Item Part #
Description
F
A
T
AN
SSEMBLIES AND
HERMOSTATS
A. 4W Fan Assembly
0392457
Fan Motor, Standard (MO.4410101)
0409511
Front & Rear — Fan Blade
embossing toward motor (FB.0409511)
0409513
End Compartment — Fan Blade
embossing toward motor (FB.0409513)
B. Optional Adjustable Refrigeration Thermostat
C. Defrost Termination Thermostat
(Electric Defrost only)
0398557
Front & End Compartment
(CT.4440611)
0398558
Rear (CT.4481088)
D. 0425304
Heater Switch
(Koolgas Defrost only)
H
EATERS
E. Modular Electric Defrost Heaters, 208V
0395709
Parent (HE.4850409)
0406444
End Compartment (HE.4850478)
NOTE: Revision J corrects heater data on Page 4.
©2007 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
®
Merchandisers
D
Wiring Item #
(CT.0425304)
C G
D
B
Item Part #
H
(C
EATERS
ONTINUED
(1)
F. Drip Pan Heaters, Electric 208V
0392412
0392413
0392412
F. Drip Pan Heaters, Koolgas 120V
0421237
(2)
0421238
0421237
(3)
G. Nosing Anti-sweat Heaters
0401603
0401555
0401605
(4)
0401557
0401612
(5)
0401555
LWU
Technical Data Sheet
P/N 0395741_J
NSF
®
Certified
February 2007
D
E
F
C
Description
Wiring Item #
)
90 inch case (HE.4850461)
138 inch case (HE.0392413)
End Compartment (HE.4850461)
90 inch case (HE.4850495)
138 inch case (HE.4850496)
End Compartment (HE.4850495)
90 inch case (Discharge)
(HE.4850470)
90 inch case (Return) (HE.4850465)
138 inch case (Discharge)
(HE.0401605)
138 inch case (Return) (HE.4850467)
End Compartment (Discharge)
(HE.0401612)
End Compartment (Return)
(HE.4850465)
P/N 0395741_J
(6)
(7)
(8)
