SBC-350
User Manual
Version 1.0
Published July 2019
Copyright©2019 ASRockInd INC. All rights reserved.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SBC-350 and is the answer not in the manual?

Questions and answers

Summary of Contents for ASRock Industrial SBC-350

  • Page 1 SBC-350 User Manual Version 1.0 Published July 2019 Copyright©2019 ASRockInd INC. All rights reserved.
  • Page 2 Version 1.0 Published July 2019 Copyright©2019 ASRockInd INC. All rights reserved. Copyright Notice: No part of this documentation may be reproduced, transcribed, transmitted, or translated in any language, in any form or by any means, except duplication of documentation by the purchaser for backup purpose, without written consent of ASRockInd Inc.
  • Page 3: Table Of Contents

    Contents 1 Introduction ............5 1.1 Package Contents ............5 1.2 Specifications ..............6 1.3 Motherboard Layout ............8 1.4 I/O Panel ................ 10 2 Installation ............11 2.1 Screw Holes ..............11 2.2 Pre-installation Precautions ........... 11 2.3 Installation of Memory Modules (SO-DIMM) ....12 2.4 Expansion Slots .............
  • Page 4 4 Software Support ..........40 4.1 Install Operating System ..........40 4.2 Support CD Information ..........40 4.2.1 Running Support CD ............ 40 4.2.2 Drivers Menu ............... 40 4.2.3 Utilities Menu ............... 40 4.2.4 Contact Information ............. 40...
  • Page 5: Introduction

    Chapter 1: Introduction Thank you for purchasing ASRockInd SBC-350 motherboard, a reliable mother- board produced under ASRockInd’s consistently stringent quality control. It delivers excellent performance with robust design conforming to ASRockInd’s commitment to quality and endurance. In this manual, chapter 1 and 2 contain introduction of the motherboard and step- by-step guide to the hardware installation.
  • Page 6: Specifications

    1.2 Specifications Form Dimensions 3.5” SBC (6.3-in x 4.0-in) Factor ® Intel Gen (Whiskey lake-U) Core™ MCP Processors Processor - SBC-350P (i7-8665UE, QC, 1.7GHz, 15 W) System - SBC-350M (i5-8365UE, QC, 1.6GHz,15 W) - SBC-350V (i3-8145UE, DC, 2.2GHz, 15W) Chipset PCIe Mini-PCIe mSATA...
  • Page 7 2 x USB 2.0, 2 x USB 3.1 LVDS/ Inverter 1 x COM (RS232/422/485), 3 x COM Serial (RS232) SATA 1 x SATA3 (6.0 Gb/s) Internal Parallel Connector GPIO 4 x GPI, 4 x GPO SATA PWR Output Con Speaker Header SBC-350P/M: 1 x TPM 2.0 IC onboard SBC-350V: 1 x TPM 2.0 (For i3 CPU with...
  • Page 8: Motherboard Layout

    BKT_PWR1 HD_AUDIO1 BUZZ2 DDR4_A1 (Support DDR4 Only) SPEAKER1 DDR4_B1 (Support DDR4 Only) USB 3.0 T: USB1 B: USB2 USB 3.0 T: USB3 B: USB4 SATA3_1 SBC-350 DISPLAY1 BAT1 Industrial M2M_1 DISPLAY2 LAN1 LAN2 DC_JACK1 USB2_5_6 PWR_JP1 COM2 PANEL1 PLED PWRBTN...
  • Page 9 1 : Front Panel Audio Header 2 : 3W Audio AMP Output Wafer 3 : Buzzer 4 : Panel Power Select (LCD_VCC) (PNL_PWR1) 5 : BL1 6 : LVDS Panel Connector 7 : Inverter Power Control Wafer (BLT_PWR1) 8 : Backlight Power Select (LCD_BLT_VCC) (BKT_PWR1) 9 : BL2 10 : Backlight &...
  • Page 10: I/O Panel

    1.4 I/O Panel USB 3.1 Ports (USB12) LAN RJ-45 Port (LAN1)* USB 3.1 Ports (USB34) LAN RJ-45 Port (LAN2)* DisplayPort 1.2 (DP1) DC Jack (DC_JACK1) DisplayPort 1.2 (DP2) * There are two LED next to the LAN port. Please refer to the table below for the LAN port LED indications.
  • Page 11: Installation

    Chapter 2: Installation This is a 3.5” SBC (6.3-in x 4.0-in) form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard.
  • Page 12: Installation Of Memory Modules (So-Dimm)

    2.3 Installation of Memory Modules (SO-DIMM) SBC-350 provides two 204-pin DDR4 (Double Data Rate 4) SO-DIMM slots. Step 1. Align a SO-DIMM on the slot such that the notch on the SO-DIMM matches the break on the slot. 1. The SO-DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the SO-DIMM if you force the SO-DIMM into the slot at incorrect orientation.
  • Page 13: Expansion Slots

    2.4 Expansion Slots (M.2 Sockets) There are 3 M.2 sockets on this motherboard. M.2 Key-M Socket (M2M_1): Key M (2242/2280) with PCIe x4 and SATA3 for SSD M.2 Key-M Socket (M2M_2): Key M (2242) with SATA3 for SSD M.2 Key-E Socket (M2E_1): Key E (2230) with PCIe x1, CNVI and USB 2.0 for Wireless...
  • Page 14: Jumpers Setup

    2.5 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on pins, the jumper is “Short”. If no jumper cap is placed on pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short”...
  • Page 15 Backlight Power Select Use this to set up the backlight (LCD_BLT_VCC) power of the LVDS connector. 1-2: +5V (3-pin BKT_PWR1) 3 2 1 2-3: +12V (see p.8 No. 8) COM1 Pin9 PWR Setting Jumpers 1-2: +5V 2-3: +12V (3-pin PWR_COM1: see p.8 No. 29) (3-pin PWR_COM2: see p.8 No.
  • Page 16: Onboard Headers And Connectors

    2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage of the motherboard! SATA3 Connector These two Serial ATA3 SATA3_1 (SATA3) connectors support (SATA3_1: see p.8, No.
  • Page 17 HDLED (Hard Drive Activity LED): Connect to the hard drive activity LED on the chassis front panel. The LED is on when the hard drive is reading or writing data. The front panel design may differ by chassis. A front panel module mainly consists of power switch, reset switch, power LED, hard drive activity LED, speaker and etc.
  • Page 18 COM Port Headers (10-pin COM1) (see p.8 No. 19) (10-pin COM2, 3, 4) (see p.8 No. 25) Signal Signal Signal Signal Signal Name Name Name Name Name DDCD# TTXD RRTS# DUMMY RRXD DDTR# DDSR# CCTS# DUMMY This motherboard supports RS232/422/485 on COM1 port. Please refer to below table for the pin definition.
  • Page 19 LVDS Connector (40-pin LVDS1) (see p.8 No. 6) Front Panel Audio Header (9-pin HD_AUDIO1) (see p.8 No. 1) 1. High Definition Audio supports Jack Sensing, but the panel wire on the chassis must support HDA to function correctly. Please follow the instruction in our manual and chassis manual to install your system.
  • Page 20 LPC Header This connector supports Trusted Platform Module (TPM) (18-pin LPC1) F_CLKRUN# system, which can securely SERIRQ# +3VSB (see p.8 No. 21) store keys, digital certificates, LAD0 LAD1 passwords, and data. A TPM LAD3 LAD2 PCIRST# system also helps enhance FRAME network security, protects PCICLK...
  • Page 21: Uefi Setup Utility

    Chapter 3: UEFI SETUP UTILITY 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer. Please press <F2>...
  • Page 22: Navigation Keys

    3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Enter>...
  • Page 23: Advanced Screen

    3.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configu- ration, Chipset Configuration, Storage Configuration, Super IO Configuration, AMT Configuration, ACPI Configuration, USB Configuration and Trusted Computing. Setting wrong values in this section may cause the system to malfunction.
  • Page 24: Cpu Configuration

    3.3.1 CPU Configuration Intel Hyper Threading Technology To enable this feature, a computer system with an Intel processor that sup- ports Hyper-Threading technology and an operating system that includes ® ® optimization for this technology, such as Microsoft Windows 7 / 8 / 8.1 / ®...
  • Page 25 Intel Turbo Boost Technology Use this item to enable or disable Intel Turbo Boost Mode Technology. Turbo Boost Mode allows processor cores to run faster than marked fre- quency in specific conditions. The default value is [Enabled]. CPU Thermal Throttling You may select [Enabled] to enable CPU internal thermal control mechanism to keep the CPU from overheating.
  • Page 26: Chipset Configuration

    3.3.2 Chipset Configuration VT-d ® ® Use this to enable or disable Intel VT-d technology (Intel Virtualization Technology for Directed I/O). The default value of this feature is [Disabled]. Share Memory Configure the size of memory that is allocated to the integrated graphics processor when the system boots up.
  • Page 27 Onboard HD Audio Select [Auto], [Enabled] or [Disabled] for the onboard HD Audio feature. If you select [Auto], the onboard HD Audio will be disabled when PCI Sound Card is plugged. Deep Sleep Mobile platforms support Deep S4/S5 in DC only and desktop platforms support Deep S4/S5 in AC only.
  • Page 28: Storage Configuration

    3.3.3 Storage Configuration SATA Controller(s) Use this item to enable or disable the SATA Controller feature. SATA Mode Selection Use this to select SATA mode. The default value is [AHCI Mode]. AHCI (Advanced Host Controller Interface) supports NCQ and other new features that will improve SATA disk perfor- mance but IDE mode does not have these advantages.
  • Page 29: Super Io Configuration

    3.3.4 Super IO Configuration COM1 Configuration Use this to set parameters of COM1. Type Select Use this to select COM1 port type: [RS232], [RS422] or [RS485]. COM2 Configuration Use this to set parameters of COM2. COM3 Configuration Use this to set parameters of COM3. COM4 Configuration Use this to set parameters of COM4.
  • Page 30: Amt Configuration

    3.3.5 AMT Technology Intel AMT Use this to enable or disable Intel(R) Active Management Technology BIOS Extension. The default is [Enabled]. BIOS Hotkey Pressed Use this to enable or disable BIOS hotkey press. The default is [Disabled]. MEBx Selection Screen Use this to enable or disable MEBx Selection Screen.
  • Page 31 PET Progress User can enable or disable PET Events progress to receive PET events or not. The default is [Enabled].
  • Page 32: Acpi Configuration

    3.3.6 ACPI Configuration Suspend to RAM Use this item to select whether to auto-detect or disable the Suspend-to- RAM feature. Select [Auto] will enable this feature if the OS supports it. Onboard LAN Power On Use this item to enable or disable onboard LAN to turn on the system from the power-soft-off mode.
  • Page 33: Usb Configuration

    3.3.7 USB Configuration Legacy USB Support Use this option to select legacy support for USB devices. There are two configuration options: [Enabled] and [UEFI Setup Only]. The default value is [Enabled]. Please refer to below descriptions for the details of these two options: [Enabled] - Enables support for legacy USB.
  • Page 34: Trusted Computing

    3.3.8 Trusted Computing Security Device Support Enable or disable BIOS support for security device.
  • Page 35: Hardware Health Event Monitoring Screen

    3.4 Hardware Health Event Monitoring Screen In this section, it allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage. CPU_FAN1 Setting This allows you to set CPU fan 1’s speed.
  • Page 36: Security Screen

    3.5 Security Screen In this section, you may set, change or clear the supervisor/user password for the system. Supervisor Password Set or change the password for the administrator account. Only the ad- ministrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.
  • Page 37: Boot Screen

    3.6 Boot Screen In this section, it will display the available devices on your system for you to config- ure the boot settings and the boot priority. Boot From Onboard LAN Use this item to enable or disable the Boot From Onboard LAN feature. Setup Prompt Timeout This shows the number of seconds to wait for setup activation key.
  • Page 38 CSM (Compatibility Support Module) Enable to launch the Compatibility Support Module. Please do not disable ® unless you’re running a WHCK test. If you are using Windows 8.1 / 8 64- bit and all of your devices support UEFI, you may also disable CSM for faster boot speed.
  • Page 39: Exit Screen

    3.7 Exit Screen Save Changes and Exit When you select this option, it will pop-out the following message, “Save configuration changes and exit setup?” Select [OK] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, it will pop-out the following message, “Discard changes and exit setup?”...
  • Page 40 Chapter 4: Software Support 4.1 Install Operating System ® ® This motherboard supports various Microsoft Windows operating systems: 10 / 10 64-bit / 8.1 / 8.1 64-bit / 8 / 8 64-bit / 7 / 7 64-bit. Because motherboard settings and hardware options vary, use the setup procedures in this chapter for general refer- ence only.
