CYCLIQ.COM
USER GUIDE
MODEL: CE603

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fly6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for cycliq Fly6

Summary of Contents for cycliq Fly6

  • Page 1 CYCLIQ.COM USER GUIDE MODEL: CE603...

  • Page 2: Table Of Contents

    Contents What’s in the box Visual and audio alerts CycliqPlus mobile app Read this before using your Fly6 Audio settings Connecting to your modile device Safety, operating and care information Audiable alerts Time and date settings Cautions Airplane Mode File lock warning...

  • Page 3: What's In The Box

    What’s in the box 1 x Fly6 1 x Cycliq 32GB microSD card 1 x Seat post mount 1 x Standard seat post strap 1 x Aero seat post strap 1 x 0° Spacer 1 x D-shaped seat post adaptor...

  • Page 4: Read This Before Using Your Fly6

    Disclaimer  Cautions The Fly6 is designed specifically to be used as a rear ‘tail light’ with video and • Warning! No modification of this device is allowed. Opening the housing of audio recording capabilities for bicycles. While every effort has been made the Fly6 will damage the water-resistant seal and void your warranty.

  • Page 5: Your Fly6

    Your Fly6 Register your Fly6 We strongly advise that you register your Fly6 with Cycliq. Once registered, you’ll receive notifications for new software or firmware updates, new features and user tips. Registration also speeds up the process should you require assistance with technical support or warranty queries.

  • Page 6: Fly6 Layout

    Fly6 layout Front and back layout Side layout Front: port cover opened Fly6 CE603 User Guide | 6 of 29...

  • Page 7: Setting Up Your Fly6

    4 rapid high pitched beeps = 75% to 100% charged • The indicator light will illuminate red showing the Fly6 is charging. • The indicator light will illuminate green when the Fly6 is fully charged. You can charge your Fly6 using the USB cable provided and your computer however, this will significantly reduce the rate of charge.

  • Page 8: Inserting And Removing The Microsd Card

    • Your Fly6 comes with a 32GB microSD card pre-installed. • Your Fly6 MUST have a microSD card installed to operate. You can insert a microSD card into the microSD card slot of your Fly6 and press in gently until locked in place.

  • Page 9: Changing Your Fly6 Settings

    Changing your Fly6 settings Most of the primary functions of the Fly6 can be controlled using the Power and Q buttons on the side of the Fly6. Power button Q button Summary On the Fly6 • All primary functions can be accessed using the Power and Q buttons.

  • Page 10: Mounting Your Fly6

    Mounting your Fly6 to your bike Your Fly6 comes with a seat post mount that features the Cycliq 1/8 Turn Quick Release System. There are 2 Velcro strap lengths included to allow for mounting to traditional (narrow) and aero (wide) seat post styles.

  • Page 11: Attaching The Safety Tether

    Attaching the safety tether to your Fly6 1. On the back of the Fly6 there are 2 holes for the safety tether to be attached through. 2. Thread the thinner part of the tether through the holes, then thread the other end through the loop to secure the tether.

  • Page 12: Using Your Fly6

    Please follow all the below steps before Press and hold the Power button (for approximately 3-4 seconds) until the going out on your first ride with your Fly6. rotating LED bezel illuminates and the ‘power on’ chime is heard – then release.

  • Page 13: Tail Light Options

    To maximise battery life, select a lower intensity tail light option and turn off your Fly6 when not in use. Your tail light mode and intensity will be remembered when you power off your Fly6. The next time you power on your Fly6 it will resume with the previously used light mode and intensity.

  • Page 14: Visual And Audio Alerts

    None Fly6 requires charging Single solid green indicator light None 100% charged & Fly6 is connected to a working charger Single solid red indicator light None 0-99% charged & Fly6 is connected to a working charger Single solid blue indicator light...

  • Page 15: Audio Settings

    CycliqPlus app. This provides a short beep at 3, 5, rendering it compliant for airline travel, transport for audible alarms and alerts. or 10-minute intervals to notify you that your Fly6 and shipping. is recording video footage. This is particularly To activate Airplane Mode the Fly6 must be useful as you can’t see the rotating bezel whilst...

  • Page 16: Features

    Video resolution The Fly6 is equipped with a Full HD camera. The lens has a 135° viewing angle providing an ultra-wide view of what’s going on behind you. There are two video resolutions to choose from. More storage space and power will be used with the higher resolution setting.

  • Page 17: Looping Function

    Capturing still images Your Fly6 can take still images while recording video. You can do this by holding the Q and power button simultaneously for 1 second. This image will be saved as a JPEG and can be accessed with the rest of your footage...
  • Page 18 When Incident Protection Mode is triggered, or if you trigger manual footage capture, the current segment will be locked and will continue recording until the current segment is complete or the Fly6 is turned off. For example, if you trigger Incident Protection Mode 3 minutes into a 5 minute segment, your Fly6 will also record the following 2 minutes and save it as a locked file.

  • Page 19: Cycliq Home Safe Mode

    CycliqPlus app. The default setting is disabled. in Bluetooth range. If the Fly6 is recording and the tail light is in use  Caution The bike alarm can be turned off (if you are in when Home Safe Mode is activated then the Bluetooth range) via the CycliqPlus mobile app.

  • Page 20: Accessing Your Footage

    After your ride, you can access your footage in two ways: The table below gives an indication of approximate file size per segment length: 1. Connect your Fly6 directly to any PC or Mac using the supplied USB cable. Example at 1080p FHD @30fps 2.

  • Page 21: Cycliqplus Mobile App

    Your Fly6 uses Bluetooth for connection to your iOS or Android device. The default setting is for Bluetooth to be on only when the Fly6 is powered on. You can also manually input the date and time via the CycliqPlus desktop app.

  • Page 22: Updating Your Firmware

    Updating your firmware Making sure you have the most up to date firmware will give you the best Cycliq experience possible. Cycliq auto-updater Download the macOS or Windows version of the Firmware auto-updater app from the links below, open it up from your desktop and follow the on screen instructions.

  • Page 23: Troubleshooting

    Troubleshooting your Fly6 Rebooting your Fly6 If your Fly6 requires a reboot, press and hold the Q button for 10 seconds and your Fly6 will restart. Q button  Warning! DO NOT reboot your Fly6 when in the process of completing a firmware update as this may damage your Fly6.

  • Page 24: Join The Cycliq Community

    We love being part of the global cycling community and hope to improve the safety of everyone on the road. We’re active on social media and if you use Strava, we welcome you to join the Cycliq Strava club and ride with our members from around the world.

  • Page 25: Technical Data

    Power Source Rechargeable Lithium ion Battery Battery Size 2000mAh (approx. 5 hours in camera only Mode) Watt Hours 7.6Wh Voltage 3.7v Ingress Protection IP56 Operating Temperature/Humidity 0-45°C (32–113°F) Storage Temperature/Humidity 0-45°C (32–113°F) Fly6 CE603 User Guide | 25 of 29...

  • Page 26: Compliance Statements

    • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Fly6 CE603 User Guide | 26 of 29...
  • Page 27 FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. Fly6 CE603 User Guide | 27 of 29...

  • Page 28: Regulatory Information

    20cm from nearby persons. Cycliq customer support Warning  Please go to support.cycliq.com for further information and support. Changes or modifications to this unit not expressly approved by the party  Caution responsible for compliance could void the user’s authority to operate the equipment.
  • Page 29 CYCLIQ.COM  PO Box 404 Subiaco WA 6904 Australia  info@cycliq.com Fly6 CE603 User Guide - Version 3.05.07 MODEL: CE603 Fly6 CE603 User Guide Cycliq reserves the right, at its discretion, to change and modify portions of this User Guide.
