We reserve the right to change or revise specifications
and product design in connection with any feature of
our products. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
Item Part #
Description
F
A
T
AN
SSEMBLIES AND
HERMOSTATS
A. 4W Fan Assembly
0392457
Fan Motor, Standard (MO.4410101)
0409511
Fan Blade, embossing toward motor
(FB.0409511)
B. Optional Adjustable Refrigeration Thermostat
C. 0398557
Defrost Termination Thermostat
(Front)
(CT.4440611)
0398558
(Electric Defrost only)
(Rear)
D. 0425304
Heater Switch
(Koolgas Defrost only)
H
EATERS
E. Control-Glass Anti-sweat Heaters (Export)
Contour Ends 250V, 5amp
0400543
8 & 12 foot cases (CT.4480905)
F. 0395709
Modular Electric
Defrost Heaters, 208V
(HE.4850409)
NOTE: Revision D corrects heater data on Page 4.
©2007 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
®
Merchandisers
C
A
C
I
B
D
Wiring Item #
(CT.4481088)
(CT.0425304)
F
E
Item Part #
H
(
EATERS
CONTINUED
(1)
G. Drip Pan Heaters, Electric 208V
0392413
0392414
Drip Pan Heaters, Koolgas 120V
0421238
(2)
0421239
(3)
H. Nosing Anti-sweat Heaters
0401605
(4)
0401606
I.
Multiglass - 2 Pane, w/heater
(5)
0420156
0420157
0420184
(6)
LWGH
Technical Data Sheet
P/N 0409827_D
NSF
®
Certified
February 2007
G
H
D
Description
Wiring Item #
)
8 foot case (HE.0392413)
12 foot case (HE.0392414)
8 foot case (HE.4850496)
12 foot case (HE.4850497)
8 foot case (Discharge)
(HE.0401605)
12 foot case (Discharge)
(HE.4850471)
(Front & Rear)
8 foot case (GL.4985203)
12 foot case (GL.4985204)
Contour end (GL.4985218)
P/N 0409827_D
(7)
(8)
(9)
(10)
