- Page 1 QUICK START GUIDE...
-
Page 2: What's In The Box
What’s in the box 64GB micro SD Fly6 Seat post Aero + standard card (preinstalled) Generation 3 mount seat post strap 0° Spacer Aero + D shape USB-A - USB-C Safety seat post adaptor cable tether... - Page 3 Fly6 layout Power Q button button...
- Page 4 Fly6 layout Recording indicator light Port cover Microphone microSD card slot Tail light Charge port...
-
Page 5: Before Your First Ride
Before your first ride Please follow these simple steps before your first ride with your Fly6 Generation 3. 1. Ensure you fully charge the Fly6. 2. Ensure the Fly6 port door is securely closed. 3. Ensure the safety tether is correctly attached. - Page 6 Connecting to the Fly6 for the first time All Fly6 settings can be managed using the CycliqPlus mobile app. Connecting to your mobile device The Fly6 uses Bluetooth for connection to your smartphone. The first time you connect you will need to follow the below steps to enable Bluetooth.
- Page 7 Mounting the Fly6...
- Page 8 Mounting the Fly6 1. Insert either the standard or aero strap into the seat post mount and pull the strap all the way through. Ensure the silicon coated part of the strap is positioned to grip onto your seat post. 2.
-
Page 9: Light Modes
Light modes You can cycle through the available light modes using the power button. Camera Only (Tail light off) Constant High (Tail light solid with high intensity) Constant Low (Tail light solid with low intensity) Flash High (Tail light flashing with high intensity Flash Low (Tail light flashing with low intensity) Organic (Random generation of high and low intensity) All light modes are available by default on the Fly6. -
Page 10: Battery Level Indicator
Battery level indicator When turning on your Fly6, an audible battery status will sound indicating the current battery level. 4 rapid high pitched beeps = 75% to 100% charged 3 rapid high pitched beeps = 50% to <75% charged 2 rapid high pitched beeps = 25% to <50% charged 1 rapid high pitched beeps = 12% to <25% charged 3 long high pitched beeps = less than 12% charged... - Page 11 Looping function The Fly6 was designed as a set and forget cycling safety device. The footage is set to record on a continuous loop so you don’t have to worry about running out of storage space on the microSD card. When there is no free space left to record on your microSD card, the Fly6 will start recording over the oldest video file first.
- Page 12 Incident Protection Incident protection mode has been designed to save your footage from major incidents without being recorded over. Incident protection mode is activated when the Fly6 is tilted more than 60° from vertical (or 30° from the ground) for more than five seconds.
-
Page 13: Image Capture
Image capture Manual footage capture If you witness an event that you want to capture and retain when riding, simply hold the Q button for approximately 2 seconds. This will lock the current and preceding video files. Three rapid beeps will sound to confirm the video files have been locked. - Page 14 1. Connect the Fly6 to a PC or Mac using the USB cable. 2. Remove the microSD card and read data using your PC or Mac. 3. Using a Cycliq On The Go Card Reader. Editing footage You can edit your footage using the CycliqPlus desktop and mobile app.
- Page 15 UpRide your ride Evidence makes a difference! If you've had an incident on the roads, been subjected to a close pass or capture any other dangerous activity, upload it to www.UpRide.cc and use your footage to help make cycling safer. Then share your UpRide with your community and help spread the word.
-
Page 16: Tech Specs
Tech specs Feature Specification 1920 x 1080p @ 30fps Recording 1280 x 720p @ 60fps Lens angle 135° wide viewing angle Video format Lumens 50lm max output Weight 75.5g / 2.66oz Dimensions 71mm (H) x 35mm (W) x 40mm (D) Battery 2000mAh, 7.6Wh (up to 5 hours) Port... - Page 17 Scan for more information C Y C L I Q . C O M...
