ballast, Electronic, 3 lamps
(120V) (BA.4480118)
Ballast, Electronic, 2 lamps
(230V 50-60 Hz) (BA.4481267) (5)
Ballast, Electronic, 3 lamps
(230V 50-60 Hz) (BA.4480897) (6)
Ballast Transformer
(230V 50-60 Hz, per ballast)
(TR.4481191)
Fluorescent Lamp
Replace with like fixtures
P/N 0420063_B
Certified
(5)
(6)
(7)
