NinjaTrac
Order and Installation Manual
For models from February 2022 onwards
Rugged Interactive
Unit 1, Callywith Court
Callywith Industrial Estate, Bodmin
Cornwall, UK
PL231 2RQ
+44 (0) 1726 981 123
www.rugged-interactive.co.uk
hello@rugged-interactive.co.uk
Updated 13/01/2023
© Rugged Interactive
2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NinjaTrac and is the answer not in the manual?

Questions and answers

Related Manuals for Rugged Interactive NinjaTrac

Summary of Contents for Rugged Interactive NinjaTrac

  • Page 1 NinjaTrac Order and Installation Manual For models from February 2022 onwards Rugged Interactive Unit 1, Callywith Court Callywith Industrial Estate, Bodmin Cornwall, UK PL231 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk Updated 13/01/2023 © Rugged Interactive 2022...

  • Page 2: Table Of Contents

    2.2 In Play Safety Guidelines Section 3 – Installation 3.1 Parts List 3.2 Tools and Components List 3.3 Installation Overview 3.4 Detailed Installation Section 4 – How to Use Section 5 – Programs Guide NinjaTrac System Specifications NinjaTrac Installation Checklist © Rugged Interactive 2022...

  • Page 3: Section 1 - Ordering Process

    Installation manual purpose and limitations This manual is intended to provide guidance only, the installation of the Rugged Interactive product will be under your control. You will be responsible for making sure, upon completion of the installation, it is safe to use.

  • Page 4: Order And Installation Checklist

    1.2 - Order and Installation Checklist ☐ Contact the Rugged Interactive sales team or a partner / distributor to begin the process. Confirm the invoice and delivery address along with date required (lead time is at least 5 weeks), ☐...

  • Page 5: Ordering And Installation Timeline

    1.3 - NinjaTrac Overview Add an exciting, interactive element to your indoor play centre. NinjaTrac is a versatile test of speed, fitness and accuracy, encouraging competition and the motivation to “ninja run” for longer. Players race down the course, being sure to hit the pods on the way as every missed pod will incur a 10 second time penalty, before hitting the final pod to stop the timer.

  • Page 6: Getting Started

    If further information is required, please get in touch and we will be able to provide further information and guidance. 1.6 - Place Order To begin the order process with Rugged Interactive: Email: Sales@rugged-interactive.co.uk Or call the Sales Office:...

  • Page 7: Section 2 - Safety Guidelines

    Tidy back loose cables that could become a tripping hazard. § § Ensure that the playing area is clear. § Immediately inform Rugged Interactive for maintenance advice if you have concerns. Don’ts: Do not wear shoes unsafe for play within a ninja run. § §...

  • Page 8: In Play Safety Guidelines

    NinjaTrac Installation and Instruction Manual: Safety Guidelines 2.2 In Play Safety Guidelines Please ensure you read the following points before using the equipment: This activity can be great fun, but it can also be dangerous. There is a risk of serious injury if care is not taken when using the equipment.
  • Page 9 NinjaTrac Installation and Instruction Manual: Safety Guidelines Don’ts: § No more than one active user on the equipment within one lane at any one time. § Do not attempt to use any of the equipment without undertaking instruction / training carried out by an appropriate instructor.

  • Page 10: Section 3 - Installation

    +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk Section 3 - Installation 3.1 - Parts List Please check off the received parts for the installation and alert Rugged Interactive immediately if anything is missing. 1 x Control Box ☐ 1 x Hub Box * ☐...
  • Page 11 NinjaTrac Order and Installation Manual: Installation Required Tools ☐ Cordless drill – with torque adjuster to avoid over-tightening the screws. ☐ A set of No.2 Pozi bits. ☐ A set of screwdrivers. ☐ Jigsaw. ☐ A set of Hex keys ☐...

  • Page 12: Installation Overview

    3.3 - Installation Overview Below is an overview of the steps needed to install NinjaTrac. More detail for the process is provided in the following pages. Please read through ALL of this prior to beginning the installation and if you are in any doubt, contact Rugged Interactive.

  • Page 13: Detailed Installation

    Installation Guidelines: § Complete the Site Survey form prior to delivery and/or installation. § Send a completed Installation Checklist after any installation to Rugged Interactive. § A typical installation should take 2 people about 1 day. § No obstructions or protrusions in the installation area: e.g., skirting boards, pipes, cables and wiring conduits.
  • Page 14 Instruction / training carried out by an appropriate instructor to all new users. A waiting / spectating area positioned nearby is advised. § IF YOU ARE IN ANY DOUBT, CALL RUGGED INTERACTIVE DIRECTLY ON +44 (0) 1726 833 882. NinjaTrac – Section 3 - Installation ©...
  • Page 15 NinjaTrac Order and Installation Manual: Installation HUB and Control Box Installation § Fix HUB or Control Box using any suitable self-tapping or wood screws into the surface material. § Both boxes can be mounted in a position that is out of the activity zone.
  • Page 16 NinjaTrac Order and Installation Manual: Installation NinjaTrac Installation Pods: Pods should be mounted onto a wall using the three 6 mm mounting points on each pod using the supplied wood screws. Figure 3.4.1 shows a typical Pod installation. Plywood Base Layer (if applicable)
  • Page 17 NinjaTrac Order and Installation Manual: Installation Pods to Score Box (HUB) Installation Notes: § All supplied CAT5 cables will be numbered. Attach correctly numbered cable to the designated Hanging cable exiting the rear of the HUB. The hanging cables will be numbered from 1 Attach CAT5 cables from the pods to HUB.
  • Page 18 NinjaTrac Order and Installation Manual: Installation Large Display Screen Installation § The screen should be installed in suitable a position, these screens will display the in-game scores. § Screens should be positioned in easily visible positions that users will not come into contact with.
  • Page 19 NinjaTrac Order and Installation Manual: Installation Touchscreen Installation § The touchscreen is used to start the games and to add names to the leaderboard. § The touchscreen should be positioned in an easy to reach location. § The touchscreen must be within 3 meters of the control box.
  • Page 20 NinjaTrac Order and Installation Manual: Installation Insert and tighten screws. Ensure all is tight and Avoid trapping cables and align the front to the secure. backplate NOTE: This is the control panel for the system and will required to start games and for leaderboard data entry.
  • Page 21 NinjaTrac Order and Installation Manual: Installation Connecting the NinjaTrac System § All cables will be supplied. Only Supplied with Duo Max 60m Max 60m 9 x Pods 9 x Pods Figure 3.4.2: Typical NinjaTrac Installation NinjaTrac – Section 3 - Installation ©...
  • Page 22 NinjaTrac Order and Installation Manual: Installation Figure 3.4.3: Typical NinjaTrac Duo Installation Note, the touchscreen must be at the start of the course for game start and data entry, the touchscreen must be within 3m of the Control Box and the display screen within 30m of the Control Box.

  • Page 23: Section 4 - How To Use

    At the end of a game, the score will be shown on the display screen. Check the leaderboard to see where you stand. NOTE: At any time, if the NinjaTrac behaves unexpectedly, wait for at least 30 seconds for the unit to reset to its idle state.

  • Page 24: Section 5 - Programs Guide

    +10 second for each pod missed. Duration: Unlimited NOTE: At any time, if NinjaTrac behaves unexpectedly during gameplay, wait for at least 30 seconds for the unit to reset to its idle state. NinjaTrac – Section 5 - Programs Guide ©...

  • Page 25: Ninjatrac System Specifications

    Rugged Interactive Unit 1, Callywith Court, Callywith Industrial Estate, Bodmin, Cornwall, UK PL31 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk NinjaTrac System Specifications Dimensions and Weights: Approx. Shipment Details Fully Assembled Details Size (mm) Weight Size (mm) Weight Pod (single unit) 205 Ø...
  • Page 26 NinjaTrac Order and Installation Manual: System Specifications 120° Figure 1: Pod Mounting Points (Dimensions in mm) Figure 2: Pod Dimensions (Dimensions in mm) NinjaTrac - System Specifications © Rugged Interactive 2022...
  • Page 27 Power Supply Specification for 5~9V) Features ‧  ‧  ‧  ‧  ‧  ‧  ‧  ‧   ‧  ‧  ‧ ℃ ‧ Ⅱ ‧  ‧  ‧  ‧   ...
  • Page 28 Power Supply Specification SPECIFICATION PRODUCT GSM60B12-P1J SAFETY MODEL NO. GSM60B12 DC VOLTAGE Note.2 RATED CURRENT CURRENT RANGE 0 ~ 5A RATED POWER (max.) OUTPUT RIPPLE & NOISE (max.) 100mVp-p Note.3 ±3.0% VOLTAGE TOLERANCE Note.4 ±1.0% LINE REGULATION Note.5 ±3.0% LOAD REGULATION SETUP, RISE TIME 1000ms, 30ms / 230VAC 1500ms, 30ms / 115VAC at full load...
  • Page 29 Power Supply Specification Derating Curve Static Characteristics (HORIZONTAL) ℃ AMBIENT TEMPERATURE ( ) INPUT VOLTAGE (VAC) 60Hz Mechanical Specification Case No. GSM60B Unit:mm ± U 2464 16AWG 1000 50mm for 5 ~ UL1185 16AWG 1500±50mm for 18 ~ 48V 31.5 POWER LED ±...

  • Page 30: Ninjatrac Installation Checklist

    Protective plastic sheet from each pod removed. Check 2: Power up. ☐ All pods light up. ☐ Text appears on the display and is as expected. E.g. NinjaTrac. ☐ Sound volume is at a suitable level*. ☐ Large display screen is displaying graphics.
  • Page 31 ☐ Instruction / training carried out by an appropriate instructor to all new users. If anything unexpected occurs or problems persist after troubleshooting, call Rugged Interactive directly on +44 (0) 1726 833 882. * The volume can be adjusted on the speakers. The volume control can be located on the rear of the speaker.
  • Page 32 Next Steps Train team members Train your team members on how to use NinjaTrac, having knowledge of the gameplay will help them encourage users. Inspire them to cheer and celebrate with the customers when they achieve high scores. Maintenance General care and maintenance procedures for your Rugged Interactive product.
  • Page 33 Congratulations! Congratulations on your new Rugged Interactive product! Your customers are going to love this, and it is a great addition to your venue! If there is anything we can assist with or if you would be interested in information about any other Rugged Interactive products, then please do not hesitate to get in contact.
