- Page 1 High-9 Order and Installation Manual For models from May 2019 onwards Rugged Interactive Unit 1, Callywith Court Callywith Industrial Estate , Bodmin Cornwall, UK PL231 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk © Rugged Interactive 2019...
-
Page 2: Table Of Contents
Section 3 – Installation 3.1 Parts List 3.2 Tools and Components List 3.3 Installation Overview 3.4 Detailed Installation Section 4 – How to Use Section 5 – Programs Guide High-9 System Specifications High-9 Installation Checklist Next Steps © Rugged Interactive 2019... -
Page 3: Section 1 - Ordering Process
Installation manual purpose and limitations This manual is intended to provide guidance only, the installation of the Rugged Interactive product will be under your control. You will be responsible for making sure, upon completion of the installation, it is safe to use. -
Page 4: Order And Installation Checklist
1.2 - Order and Installation Checklist ☐ Contact the Rugged Interactive sales team or a partner / distributor to begin the process. Confirm the invoice and delivery address along with date required (lead time is at least 5 weeks), ☐... -
Page 5: Ordering And Installation Timeline
A standard High-9 unit consists of 3 x mouldings, 1 x HUB display and sound unit with all the cables supplied. It is easy and quick to install to any suitable wall. -
Page 6: Getting Started
If further information is required, please get in touch and we will be able to provide further information and guidance. 1.6 - Place Order Key Contacts at Rugged Interactive: Sales Office Address: Commercial Director – Harry Stevens Rugged Interactive, Harry@rugged-interactive.co.uk... -
Page 7: Section 2 - Safety Guidelines
Tidy back loose cables that could become a tripping hazard. ▪ Ensure that the playing area is clear. ▪ Immediately inform Rugged Interactive for maintenance advice if you have concerns. Don’ts: ▪ Do not wear shoes with leather soles or high heels. -
Page 8: In Play Safety Guidelines
High-9 Installation and Instruction Manual: Safety Guidelines 2.2 In Play Safety Guidelines Please ensure you read the following points before using the equipment: This activity can be great fun, but it can also be dangerous. There is a risk of serious injury if care is not taken when using the equipment. - Page 9 High-9 Installation and Instruction Manual: Safety Guidelines Don’ts: ▪ No more than one active user on a single trampoline at any one time. ▪ Do not attempt to use any of the equipment without undertaking instruction / training carried out by an appropriate instructor.
-
Page 10: Section 3 - Installation
1 x Spare Pod. ☐ Manual. ☐ * Please note, quantities are for a single High-9, if a High-9 Duo been ordered, double these quantities. Also included if a Duo has been ordered: ☐ 1 x Two player launch box (MPL) ☐... -
Page 11: Tools And Components List
High-9 Order and Installation Manual: Installation 3.2 - Tools and Components List Arrange the necessary tools and the team to install the product. Ladder. ☐ Spirit level. ☐ Socket Set. ☐ Industrial vacuum cleaner. ☐ Dustpan and brush. ☐ SDS impact drill. -
Page 12: Installation Overview
3.3 - Installation Overview Below is an overview of the steps needed to install High-9. More detail for the process is provided in the following pages. Please read through ALL of this prior to beginning the installation and if you are in any doubt, contact Rugged Interactive. -
Page 13: Detailed Installation
Read this manual before installing High-9. Installation Guidelines: Complete the Site Survey form prior to delivery and/or installation. ▪ Send a completed Installation Checklist after any installation to Rugged Interactive. ▪ A typical installation should take 2 people about 2 hours. ▪... - Page 14 A waiting / spectating area positioned nearby is advised. ▪ A leaderboard to go with each unit is highly recommended. ▪ IF YOU ARE IN ANY DOUBT, CALL RUGGED INTERACTIVE DIRECTLY ON +44 (0) 1726 833 882. High-9 – Section 3 - Installation © Rugged Interactive...
- Page 15 Support long cables at least every 50 cm and provide adequate strain relief for connection points. Once the High-9 unit has been mounted to the wall, connect the CAT5 cables from the Display Box to the corresponding connection points that exit through the wall from each High-9 unit.
- Page 16 High-9 Order and Installation Manual: Installation 700 mm 750 mm Upper 0 - 100 mm Middle 0 - 100 mm Lower Trampoline bed 500 - 1000 mm Figure 3.4.2: High-9 Orientation and Installation Heights High-9 – Section 3 - Installation © Rugged Interactive 2019...
- Page 17 High-9 Order and Installation Manual: Installation High-9 Display / Score Box (HUB) Installation Fix HUB using any suitable self-tapping or wood screws into the surface material. The HUB can be ▪ recessed to be flush with the surface or affixed on top of the foam-backed vinyl if necessary.
- Page 18 High-9 Order and Installation Manual: Installation Multiplayer Launch Box (MPL) Installation Fix MPL using any suitable self-tapping or wood screws into the surface material. The MPL can be ▪ recessed to be flush with the surface or affixed on top of the foam-backed vinyl if necessary.
- Page 19 High-9 Order and Installation Manual: Installation CAT5 Cable Connections Notes: The MPL power cable (PWR) can be connected to either unit. ▪ Cables come out the back of each unit. ▪ Figure 3.4.3: MPL Wiring Diagram Figure 3.4.4: Typical High-9 Installation High-9 –...
- Page 20 High-9 Order and Installation Manual: Installation High-9 – Pod Removal and Installation Removing the Pods Read this manual before removing or installing any pods. Do not worry which order the pods come off in. They can be refitted in any order.
-
Page 21: Section 4 - How To Use
Section 4 - How to Use On power up, High-9 will sound a ‘laugh’ and will turn to its idle state. Initially the dot matrix on the display box will display the Hub Software Version Number for the High-9 unit. -
Page 22: Section 5 - Programs Guide
+1 point for each red pod Duration: 1 minute NOTE: At any time, if the High-9 unit behaves unexpectedly during gameplay, wait for at least 20 seconds for the unit to reset to its idle state. High-9 – Section 5 - Programs Guide ©... - Page 23 High-9 (3 x mouldings, 1 x HUB) (2 x boxes) (per box) 750 x 450 x 750 18 kg High-9 Duo (6 x mouldings, 2 x HUB, 1 x MPL) (4 x boxes) (per box) Power Supply: AC: 110-230V, 50-60Hz, 13A Warranty: 1 year on electronics.
- Page 24 Bolt cover inserts are secure in place. Check 2: Power up. ☐ All pods light up. ☐ Text appears on the hub display and is as expected. E.g. High-9. ☐ Sound volume is at a suitable level*. Check 3: Start High-9 via any pod. ☐...
- Page 25 High-9 Order and Installation Manual: System Specifications Check 4: Select High-9 via the MPL (High-9 Duo only). ☐ Program counts down from 3 and starts on both High-9 units simultaneously. ☐ All pods active and operational. ☐ Check all pods for colours: red, green, blue.
- Page 26 Next Steps Train team members Train your team members on how to use High-9, having knowledge of the gameplay will help them encourage users. Inspire them to cheer and celebrate with the customers when they achieve high scores. Maintenance General care and maintenance procedures for your Rugged Interactive product.
- Page 27 Congratulations! Congratulations on your new Rugged Interactive product! Your customers are going to love this, and it is a great addition to your venue! If there is anything we can assist with or if you would be interested in information about any other Rugged Interactive products, then please do not hesitate to get in contact.
